wecc phase 1 rating process coordinated planning and technical studies

WECC Phase 1 Rating ProcessCoordinated PlanningandTechnical Studies

July 18, 2008

Portland Oregon

Order 2004 Sensitive

welcome

Welcome

Darrell Gerrard - PacifiCorp

big tent meeting july 18 2008 embassy suites hotel portland 9 00 a m 12 00 noon agenda

Big Tent MeetingJuly 18, 2008Embassy Suites Hotel – Portland9:00 a.m. – 12:00 noonAgenda

9:00 Welcome – Darrell Gerrard

Background from January 2008 Session

Goals Supporting Coordination

9:15 FERC Perspectives – Shelton Cannon, Director

9:30 TCWG Work Plan- What has been accomplished since January 2008 – Ben Morris

10:00 Individual Project Updates (By Project Sponsor)

11:30 Next Steps and Timelines for TCWG – Darrell Gerrard

11:45 Inputs and Commentary – Sponsor Panel

3

background
Background
  • Purpose: status update for 9 proposed projects significant to Northwest
  • All projects currently in or will be in WECC Phase 1 Rating Process
  • Began January 2008 with Transmission Coordinated Work Group (TCWG)
  • Goal is submission of Phase 1 reports in the September – November 2008
  • Sponsors are reasonably on schedule
  • Each project sponsor will be submitting an individual Project Phase 1 Rating report to WECC
  • Expectations are that projects enter Phase 2 together in the fourth quarter of 2008
goals supporting coordination
Goals Supporting Coordination
  • Develop ideas to ensure robust proposals brought to sub-regional & regional engagement
  • Avoid duplication of study work and facilities constructed
  • Ensure efficient use of resources, siting, permitting, environmental
  • Regional view of transmission requirements necessary long term
  • NW Transmission Hub concept formulated
  • Optimize current expansion plans from commercial as well as technical views
  • Open and transparent FERC Order 890 compliant planning
  • Improved certainty of project Phase 2 ratings expected via WECC process
ferc perspective

FERC Perspective

Shelton Cannon, Director

Office of Energy Market Regulation

Federal Energy Regulatory Commission

6

objectives
Objectives

Coordinate the WECC Phase 1 Rating (non Simultaneous) studies for projects that meet the following criteria:

Currently (or soon will be) in Phase 1

Planned submission of Comprehensive Progress Reports in Sep-Nov

Agree to using a common methodology

All projects involve construction in the Northwest

Projects that meet such Criteria include: (list in order of presentation)

West of McNary Project (BPA)

I-5 Corridor Reinforcement BPA)

Idaho-Northwest Project (Idaho Power and Others)

Walla Walla-McNary (PacifiCorp)

Hemingway-Captain Jack (PacifiCorp)

Canada to Northern California Project (PG&E and Others)

Canada to Northern California Project – Devil’s Gap Interconnection (Avista)

Southern Crossing Project (PGE)

Northern Lights Project (TransCanada)

Others

Coordination facilitated by the Technical Coordination Work Group

8

technical coordination work group tcwg
Technical Coordination Work Group (TCWG)

Group formed to

Establish consistent assumptions/methods for Project Sponsors

Provide feedback on the Project Sponsor study work

Activities

Develop consistent Assumptions, Switch Decks, Base Cases

Identify and establish consistent assumptions for the analysis of Hubs

Review and Comment on Project Sponsor Study Plans, Assumptions, Study Results and Comprehensive Progress Report

Attend monthly meetings or conference calls through study completion

Six meetings held

Next meeting scheduled for August 21

Participation – Approximately 30 meeting attendees and more than 80 on the correspondence list

