Minor Planet Astrometry With CCD Images

1. Minor Planet Astrometry With CCD Images Glenn A. Snyder, Project CLEA CLEA Summer Workshop June 20, 2010

2. Outline I. Introduction II. Mathematics of Astrometry III. Methodology IV. Reference Catalogs V. Minor Planet Orbits

3. I. Introduction

4. Astrometry: • “Positional Astronomy” • “…the branch of astronomy concerned with the precise measurement of positions of objects on the celestial sphere.” • The oldest branch of astronomy. • Two kinds - absolute and relative (“differential”).

5. Fundamental (Absolute) Astrometry • Measure positions over entire sky (including Sun). • Determination of Fundamental (Inertial) Reference frame. • Determination of Astronomical Constants. • Timekeeping. • Traditionally done with Meridian Circle. • Very few sites now doing this.

6. “Differential” Astrometry • Positions are measured relative to reference stars in the same field whose positions are known. • Applications include parallax, proper motion, astrometric binaries, positions of comets and minor planets. • Effects of precession, nutation, aberration etc. nearly constant across field and can (usually) be ignored.

7. Equipment (Historically) • Long-focus refractor, or “Astrographic Camera” • Large, fragile photographic plates. • Bulky, expensive blink comparators and measuring engines. • Tedious error-prone measuring process and reductions via calculator, math tables, etc. • Only a few dedicated astronomers & sites.

8. Discovery of Pluto The Pluto Discovery Telescope • Clyde Tombaugh Blinking Plates at Lowell Observatory, 1930

9. Equipment (Today) • CCD chip and personal computer • Taking & storing images vastly simplified. • Limiting magnitude improvements allow use of smaller telescopes. • Blinking and measuring via computer. • Reductions are lighting fast and accurate. • Meaningful astrometry now possible from small institutions, students, amateurs.

10. Catalog Improvements • “Paper” catalogs difficult to work with, bright stars only, often no charts. • Proliferation of digital catalogs simplifies selection of standards. • Great improvement in limiting magnitude. • Small size of CCD fields places heavier requirements on catalogs.

11. II. Mathematics of Astrometry

12. Standard Coordinates

14. Standard Coordinates II

15. Standard Coordinates III

16. Standard Coordinates IV • We can therefore compute standard coordinates for objects whose RA & Dec we know (reference stars), and... • Compute the RA & Dec of an object if we know its standard coordinates. But... • How do we go from image positions measured in pixels to standard coordinates?

17. Instrumental Errors • Displacement of Origin: Yields constant differences between measured & true coordinates. • Error of Orientation: The x and y axes of the measurements will be rotated by some angle from true N-S, E-W. • Non-Perpendicularity of Axes: The axes of measurement will not be strictly orthogonal. • Scale Errors: The standard coordinates are expressed in terms of the focal length, which will not be constant, and may differ in x and y.

18. Plate Solution

19. Plate Solution II • The goal of the plate solution is to determine the plate constants. We do this by measuring the positions of the reference stars, whose standard coordinates we can compute. • Since we must determine 6 constants, we must measure at least 3 reference stars (each star yields a pair (x,y) of measurements).

20. Plate Solution III • In practice, more than the minimum # of reference stars should be used. The plate constants are then determined via least squares. • In addition to strengthening the solution, this gives residual information that can be used to eliminate bad reference stars. • More than 20-25 reference stars is probably overkill (if not impossible).

21. Instrumental Errors II • Plate Tilt: Errors due to non-perpendicularity of the image surface to the optical axis can be shown to be quadratic in nature, and are not accounted for by the 6-constant solution. • Others: Other potential non-linear errors include sphericity of the focal surface and coma.

22. Plate Solution IV

23. Centering Errors • Errors due to miss-centering on the star images should average out in the solution and be reflected in the residuals. But… • The target is frequently much fainter than the references and thus be more likely to have a greater than average centering error. • Automated centering should minimize centering errors for all but the most experienced measurers.

24. III. Methodology

25. General Technique • Blink images, identify object. • Select reference stars, get solution. • “Improve” the solution. • Repeat for each image. • Assemble observations and report to the Minor Planet Center (MPC). • Entire sequence supported by CLEA Toolkit software.

26. Blinking • Select alignment stars that are well exposed, well separated diagonally. • Adjust image contrast for visibility. • Blink area can be selected for magnification.

27. Selecting Reference Stars • Should cover a good range in both dimensions on the image. • Ideally should surround the unknown. • One or two close to the unknown in brightness is useful for error assessment. • Sometimes have to live with what you get.

28. CLEA Astrometry Toolkit • Software Demo

29. Getting Started • Visit MPC Website via link in Toolkit.http://cfa-www.harvard.edu/iau/mpc.html • Follow links“How Do I Report Material to the MPC?”  “Observation Format” • Read (as a minimum):“Guide to Minor Body Astrometry”“Format for Optical Astrometric Observations of Comets, Minor Planets and Natural Satellites”“Packed Provisional Designations”

30. Reporting to the MPC • A specific format is required - supported by CLEA Toolkit software. • First time? - need site ID. • Save report, insert in e-mail message to MPC. • Must be in-line, MPC will not open attachments. • Preserve text format, fixed font, no wrap. (May have to force e-mail software to do this.) • “Junk” rating in acknowledgement!

31. A New Observation Format • Current format dates from 1940s, designed for 80 column punched cards. • New format described in “The New MPC Observation Format” • 132-column records, some multiple. • Larger ID fields, greater precision, error estimates, etc. • Records split after column 66 to avoid “butchering” by e-mail software.

