reminder proposal presentation on monday march 5
Reminder: Proposal Presentation on Monday, March 5
  • Prepare powerpoint slides to motivate your project and show the overall approach to tackling the problem
  • Come at least 10 minutes before the class begins
    • Give your slides to the tech staff
    • Lean how to use the presentation tool etc.
  • Teams & presentation order:
    • Mike & Vic (+ Brian)
    • Chris & Yan
    • Dahee & Chao
    • Surabh
    • Mehmet
design goals of b mac
Design goals of B-MAC
  • Low power operation
  • Effective collision
  • Simple implementation, small code & RAM size
  • Efficient channel utilization at low & high data rates
  • Reconfigurable by network protocols
  • Tolerant to changing RF/Networking conditions
  • Scalable to large numbers of nodes
small configurable mac
Small, configurable MAC
  • Export control to higher services to support wide variety of WSN workloads
    • WSNs are supposed to support various applications
  • S-MAC (discussed in the previous class) is more than a link layer protocol
    • Drawbacks of S-MAC
      • Scalability: A node may have to remember many schedules and wake up accordingly
      • MAC layer may not be the best place for sleep scheduling & synchronization
adaptive reconfigurable mac
Adaptive, reconfigurable MAC
  • Adaptive bidirectional interface for WSN applications
    • Reconfigure the MAC protocol based on the current workload
    • Identify the best parameters for an arbitrary low power WSN applications at compile or run time & estimate the application’s lifetime
b mac design
B-MAC Design
  • Really simple
    • CSMA via CCA (Clear Channel Assessment) & backoff
    • Low power listening via Preamble
    • Acknowledgment
  • Enable/disable anything above and allow to build anything on top of the configured B-MAC!
clear channel assessment
Clear Channel Assessment
  • Effective collision avoidance
  • Find out whether the channel is idle
    • If too pessimistic: waste bandwidth
    • If too optimistic: more collisions
  • Key observation
    • Ambient noise may change significantly depending on the environment
    • Packet reception has fairly constant channel energy
  • Software approach to estimating the noise floor
slide9
Take a signal sample when the channel is assumed to be free
    • Right after a packet is transmitted or when no valid data is received
    • Take exponential moving average (EMA) of the median signal strength
      • Works as a low pass filter
      • Smoothed idle signal level Sm(t)= a * S(t) + (1 - a) * Sm(t-1)
        • Sm(t): EMA at time t
        • S(t-1): Signal strength of ambient noise at t
        • Sm(t-1): EMA at time t-1
    • It contrasts to common threshold-based methods in which only a single sample is taken
    • Resilient to time-varying ambient noise
cca vs threshold techniques
CCA vs. Threshold techniques

Idle

CCA dynamically

adjusts threshold

CCA finds channel

busy/idle status with

high accuracy

  • Threshold: waste channel utilization
  • CCA: Fully utilize the channel since a valid packet could have no outlier significantly below the noise floor
slide11
CCA can be turned on/off
    • If turned off, a schedule-based protocol, e.g., S-MAC, can be implemented atop B-MAC
  • If turned on, initial channel backoff when sending a message
  • B-MAC does not set the backoff time, but signals an event to the higher service that sent the packet
  • The higer level service may return an initial backoff time or ignore the event
    • If ignored, use a short random delay
low power listening preamble sampling
Low Power Listening: Preamble Sampling
  • Preamble is not a packet but a physical layer RF pulse
    • Minimize overhead

Send data

Preamble

Sender

S

R

Receiver

Active to receive a message

Preamble sampling

|Preamble| ≥ Sampling period

optional link layer ack
Optional link layer ACK
  • If enabled, ACK is sent immediately after receiving a unicast packet
  • Overall, B-MAC is easier to implement than S-MAC
    • No RTS/CTS
      • Is this always good?  or ?
      • We know RTS/CTS can reduce hidden/exposed node problem
      • You may have to implement RTS/CTS on your own...
      • Simple but not very friendly
    • No synchronization
      • No need for a schedule table in S-MAC
      • But periodic sleep & wake-up is a good approach to energy saving
modeling lifetime
Modeling Lifetime
  • Monitoring applications
  • E = Esleep + Elisten + Ed + Erx + Etx
  • Given #nodes in the neighborhood, BMAC can estimate the network lifetime
  • Lifetime tl = 1/E * Cbatt * V * 60 * 60
derivation of lifetime
Derivation of Lifetime
  • Ed = td * cdata * V where td = tdata * r
  • Etx = ttx * ctxb * V where ttx = r * (Lpreamble + Lpacket) * ttxb
  • Erx = trx * crxb * V where trx ≤ n * r * (Lpreamble + Lpacket) * trxb
    • r * sum_i=1^n ( children (i) + 1 )
    • Lpreamble ≥ ti / trxb
derivation of lifetime cont d
Derivation of Lifetime (Cont’d)
  • Esample = 17.3 uJ
  • Elisten ≤ Esample * 1/ti
  • tlisten = (tr_init + tr_on + trx/tx + tsr) * 1/ti
  • tsleep = 1 – trx– ttx– td– tlisten
  • Esleep = tsleep * csleep * V
  • Lifetime tl = 1/E * Cbatt * V * 60 * 60
network parameters
Network Parameters
  • Scientists may determine the physical location of the nodes & ideal sampling rate
    • Compute the parameters to get the best lifetime that B-MAC can achieve
    • Best LPL check interval is the lowest line at a given network density in the following graph