Representatives from Phase 1 projects

Other stakeholders with interest in providing feedback on technical studies

9

slide12

Transmission Projects in Regional Planning and/or Phase 1

Planned Operation: 2010 – 2015

* RP = WECC Regional Planning Process

Ph 1 = WECC Rating Process: Phase 1

12

slide13

Project Sponsor Activities/Progress for Phase 1

  • Developed Study Plan
  • Developed Study Assumptions
    • Identified the location and capacity of new incremental generation to be accessed with the proposed project
    • Listed Major paths to be monitored and their target flows
    • Identified the projects in the WECC Phase II Rating process to be modeled in the cases
    • Set of critical contingencies to be studied
  • Developed Base Cases:
    • Seasonal cases:
      • 2015 Heavy Summer (North-South Flow)
      • 2017 Heavy Winter (South-North Flow)
      • 2011 Light Spring (East-West Flow)
      • 2010 Light Autumn(East-West Flow)
    • Reviewed and adjusted Load and Generation balance as necessary

13

project sponsor activities progress
Project Sponsor Activities/Progress

Conduct Studies pre and post Project (In Progress)

Power flow

Transient Stability

Voltage Stability

Identify known interactions with existing facilities and Phase 3 projects (In Progress)

Communication of Study Progress and Results (In Progress)

Participate in Monthly Meetings/Teleconferences of the Phase 1

Participate in Joint Big Tent meetings

14

next steps coordination of phase 2 studies
Next Steps: Coordination of Phase 2 Studies
  • TCWG is the basis for the Phase 2 Project Review Group
      • No need to have separate review teams for individual projects
  • Timing
      • Regular monthly meetings through Phase 2 – a meeting schedule will be published in the 4th Quarter 2008
      • Recognize individual projects will proceed through Phase 2 on different schedules
      • TCWG will function until the last project gets through Phase 2 at a minimum
  • Coordination Activities
      • Common/Similar assumptions
      • Interactions with other TCWG- coordinated projects in Phase 2
      • TCWG is currently developing a base case with TCWG-coordinated projects

15

proposed schedule for coordinated studies
Proposed Schedule for Coordinated Studies
  • Announce Phase 1 and Form Study Teams Dec 2007 – Jan 2008
  • Joint Big Tent Meeting Jan 24, 2008
  • Develop Assumptions (TCWG) Feb 2008
  • Prepare and Finalize Project Study Plans (TCWG) Feb 2008
  • Prepare Base Cases (TCWG) Mar 2008
  • Pre-Project Studies (Project Sponsor) April 2008
  • Joint Big Tent Meeting Jul 18, 2008
  • Technical Studies on Individual Projects (Project Sponsor) May-Aug 2008
  • Draft Comprehensive Progress Reports (Project Sponsor) Aug-Sep 2008
  • Review Comprehensive Progress Reports (TCWG) Aug-Sep 2008
  • Joint Big Tent Meeting Nov 2008
  • Submit Phase 1 CPR to PCC and TSS (Project Sponsor) Sep-Nov 2008
  • Phase 2 Studies (Project Sponsor and TCWG) Nov 2008 and on

16

project overview
Project Overview

Major Project Elements

Part One: Construct a new McNary – John Day 500 kV transmission line.

Part Two: Construct a new 500 kV substation (“Station Z”) near Goldendale, WA, and a 500 kV line from Station Z to BPA’s Big Eddy substation near The Dalles, OR.

Anticipated rating (TTC) increase:

Depending on where new generation is integrated.

West of McNary: 2850MW to 4500MW

West of Slatt: 4100MW to 5500MW

West of John Day: 2440MW to 3450MW

Anticipated Operating Date:

Part One: Mid 2012

Part Two: Late 2013

Project Website:http://www.columbiagrid.org/WMRP-overview.cfm

19

objectives20
Objectives

The objectives of this project are:

To enable BPA to serve point-to-point transmission requests across multiple congested east-west transmission paths along the Washington – Oregon border. It would also enable BPA to interconnect additional wind generation in Eastern Washington and Eastern Oregon.

Increase system reliability to serve Portland area load.

20

update
Update

Regional Planning for the West of McNary Generation Integration Project was initiated through Columbia Grid on June 29, 2007. WECC approved the Regional Planning Compliance Report on February 8, 2008.