32. A New Observation Format - II • CLEA Toolkit now includes the new format for output as an option. BUT… • Has not been verified. MPC has yet to provide examples to check against or verification of submitted samples. • June 1, 2006 was set as conversion date. (Now cancelled. “…details to be provided later.”) • Not clear when MPC will begin accepting observations in new format - both formats will be accepted for “a period of time”.

33. IV. Reference Catalogs

34. Reference Star Errors • Random: Random errors in the catalog positions are likely to be small, and are averaged out by the least squares method. • Systematic: Catalog positions can have systematic errors that vary from the center to the edge of the original plates, and from field to field. Since these may be as large as 3”, they can clearly affect the final accuracy.

35. Reference Star Errors II • Proper Motions: Until recently, the most commonly used catalogs were made from plates taken decades ago, and did not include proper motions. This frequently resulted in large reference star residuals. • New Catalogs now available have greatly reduced systematic errors, & include proper motion.

36. “Obsolete” Catalogs • The HST Guide Star Catalog (GSC) • The USNO Precision Measuring Machine Project (PMM) Catalogs A1.0, A2.0, SA1.0, SA2.0 • Distributed on CD-ROM, none currently available from original source. • Biggest problem is age of plate material combined with lack of proper motion data. • MPC no longer favors use of these catalogs for submitted measurements.

37. HST Guide Star Catalog • Number of Stars: ~19,000,000 • Limiting Magnitude: V=~16, but many omissions • Source: North - Palomar Schmidt plates (1982) South - UK Schmidt plates (1975,82) • Availability of the GSC on 2 CD-ROMs made PC-based CCD astrometry possible.

38. USNO PMM Catalogs • Large, fast, highly precise measuring engine for photographic plates. • Deep, dense stellar catalogs by digitization of major photographic surveys. • Versions: A1.0, A2.0, B1.0 • Subset versions: SA1.0, SA2.0 • http://ftp.nofs.navy.mil/projects/pmm

39. USNO A2.0 Catalog • Number of Stars: 526,230,881 • Limiting Magnitude: B~21, R~20(detection in both colors required for inclusion) • Source: North - Palomar Sky Survey I (1950s) South - UK SCR-J, ESO-R Surveys (1980s) • Media: 11(!) CD-ROMs (Last PMM catalog available on CD-ROM.) • On Intl. Earth Rotation Service (ICRS) systemEarlier A1.0 on GSC system

40. USNO A2.0 Catalog II • Availability: CD-ROMs no longer available from USNO. Catalog is accessible on-line via NVO-Compliant Web Services. • Advantages are completeness & limiting magnitude. • Biggest drawback is age of plate material (no proper motions). • MPC no longer favors use of this catalog, or its predecessors/subsets (A1.0, SA1.0, SA2.0)

41. USNO SA2.0 Catalog • Spatially sub-sampled version of A2.0. • Uniform “grid” of stars in intermediate magnitude range. • Number of Stars: 54,787,624 • Magnitude Range: ~14.0 <= B <= 19.0 • Media: 1 CD-ROM (now download only). • Useful primarily as adjunct to GSC (more stars, fainter magnitude).

42. New Catalogs • USNO CCD Astrographic Catalog (UCAC) • USNO B1.0* • (NOMAD)* • *Available via NVO-Compliant Web Services. Toolkit provides real time on-line access.

43. USNO CCD Astrographic Catalog (UCAC) • Homogeneous observations - same telescope & detector for entire sky (starting in Southern Hemisphere). • Magnitude range 8-16 (passband between V & R). • Includes proper motions(!) • 20 mas accuracy (10<m<14), 70 mas at m=16. • “Photometry is poor, with errors on the order of 0.1 to 0.3 magnitude in a single, non-standard color.”

44. UCAC Catalog II • UCAC1 - partial coverage of Southern Sky • UCAC2 - declinations -90 to +40..+50. 3 CDs – no longer available from USNO. • Bright Star Supplement (BSS) also available. 430,000 stars from Hipparchos & Tycho-2 • UCAC3 - Full sky coverage. Released Aug. 2009 on 2-sided DVD. B, R, I photometry added from SuperCosmos project, J, H, K from 2MASS. • http://www.usno.navy.mil/USNO/astrometry/optical-IR-prod/ucac

45. USNO B1.0 • 1,000,000,000 Entries • Positions, magnitudes(B,R,I) and proper motions • 80 GBytes • Available by download only, not circulated on CD-ROM/DVD. • Toolkit accesses via Web Service.

46. Catalog Summary • CLEA Format GSC plus USNO SA2.0 Convenient: 1 on HD + 1 CD-ROM Useful for charts when no Web access available. • USNO B1.0 Best choice for all purposes if Web access available. Only choice for faint magnitudes. • UCAC3 Accuracy is excellent, probably the best.Download from CDS, but not directly as Web service.Limitation is magnitude limit (~16.5).

47. NOMADNaval Observatory Merged Astrometric Dataset • 100 GBytes, 1.1 billion stars. • Astrometry with Proper Motions plus Photometry (B,V,R,J,H,K) • Source Catalogs: Hipparcos, Tycho-2, UCAC2, Yellow-Blue 6, USNO-B1 plus 2MASS. • Toolkit (& VIREO) access via Web Service. • Not a “compiled” catalog. • http://www.nofs.navy.mil/nomad.html

48. Photometry • Catalog magnitudes (from photographic plates) are not very useful as standards for accurate photometry. • Accuracy of photographic photometry at best is 0.1 magnitude (this isn’t best). • In some cases passbands vary from plate to plate. • In most cases calibrations not good. These are not photometric catalogs. • Use R magnitudes with unfiltered CCD.

49. V. Minor Planet Orbits

50. “Keplerian” Orbital Elements • 6 elements total plus associated date (epoch) • 2 elements define size and shape of ellipse • 3 elements define position of ellipse in space • 1 element defines position of body in ellipse
