slide1

Company profile

All Flex Inc. - Flexible Printed Circuits

© Quicktronics PCB & Electronic Service GmbH 2009

slide2

Key Facts

  • -
  • -
  • -
  • -
  • -
  • -
  • -
  • All Flex was incorporated in 1991 focusing on quick-turn and low to medium volume single and double sided flexible circuitry
  • Consistent sales growth trend over the past 18 years
  • Developed Multilayer Capabilities
  • Added Maxi Flex™ Capabilities
  • Expanded Product Offering to Include Surface Mount and thru-hole Component Assembly
  • Expanded product line offering to include flexible heaters
  • Strategy is to continue to grow the company in revenue and profit by excelling within the existing product niche.

© Quicktronics PCB & Electronic Service GmbH 2009

slide3

Key aims

All Flex provides quick-turn prototype, short run and serial production of flexible printed circuits, heater circuits, & assemblies.

© Quicktronics PCB & Electronic Service GmbH 2009

slide4

Shipments

© Quicktronics PCB & Electronic Service GmbH 2009

slide5

Facilityinformation

  • 15,000 Square Foot “Front End” Fabrication
    • Expansions completed in 1995, 1998, 2000 and 2002
    • Additional 15,000 square foot facility for
    • “Back End” processes and circuit assembly
  • All Flex practices “Green” policies. Products able to meet RoHS.
  • ∙Key equipment duplicated for improved
  • service for quick-turn and production work.

© Quicktronics PCB & Electronic Service GmbH 2009

slide6

Standard ProductCapability

  • Standard Circuit Constructions
    • - Single and Double Sided Flex circuits
        • (Resistive metal constructions for single and double sided flexible heaters)
    • - Sculptured circuits with unsupported leads
    • - Up to 8 Layer Multilayer
    • - Copper, Silver, and conductive film Shielding
  • Standard Circuit Materials
    • - Polyimide and Polyester film substrates
    • - Polyimide and Polyester film coverlays
    • - Photoimagablesoldermask
    • - Adhesiveless and adhesive based constructions
    • - Surface finishes of OSP, tin, tin/lead, ENIG, electroplated hard and soft gold, and immersion silver
    • - Copper thicknesses 1/2 to 7 ounces

© Quicktronics PCB & Electronic Service GmbH 2009

slide7

Quality Fabrication and Verification

Capital equipment investment for quick-turn and serial production work

Gerbig Class 10,000 clean room

Orbotech Automated

Optical Inspection system

© Quicktronics PCB & Electronic Service GmbH 2009

slide8

Quick Response Equipment

  • Numerical control drill and rout for plated thru vias and tooling holes
  • Rule dies and hard tools for circuit cutline
  • Software driven tooling generated from CAD files
  • Short cycle time and simple modification

© Quicktronics PCB & Electronic Service GmbH 2009

slide9

Current Key Capabilities

All Flex operates a full complement of imaging, etching, plating and surface finishing wet process equipment. Statistical control techniques are used extensively for in-process monitoring.

© Quicktronics PCB & Electronic Service GmbH 2009

slide10

Maxi Flex™

  • Trademark name for All Flex “extended length”

flexible circuits

  • Custom imaging equipment allows fabrication of

continuous circuitry

  • Parts in excess of 40 feet have been produced

© Quicktronics PCB & Electronic Service GmbH 2009

slide11

Component Assembly

© Quicktronics PCB & Electronic Service GmbH 2009

slide12

Mixed Form Factor Assembly

  • Surface mount

components up to 0204

  • Precise vision system

allows placement

accuracy to .001”

  • Fine pitch capability to

.5mm pitch

  • Leaded devices
  • Tactile domes
  • Staked terminals
  • Unlimited component

configurations

  • RoHS Compliant assembly
  • Virtually all SMT

components including

discretes, SOICs, PLCCs,

QPPs, & BGA’s

  • Auto fiducial correction

© Quicktronics PCB & Electronic Service GmbH 2009

slide13

- Assembly of components to meet J-STD001-C

- Design and Reverse Engineering

- Electrical Testing

- Rigid carrier panels for automated assembly

- Rigid, polyimide, and aluminum stiffeners

- Nomenclature screening

- Pressure Sensitive Adhesives

- Aluminum Heat Sinks

- Conformal Coating

- Potting

- Ionic Testing

- Special Packaging

Value Added Capabilities

© Quicktronics PCB & Electronic Service GmbH 2009

slide14

Sales & Marketing

- Today we have over 400 active customers.

- Our largest customer is <10% of our sales.

- Average 100 new customers per year.

- All Flex has been marketing on-line since 1998.

- We have enjoyed significant sales growth…~ 30%

average over the past 5 years.

© Quicktronics PCB & Electronic Service GmbH 2009

slide15

Delivery

Standard Lead Times

  • Single and Double Sided Circuits @ 2-3 weeks
  • Multilayer Circuits at 3-4 weeks
  • Component Assembly +1 week
  • Flexible Heater Circuits 2 – 3 weeks
  • Expedited deliveries possible

© Quicktronics PCB & Electronic Service GmbH 2009

slide16

Quality Certifications and Support Systems

All Flex Today...

  • - ISO 9001:2000 Certified
  • - MIL P-50884 Qualified
  • - ITAR & JCP Registered Corporation
  • - RoHS Compliant (lead free)
  • - UL Certified
  • - Build to Requirements of IPC 6013
  • - Application engineering support for customer’s
  • new product development
  • - Manufacturing focus on low to medium volume
  • production with short cycle times

© Quicktronics PCB & Electronic Service GmbH 2009

slide17

That´s all… smile!