BPA plans to initiate the WECC Phase One Rating Process in August 2008.

Funds were approved to begin preliminary design and NEPA work.

Some Public Involvement effort has been initiated.

This project will be included in BPA’s Network Open Season (NOS) process.

21

project implementation schedule
Project Implementation Schedule

McNary-John Day 500-kV

Project will take approximately 3.5 years from start to energization

Environmental Process / Design – 0.5 years

Material Procurement / Construction – Additional 3 years

Big Eddy-Station Z 500-kV (includes Station Z)

Project will take approximately 5 years from start to energization

Environmental Process / Design – 2 years

Material Procurement / Construction – Additional 3 years

22

slide23

I-5 Corridor Reinforcement

Anthony Radcliff, BPA

23

project overview24
Project Overview

Major Project Elements:

Construct a new 500 kV Substation near Castle Rock, WA. Develop a 500 kV yard at the existing Troutdale Substation in Troutdale, OR. Construct a new 500 kV transmission line between these substations (approximately 70 miles).

Anticipated rating (TTC) increase:

South of Allston: approximately 1300 MW

Anticipated Operating Date:

Late 2014

Project Website:

http://www.columbiagrid.org/I5CRP-overview.cfm

Alternate Option:

Construct a new 500 kV Substation near Castle Rock, WA. Add a new 500 kV bay at the existing Pearl Substation. Construct a new 500 kV transmission line between these substations (approximately 100 miles).

24

objectives25
Objectives

The objectives of this project are:

To relieve congestion along the I-5 corridor transmission path south of Paul Substation and enable BPA to serve point-to-point transmission service requests which impact this path.

To enable BPA to interconnect additional new resources which are being planned along the I-5 Corridor.

Maintain reliable service to growing loads in Portland and vicinity.

Reduce dependence on existing RAS while maintaining transmission system reliability.

25

update26
Update

Regional Planning for the I-5 Corridor Reinforcement Project was initiated through Columbia Grid on June 29, 2007. WECC approved the Regional Planning Compliance Report on March 21, 2008.

BPA plans to initiate the WECC Phase One Rating Process in August 2008.

Funds were approved to begin preliminary design and NEPA work.

Preliminary design work to evaluate possible corridors for routing the line.

Some Public Involvement effort has been initiated.

This project will be included in BPA’s Network Open Season (NOS) process.

26

project implementation schedule27
Project Implementation Schedule

I-5 Corridor Reinforcement Project

Project will take approximately 6 years from start to energization

Environmental Process / Design – 3 years

Material Procurement / Construction – Additional 3 years

27

slide28

BPA Network Open Season Update

Anders Johnson, BPA

28

objectives29
Objectives

One of BPA’s most important strategic objectives is to ensure an adequate electric power infrastructure for the Pacific Northwest

Network Open Season (NOS) is a key way to meet planning, expansion, and reliability obligations to BPA’s Network (NT) and Point-to-Point (PTP) customers

This project is aimed at better managing BPA’s transmission queue and determining priorities for new transmission

BPA wants to encourage new resource development, including development of renewable resources

29

overview
Overview

BPA offered transmission service to all entities that requested service on BPA’s Network (excluding interties)

The customer committed to purchasing transmission by signing a precedent agreement (PTSA)

BPA’s commitment is contingent on providing service at embedded-cost rates and completing environmental work

BPA will perform a cluster study and commercial infrastructure analysis

More information is available:

http://www.bpa.gov/corporate/pubs/fact%5Fsheets/08fs/Factsheet-Network_Open_Season_March_2008.pdf

30

project overview33
Project Overview

Conceptual Major Project Elements

Eastern Wyoming - Two AC circuits (230kV/500kV) from Windstar, near Dave Johnston, to Jim Bridger

Western Wyoming – Double circuit 500 kV AC from Jim Bridger to Populus, southern Idaho

Southern Idaho – Two circuits of 500 kV AC from Populus to Hemingway, near Boise

Potential rating:

