  1. WORLDWIDE INTEROPERABILITY DEMONSTRATION Carlo Cavazzoni Alessandro D’Alessandro

  2. Summary • OIF overview • OIF Worldwide interoperability demo 2005 • Introduction • Some technical details • OIF & ITU collaboration • Telecom Italia Laboratory in Torino • Conclusions

  3. Summary • OIF overview • OIF Worldwide interoperability demo 2005 • Introduction • Some technical details • OIF & ITU collaboration • Telecom Italia Laboratory in Torino • Conclusions

  4. About OIF • Launched in April of 1998 with an objective to foster development of low-cost and scaleable internet using optical technologies • The only industry group bringing together professionals from the data and optical worlds • Open forum: 130+ member companies • International • Carriers • Component and systems vendors • Testing and software companies • Our MissionTo foster the development and deployment of interoperable products and services for data switching and routing using optical networking technologies

  5. Architecture and Signaling Carrier Interoperability OAM&P Physical Layer User Group Physical and Link Layer OIF Organization and main focus

  6. Architecture and Signaling Carrier Interoperability OAM&P Physical Layer User Group Physical and Link Layer OIF Organization and main focus

  7. OIF Outputs • Implementation agreements, using • Carrier & user group’s requirements • Existing standards and specifications when available • Newly developed solutions when necessary • Interoperability demonstrations, to validate industry acceptance and maturity of implementation agreements • Testing methods, to evaluate interoperability that will help in the accelerated development of interoperable products and networks • Inputs to other standardization bodies and fora

  8. Summary • OIF overview • OIF Worldwide interoperability demo 2005 • Introduction • Some technical details • OIF & ITU collaboration • Telecom Italia Laboratory in Torino • Conclusions

  9. A brief history • Traditional networks limit the ability to offer new data-centric services in a cost and resource efficient manner • Time and labor-intensive inventory and provisioning processes • Limited service levels, protection schemes, service differentiation • OIF UNI/E-NNI enables the efficient deployment of these new services • Rapid, flexible provisioning • Multi-vendor interoperability • Keys to ongoing success • Joint carrier / vendor participation • Liaisons between standards organizations UNI 2.0 E-NNI E-LINE services E-LAN services Carrier lab testing 2nd Worldwide demo UNI 1.0 R2 E-NNI E-LINE services Carrier Lab testing 1st Worldwide demo UNI 1.0 Interim E-NNI demo UNI 1.0 demo OIF Founded Interim UNI demo 2001 2002 2003 2004 2005 1998

  10. Carrier Participants

  11. Vendor Participants

  12. Technical Highlights • The network consists of over 70 nodes from 13 vendors in the 7 carrier labs across 3 continents • Equipment includes Ethernet switches, routers, MSPPs, SONET/SDH cross-connects, OADMs, ROADMs • Ethernet Services demonstrated: • Ethernet Private Line service • Enabled by OIF optical control plane • Virtual Ethernet services (Virtual Private Line, Virtual Private LAN, Internet Access/Virtual Trunking) • Enabled by VLAN tags

  13. Global Topology

  14. Making it Happen • Demonstration Timeline • Spec completion • Formal commitments • Intra-lab testing begins • Global testing begins • Base spec defined • Initial event planning • SuperComm demo 2005 June* 4Q04 Jan Feb March April May • Test content defined • Verbal commitments • Equipment installed • Signaling network in place • Regional testing begins • Global testing completed * After demonstration, technical results and potential enhancements to specs are provided by OIF to other organizations (e.g. ITU-T, IETF, MEF)

  15. Architecture Model Ethernet Client Carrier A Domain Ethernet Client Carrier B Domain Carrier C Domain OIF E-NNI OIF E-NNI OIF UNI OIF UNI NE NE NE NE NE NE UNI-C UNI-N Carrier C Domain • User-Network Interface (UNI): signaling interface for clients to request services from optical network • External Network-Network Interface (E-NNI): signaling and routing interface providing call/connection control and topology • Domain edges provide interworking between vendor-specific Internal NNI (I-NNI) and OIF UNI-N/E-NNI protocols Vendor 2 Domain Vendor 1 Domain I-NNI OIF E-NNI NE NE NE NE • Domains can be advertised as • Multiple exposed border nodes with virtual intra-domain links (vendor 1) or • Single abstract node (vendor 2)

