Presentation Transcript
beam tests of an integrated tpc endplate with 2 phase co2 cooling

Beam tests of an integrated TPC endplatewith 2-Phase CO2 cooling

Gaseous detectors, upgrade of the Large Prototype at DESY

Integration of endplate and module systems

P. Colas

slide2
Menu
  • Integration of electronics
  • Cooling
    • Advantages of 2PCO2
    • TRACI
    • Test on one module at NIKHEF
    • Test on 7 modules at DESY Test Beam
  • Spending
  • Future (AIDA 2?)

TPC module integration

integration of electronics
Integration of electronics
  • AFTER-basedelectronics (T2K) must beminiaturized to fit behind a module within 5cm and 0.25 X°.
  • This has been achieved (within AIDA) (62700 € in 2013)

TPC module integration

integrated electronics

This is for AFTER chips. Similarworkisbeingdonewith S-ALTRO

Integrated electronics
  • Remove packaging and protection diodes
  • Wire-bond AFTER chips
  • Use two 300-point connectors

Front-End Card

(FEC)

25 cm

4.5cm

12.5cm

14 cm

3.5cm

2.8cm

0.78cm

3.5cm

AFTER Chip

0.74cm

  • The resistive foil protects against sparks
cooling why 2 phase co2
COOLING: why 2-phase CO2?
  • Lowviscosityallowsverysmall pipe diameter and lowDP.
  • Very large latent heat and heatcapacitymakesit an excellent cooler
  • Can work at room temperature (avoidsdripping water by condensation)
  • Howeverneedsvery high pressures (50 bar for 20 degrees)

TPC module integration

cooling why 2 phase co21
COOLING: why 2-phase CO2?

TPC module integration

cooling traci
COOLING: TRACI
  • Weused the TRACI purchased by KEK and installed at DESY in February 2014.

TPC module integration

cooling tests at desy 7 modules1
COOLING: Tests at DESY (7 modules)

7 temperature probes

(1 per FEC, 1 FPGA)

TPC module integration

spending
SPENDING
  • The ‘plumbering for the coolingcosted about 22 k€ in 2014.
  • 100% of the spending for this has been used. The resultsoverpass the initial goals.

TPC module integration

outlook
outlook
  • New materials. (Ex: TPG) lighterthan Al, withtwicebetter thermal conductivity
  • New technique (3D printing) allows micro-channels to bebuilt

TPC module integration

summary
Summary
  • A demonstration of full integration of an endplate meeting the requirements of a LC TPC has been made.
  • A first try of using 2PCO2 for a TPC has been made, showingthatthis solution isvery attractive.
  • This opens the way to furtherdevelopments, using new materials (TPG) and new techniques (3D printing) to getuniformtemperatureacross the endplate.

TPC module integration