3000 MW

Operating Date:

2012/2014

Project Website:

http://www.idahopower.com/newsroom/projnews/Gateway/default.htm

33

objectives34
Objectives

Connect resource centers to load centers (hub and spoke concept)

Transmission to forecasted load growth areas

Transmission to forecasted resources areas

Relieve congested transmission paths

Meet transmission requirements of Integrated Resource Plans (IRP)

Satisfy OATT obligation for transmission service requests in excess of 1000 MW

Provide transmission for generation interconnection queue

34

background35
Background

Project developed through Northern Tier Transmission Group (NTTG) Fast Track Project Process

Milestones:

NTTG Fast Track Process 1/1/2007 – 6/1/2007

Initiated Regional Planning 7/5/2007

Completed Regional Planning 5/30/2008

Initiated Phase 1 Rating Process 2/19/2008

Complete Phase 1 Comprehensive Planning Report 8/31/2008

Initiated NEPA process for siting the lines

35

slide37

Idaho to Northwest

(Hemingway Boardman)

Dave Angell, Idaho Power

37

project overview38
Project Overview

Conceptual Major Project Elements

Single 500 kV AC circuit from Hemingway, Idaho to Boardman, Oregon

Potential ratings:

800 MW NW-ID

1500 MW ID-NW

Project Operating Date: 2012

Project Website:

http://www.idahopower.com/newsroom/projnews/hemingway_boardman/default.htm

38

objectives39
Objectives

Meet Idaho Power Network Transmission requirements for imports from the northwest

225 MW of northwest resource import – Integrated Resource Plan

Additional Network Customer load growth

Satisfy OATT obligation for transmission service requests in excess of 1000 MW

Connect resource centers to load centers (hub and spoke concept)

Transmission to forecasted load growth areas

Transmission to forecasted resources areas

Relieve congested transmission path

39

background40
Background

Project initiated through Idaho Power IRP

Milestones:

NTTG Fast Track Process 1/1/2007 – 6/1/2007

Initiated Regional Planning 7/5/2007

Completed Regional Planning 5/30/2008

Initiated Phase 1 Rating Process 2/19/2008

Complete Phase 1 Comprehensive Planning Report 8/31/2008

Initiated NEPA and OEFSC process for siting the line

40

slide42

Walla Walla to McNary/Boardman 230 kV Line Project

Hemingway to Captain Jack

500 kV Line Project

Tom Tjoelker - PacifiCorp

42

project overview walla walla to mcnary boardman
Project Overview; Walla Walla to McNary/Boardman

Conceptual Major Project Elements: Single 230 kV circuit from Walla Walla Washington to McNary/Boardman Oregon with a tie to Wallula Substation

Potential bidirectional rating: 400 MW

Proposed Project Operating Date: 2010

43

objectives44
Objectives

Meet transmission requirements of PacifiCorp Integrated Resource Plans (IRP)

Relieve congested transmission path

Improve Wallula Area Transmission Reliability

Satisfy OATI obligation for transmission service requests

Provide transmission for generation interconnection queue

44

progress and future activities
Progress and Future Activities

Initiated Regional Planning November 2007

Conducted regional planning meetings July 2008

Initiate Phase 1 Rating Process July 2008

Complete Regional Planning Report August 2008

Complete Phase 1 Comprehensive Planning Report September 2008

Information can be found on

www.pacificorp.com/energygateway

45

project overview hemingway to captain jack
Project Overview: Hemingway to Captain Jack

Conceptual Major Project Elements

Single 500 kV circuit from Hemingway Idaho to Capt. Jack Oregon

Potential east to west rating of 1500 MW, west to east rating to be determined

Proposed Project Operating Date: 2014

46

objectives47
Objectives

Meet transmission requirements of PacifiCorp Integrated Resource Plans (IRP) by increasing transmission capacity between PacifiCorp’s East and West Control Areas

Relieve congested transmission paths (Idaho to Northwest)

