Presentation Transcript
slide2

Topics

  • Rigid plastic container overview
      • Processing
      • Market overview
  • Recycling issues
  • Plastic container resin and molding technology
      • Lightweighting
      • Industry trends
  • California regulations
slide3

Packaging plastic options

  • Blow molding
    • Bottle formed with small opening
  • Vacuum thermoforming
    • Sheet of plastic melted on a steel mold
  • Injection molding
    • Melt resin pellets
    • Forced into a steel mold
    • Cooled to form part
slide4

North America -- Total Plastics Consumption

Non-Bottle Rigid Containers Account for only 3% of the total plastics stream

slide5

Plastics Collection Programs

Source: RW Beck

1Actual is higher due to non-responding communities.

slide7

Recycling Issues

  • Variety of resins used in rigid packaging
  • Melt flow index within resin families

High Density Polyethylene

PackageMelt FlowFlows Like

Milk jugs 1 melt Honey

1 gallon industrial 20 melt Syrup

Butter tub 50 melt Salad dressing

Lids 100 melt Water

slide8

Non-Bottle Rigid Containers - Barriers to Recycling

  • Relatively small size of waste stream
  • Many polymer types - different polymer performance attributes (PP; HDPE; LLDPE; PS; PET; PVC)
    • only PP, HDPE and LLDPE recyclable as co-mingled - all polyolefins
  • Sorting technology not yet developed
  • Even within single polymer streams - many polymer types --- (eg. different melt flow resins)
slide9

Injection molders use highly-engineered resins to attain thinwalling (lightweighting)

  • High melt index resins > 40-100 melts
  • PCR 18 to 1 melt index
  • Must thicken part to use PCR
    • Increased energy cost
    • More plastic in landfill
    • Consumers will have increased costs
slide10

2000 container vs. 1985 container

  • 46% less plastic
  • 200 million containers used annually in U.S.
  • 32 million lbs. of resin
  • 15 million lbs of resin saved
  • 1,500 truckloads of plastic not going to the waste stream annually
slide11

Polypropylene Dairy ContainersCase Study Example

Wax Paper (1970’s)

Polypropylene (PP) (Mid-1980’s)

PP - 2nd generation technology 1990’s

33% Reduction

PP - 3rd generation technology 2000’s (specialized resins)

slide12

Technology Trends - Rigid Plastic Containers

  • Resin and polymer processing technology advancing
    • Lightweight
    • Increase strength of containers
  • Higher production rates and lower unit energy consumption
  • More customized and tailored resins --- to minimize resin consumption, increase production rates and reduce costs

Major Environmental Benefits

Resource Conservation - lighter weight packaging/less raw materials usage

Less Energy/Emissions in fabrication & shipping

slide13

Key Environmental Concerns

Heavier Gauge Containers

Recycle-Content Resin Trend

Resin Technology Trend

Increased Light-weighting

slide14

Compliance with current SB135

  • Lightweight containers
  • Limited PCR usage
slide15

California-Proposed Regulations/Issues

  • Recycle-Content Resins
  • Source Reduction
  • No FDA Food Grade resin supply available in higher technology resins
  • Traceability of PCR resins
  • Lower melt flow resins will tend to drive processors towards heavier containers
  • Cost reduction is already providing adequate incentives
  • Would penalize companies who source-reduced early -- lower base year container weight
slide17

Find and grow markets that can produce products using PCR

  • Use R&D departments of resin companies, mold makers and machine manufacturers to further develop engineered resins to allow lighter part weights
  • Today the plastic packaging industry gives the consumers their preferred packaging, a reusable, recyclable, resealable, lightweight container. The future can be even brighter with the use of technology tofurther reduce plastic waste.