If n=60, 25ms is

best

If n = 20, 50ms check

interval is optimal

experiments
Experiments
  • Compare BMAC to S-MAC & T-MAC
    • T-MAC is similar to S-MAC, but a receiver goes to sleep if it does not receive any message
    • B-MAC & S-MAC: implemented in TinyOS
    • TMAC: simulated in Matlab
tinyos implementation
TinyOS Implementation
  • B-MAC does not need timestamp
packet transmission time vs checking frequency
Packet transmission time vs. Checking frequency
  • More frequent checking of the radio
    • Shorter transmission time
    • More energy consumption

LPL check interval

channel utilization
Channel utilization
  • Place n nodes equidistant from a receiver
  • Increase n to increase load
  • BMAC relies on higher level services to send data according to the traffic pattern
    • Consider hidden node problem too
    • For example, after a packet is sent to the parent, nodes in the same cell wait for a certain amount of time for the parent to forward the packet up the tree Always work? More difficulty for developing sensing applications?
classic protocols
Classic Protocols
  • TDMA (Time Division Multiple Access)
    • A node can sleep when it is not its turn to send or receive
  • FDMA (Frequency Division Multiple Access)
  • CDMA (Code Division Multiple Access)
  • No node within two hops can use the same slot to avoid the hidden node problem
optimal channel assignment
Optimal channel assignment
  • Achieve contention-free communication using the minimum number of channels
  • The problem of assigning a minimum number of channels for an arbitrary graph is NP-hard
    • Develop efficient heuristics
    • Centralized approaches do not scale
stationary mac and startup
Stationary MAC and Startup
  • Local synchronization only
  • Starting phase
    • Handshaking on a common control channel
    • Each link utilizes a unique random frequency or CDMA frequency hopping code
    • Assume there are sufficiently many frequencies or codes
    • Periodically use the slot
bfs dfs based scheduling
BFS/DFS-based scheduling
  • Breadth-first or depth-first traversals of a data gathering tree
  • Every single node is given a slot
  • BFS might provide more chances for aggregation
  • DFS may transmit individual data more quickly
  • Global synchronization required
reservation based synchornized mac resync
Reservation-based synchornized MAC (ReSync)
  • TDMA is not flexible enough to allow the traffic from each node to change over time
  • ReSync provides more flexibility
  • Each node maintains an epoch based on its local time (or can be synchronized with nearby neighbors)
    • Select a regular time in each epoch to send a short intent message
      • Probability of collisions is low since the intent is very short
    • Listen long enough to learn when the neighbor is sending the intent
    • The intended receiver wakes up at the corresponding time to receive the message
    • No RTS/CTS
      • Data transmissions are scheduled randomly
traffic adaptive medium access trama
Traffic-adaptive medium access (TRAMA)
  • Distributed TDMA for flexible & dynamic scheduling of time slots
  • Divide time epochs into a set of short signaling slots followed by a set of longer transmission slots
  • Key components
    • Neighbor protocol (NP)
    • Schedule exchange protocol (SEP)
    • Adaptive election algorithm (AEP)
neighbor protocol
Neighbor Protocol
  • Nodes exchange one-hop neighbor info during the random access signaling slots
    • Ensure the slots are long enough to allow all nodes to get consistent two-hop neighbor info
schedule exchange protocol
Schedule exchange protocol
  • Each node publishes its schedule during the last winning slot in each epoch
  • Use bitmaps to indicate the intended unicast or multicast recipients
  • Sleep when not required to transmit or receive
adaptive election algorithm
Adaptive election algorithm
  • Hash function based on node IDs and time
    • Ensure there’s a unique ordering of node priorities within any two-hop region at each time
    • A node transmits iff it has the highest priority among the two hop neighbors at the moment
    • Sophisticated slot reuse protocol
summary
Summary
  • MAC protocols in WSNs
    • Arbitration for access to the wireless channel
    • Energy conservation
  • B-MAC is a nice building block for diverse applications and workloads
    • TDMA, for example, can be built on top of it
  • Energy savings
    • Preamble
    • S-MAC like periodic sleep & wake-up
    • Adaptive listening in S-MAC & T-MAC
    • D-MAC & DESS try to minimize the E2E delay, while using sleep modes
  • TDMA
    • No idle listening
    • Higher complexity distributed algorithms or tight synchronization required