Connect resource centers to load centers (Wyoming Resources to Southern Oregon Loads)

47

progress and future activities48
Progress and Future Activities

Initiated Regional Planning November 2007

Conducted regional planning meetings July 2008

Initiate Phase 1 Rating Process July 2008

Complete Regional Planning Report August 2008

Complete Phase 1 Comprehensive Planning Report November 2008

Information can be found on

www.pacificorp.com/energygateway

48

project overview50
Project Overview

Major Project Elements

HVAC from Selkirk to Boardman area via Spokane area sub

HVDC or HVAC from Boardman area to Olallie/Maupin area to Tesla/Tracy

HVDC converter stations either in the Boardman area or Olallie area and Tesla/Tracy and potential third terminal in the Cottonwood area

Potential Bidirectional rating:

3000 MW North to South

2000 MW South to North

Project Operating Date: late 2015

Project Website:

Legend:

500 kV AC

AC or DC

HVDC

Selkirk Sub

Devil’s

Gap

Boardman Hub

Olallie/

Maupin area

Cottonwood

To SF Bay Area Substation

http://www.pge.com/canada/

50

objectives51
Objectives

Enhance access to significant incremental renewable resources in Canada and the Pacific Northwest.

Improve regional transmission reliability.

Provide market participants with beneficial opportunities to use the facilities.

Other considerations:

Minimize the footprint on the land by using existing and under utilized corridors where possible

Use an open stakeholder planning process to provide benefits to customers in all the regions the line traverses.

51

background52
Background

Project steering team: Avista Corp, BCTC, PacifiCorp, Portland General, PG&E

Milestones reached:

Initiated Regional Planning 12/16/2006.

Completed Regional Planning 11/1/2007.

Initiated Phase 1 Rating Process 10/31/2007.

Completed load and resources, technical feasibility and economic screening analysis. Reports posted on project website 11/1/2007.

Milestones planned for 2008

Develop Preliminary Plan of Service – August-September 2008.

Complete Phase 1 Studies – September 2008.

Begin Phase 2 Studies (following PCC/TSS acceptance of Phase 1 Studies) – expected by November-December 2008.

Continue to perform pre-permitting studies including environmental and design activities – throughout 2008-2009.

52

technical study activities
Technical Study Activities

Developed 2015 heavy summer case and 2017 heavy winter benchmark and project base cases and shared the data with TCWG members.

Developed two and three terminal HVDC models for power flow and dynamic studies and shared the information with TCWG members.

Developed wind generator model for power flow and dynamic studies.

Working with TCWG members reviewed project interconnection alternatives in Oregon:

Boardman HVDC alternative

Olallie HVDC alternative

Southern Oregon Hub alternative

Station K alternative – development in progress

Completed preliminary power flow studies and shared the information with TCWG members for review and comment.

September 2008 – Issue draft Phase 1 report including preliminary plan of service.

53

preliminary findings
Preliminary Findings

Preliminary findings suggest that desired rating of 3000 MW (north-south) is feasible for all segments of the project from Selkirk-BC to Northern California terminal at Collinsville

Among the interconnection alternatives evaluated in the technical studies, the Southern Oregon Hub alternative had more adverse impact on the existing PACI intertie requiring mitigation measures at added cost.

Based on preliminary technical studies, routing studies and considerations for regional benefits, the preliminary plan of service includes:

500 kV AC from Selkirk to the Olallie area via Devils Gap and the Boardman Hub

500 kV HVDC from the Olallie area termination to Collinsville area substation in Northern California

A potential third terminal in the Cottonwood area of Northern California

500 kV AC from Collinsville to Tesla/Tracy

54

project overview57
Project Overview

Major Project Elements:

500/230 kV interconnection at Devils Gap

230 kV Phase Shifting Transformers

2-230 kV interconnections to the Spokane Area 230 kV Grid

Potential Bidirectional rating:

500 MW

Project Operating Date: 2015

PG&E-CAN

500 kV Line

Westside

230-115 kV

Devil’s Gap

500-230-115 kV

Sunset

230-115 kV

Beacon

230-115 kV

Major Highways

Existing 230 kV

Proposed 230 kV

Existing 115 kV

57

objectives and resources
Objectives and Resources

The Avista interconnection to the PG&E Canada to Northern California 500 kV Project will provide up to 500 MW of access to the “Main Stem” Project from the Avista transmission system for renewable resources in the Avista service territory.

