Presentation Transcript
slide2

Before modification -1) Manually removes the unbaked sand at the center of core for plug.2) Extra man power required for sand removing (2 no. of workers,125 no. of core produced.) 3) Inside core baking not properly.

core box core cavity loose piece inserted
Core Box core cavity Loose Piece Inserted

Before Work.

After Work.

New loose piece inserted.

after modification

After Modification.

Manually removes the unbaked sand totally avoided

Extra worker totally avoided.

Totally 02 worker Saved

Core required Quantity 500 nos produced & 8 workers Saved.

Core weight reduced by 700 gm.Old Core Weight 2.720 Kg Modified Core Weight 2.0Kg

wabco crank case 911 905 0106
Wabco Crank Case 911 905 0106

After Implementation

Before Implementation

slide6
Before Work

After Work.

wabco crank case 911 905 01061
Wabco Crank Case 911 905 0106

After Implementation

Before Implementation