The interconnection will allow Avista access to other renewable resources in the Northwest as well as in Canada.

The project may also allow Avista to integrate some of its existing thermal resources to its loads over its own transmission, and may allow for additional imports of economy energy into the Avista system.

Potential resources are wind resources located in various locations on the Avista system, including but not limited to wind farms near Spokane, Othello, Lewiston, and Clarkston Washington, as well as Grangeville, Idaho. Avista presently has 12 interconnection requests pending.

58

background study work and future meetings
Background, Study Work, and Future Meetings:

Avista announced a Regional Planning Process that will run concurrently with a WECC Phase I Rating Process. The letter announcing these processes went to the WECC Committees and other stakeholders in the fourth quarter of 2007.

Preliminary studies that have been run on this project indicate that a 500/230 kV interconnection at Devils Gap with the associated 230 kV construction is feasible. The studies further indicate that a phase shift angle of plus 20 degrees to minus 40 degrees will be sufficient to satisfy the goal of a bi-directional rating of 500 MW. There may be a requirement to trip the interconnection and some generation for some outages. Studies continue.

Avista hosted an initial meeting in Spokane on 2-29-08, and will be hosting a second meeting in the near future to review the first draft of our study report.

59

slide61

Southern Crossing

Philip Augustin, PGE

project overview62
Project Overview

Conceptual Major Project Elements

500 kV transmission lines

500/230 kV substation

Potential Bidirectional rating:

1500 MW

1500 MW

Project Operating Date:

2013

2013/2015 if staged

Project Website: PGE OASIS

http://www.oatioasis.com/pge/index.html

http://www.nwpp.org/tcwg/

62

objectives63
Objectives

Meet the state mandated Renewable Portfolio Standard requirements for 2015

Deliver future wind and other resources to load

Opportunity for integration of existing resources

PGEs 2002 and 2007 Integrated Resource Plans (IRP) - Identified significant demand and energy requirement, and the critical nature of transmission

OPUC directed PGE to work with region to develop transmission capacity over the Cascades to access additional resources

Access to a new Transmission Hub

Balanced scheduling of diverse wind resources at Transmission Hub

Reliability Improvement to Willamette Valley customers

Provide some congestion relief to current transmission system

63

status
Status

Project is currently being studied by PGET under the OATT process. Feasibility Study completed, System Impact Study in progress.

Exchanged technical results with adjacent utilities

Formed Regional Planning Review Group

Report on Projects conformance to WECC Regional Planning Guidelines delivered to Review Group for review and comment

Established Project planning assumptions, and began preliminary discussions with state permitting authorities

Initiated ROW investigations

Initiated detailed economic evaluation financial model

Consultant developed preliminary EPC estimate

64

project implementation schedule65
Project Implementation Schedule

Duration

Task Name

2007

2008

2009

2010

2011

2012

2013

2014

2015

Start

Finish

Q1

Q2

Q3

Q4

Q1

Q2

Q3

Q4

Q1

Q2

Q3

Q4

Q1

Q2

Q3

Q4

Q1

Q2

Q3

Q4

Q1

Q2

Q3

Q4

Q1

Q2

Q3

Q4

Q1

Q2

Q3

Q4

Q1

Q2

Q3

Q4

OATT Interconnection Process

Q3

2007

Q4

2008

  • Regulatory & Stakeholder Coordination

18 months

  • Corridor Options
  • High Level cost and schedule
  • Feasibility and System Impact Studies
  • WECC Phase 1 & Regional Review
  • • Comprehensive Progress Report (CPR)
  • -Identify the non-simultaneous and known
  • interactions of the project
  • • CPR reviewed by PCC & TSS membership
  • • Informal reports are presented at TSS
  • meetings
  • Letter to TSS and PCC requesting
  • Phase 2 Status

Q3

2008

Q1

2008

8 months

  • WECC Phase 2
  • • Identify the simultaneous transfer capability for project
  • • Address mitigations for any adverse impacts
  • to existing system
  • EFSC permitting process
  • Land Acquisition

Q4

2008

Q4

2010

30 months

Q2

2013

or

  • WECC Phase 3
  • Definitive commercial agreements
  • Engineering
  • Procurement
  • Construction
  • Release To Operation

Q1

2009

2013

through

Q2 2015

48 to 72

months

65

alberta to pacific northwest

Alberta to Pacific Northwest

Bill Hosie, TransCanada

66

northernlights overview

Edmonton/Heartland

AB

BC

SK

Calgary

Spokane

WA

Buckley

MT

ID

NorthernLights

AC or DC Connectors

Converter

OR

NorthernLights Overview
  • HVDC transmission line from Edmonton/Heartland area to Buckley, Oregon
  • 3000 MW design capacity
  • 900 miles
  • $2 billion (‘08$), 2000 MW initial capacity
  • Merchant intertie line
  • 6 years to permit and build
  • Operational in 2015

Project web site: http://www.transcanada.com/company/projects_initiatives.html

67

objectives68
Objectives
  • Create a bi-directional path between Alberta and the Pacific Northwest
  • Enhance regional resource reliability by providing bi-directional market access (AESO’s 2007 Market Roadmap)
  • Provide opportunities for markets to access large-scale renewable energy resources – wind, hydro IGCC with sequestration, nuclear
  • Enhance regional wind capacity factors though geographic diversity
  • Improve regional transmission reliability.
  • Provide market participants with beneficial opportunities to use the facilities.

68

background69
Background
  • NTAC’s Canada to NW to California study demonstrated the cost effectiveness of HVDC to interconnect the PNW with California
  • Milestones reached:
    • Initiated Regional Planning July 11, 2006
    • Regional Planning Meeting in Portland September 22, 2006
    • Completed Regional Planning January 2008
    • Initiated Phase 1 Rating Process December 10, 2007
    • Alberta Transmission Regulations amended – multiple Alberta terminals allowed for merchant interties December 19, 2007
    • Alberta Government signifies support of significant intertie capacity increase Fall 2007

69

project schedule

2008

2009

2010

2011

2012

2013

2014

2015

Initial Feasibility

(complete 2006)

2012: Fully Permitted and Committed Line

Market Verification & Commercial Support

Detailed Siting andPermitting

Detailed TechnicalStudies / Path Rating

Finalize Land Acquisitionand Construct

Commence Operations

Project Schedule

Open Season

70

progress
Progress
  • Southern HVDC terminal confirmed at Buckley
  • BPA Interconnection Application submitted May, 2008
  • Coordinated PNW Path Rating and Interconnection Study scoped
  • Integrated Alberta/WECC dynamic model complete and tested
  • Completed North – South Alberta corridor assessment
  • 26 AESO open houses for Alberta North – South capacity

71

recap of next steps and timelines
Recap of Next Steps and Timelines

Darrell Gerrard - PacifiCorp

73

next steps and timelines for tcwg
Next Steps and Timelines for TCWG
  • Joint Big Tent Meeting Jul 18, 2008
  • Technical Studies on Individual Projects (Project Sponsor) May-Aug 2008
  • Draft Comprehensive Progress Reports (Project Sponsor) Aug-Sep 2008
  • Review Comprehensive Progress Reports (TCWG) Aug-Sep 2008
  • Joint Big Tent Meeting Nov 2008
  • Submit Phase 1 CPR to PCC and TSS (Project Sponsor) Sep-Nov 2008
  • Phase 2 Studies (Project Sponsor and TCWG) Nov 2008 and on

74