  16. Optical Control Plane - Benefits Carrier A Domain Carrier B Domain Carrier C Domain Client Client OIF E-NNI OIF E-NNI OIF UNI OIF UNI NE NE NE NE NE NE Routing Discovery Signaling • Technology Benefits Service activation Multi-layer resource control Resiliency mechanisms • Topology discovery • Path Selection Resource discovery Inventory management Control channel management

  17. Control Plane: major innovations demonstrated Ethernet Client Carrier A Domain Ethernet Client Carrier B Domain Carrier C Domain OIF E-NNI OIF E-NNI OIF UNI OIF UNI NE NE NE NE NE NE Ethernet SONET/SDH Ethernet UNI-N UNI-N UNI-C UNI-C Ethernet Layer Call/Connection Flow SONET/SDH Layer Call/Connection Flow • OIF UNI 2.0 support for Ethernet clients • OIF UNI 2.0 call control based on ASON • UNI-N devices integrate multi-layer functions of the control plane

  18. GFP-F GFP-F VCAT VCAT LCAS LCAS Data Plane: major innovations demonstrated Ethernet Client Carrier A Domain Ethernet Client Carrier B Domain Carrier C Domain OIF E-NNI OIF E-NNI OIF UNI OIF UNI NE NE NE NE NE NE Ethernet SONET/SDH Ethernet GbE GbE Virtual Concatenation Group (21 STS-1 or 7 VC-4) . . . . . . . . . • Ethernet over SONET/SDH adaptation using GFP/VCAT/LCAS • Ethernet Private Line Service (E-Line Service Type) triggered by UNI connection requests • Services enabled by data plane VLAN tags • Ethernet Virtual Private Line (E-Line Service Type) • Virtual Private LAN (E-LAN Service Type) • Internet Access/Virtual Trunking (E-Line service type with multiplexed access)

  19. Major Accomplishments • Multi-layer call/connection control of UNI-N devices • Orchestrates actions between client and server layers • Controls Ethernet adaptation using GFP-F/VCAT/LCAS • Creation of end-end calls and connections across: • Multiple data plane layers • Multiple vendors’ equipment • Multiple carrier labs • The major features (1) Ethernet over SONET/SDH adaptation and (2) distributed optical control planes have each been demonstrated before • However, this is the first event bringing both together in an integrated fashion on a global scale

  20. Interoperability: Carrier Benefits • Provision end-to-end dynamic connections for flexible data services over multiple, control plane enabled SDH/SONET domains • Deploy at faster pace innovative network technologies • Select cost effective and leading edge network elements, platforms and multi-vendor solutions • Reduce operations overheads and simplify provisioning of new services

  21. Promotes the global development of optical internetworking products Recognized by ITU-T Study Group 15 is the focal point for studies on optical and other transport networks, systems and equipment. OIF and ITU-T Collaboration • Ethernet architecture and services Recommendations • ASON Recommendations for Optical Signalling and Routing • Transport Recommendations for GFP, LCAS, VCat • Carrier Requirements • Interoperability Experience • Protocol Specifications in OIF UNI and ENNI • Adoption of ITU-T Recs.

  22. Evolution from Standards to Deployment Deployment Field Trials Carrier Sites Interoperability Tests/Demonstrations OIF Standards Specifications OIF ITU-T IETF Feedback

  23. Verizon AT&T NTT CT DT FT TI SuperComm 2005 booth A distributed real time demo USA Europe Asia

  24. OIF interoperability labs Lannion, France Waltham, MA-USA Beijing, China Berlin, Germany Middletown, NJ-USA Musashino, Japan Torino, Italy

  25. Interfaces STM-16 / POS-16 STM-1 / POS-1 Gigabit Ethernet Transponder WDM An example: Telecom Italia Lab Test bed Ciena CT Sycamore FT Fujitsu VZ Cisco1 Huawei1 Marconi2 Cisco2 Alcatel DT Marconi1 Marconi3 Avici2 Avici1 Lambda1 Lambda2 Lambda3

  26. Marconi2 Marconi1 Marconi3 An example: Telecom Italia Lab Test bed CienaCT Sycamore FT FujitsuVZ Cisco1 Huawei1 Marconi2 Cisco2 AlcatelDT Marconi1 Marconi3 Avici2 Avici1 Lambda1 Lambda2 Lambda3

  27. Lambda1 Lambda2 Lambda3 An example: Telecom Italia Lab Test bed CienaCT Sycamore FT FujitsuVZ Cisco1 Huawei1 Marconi2 Cisco2 AlcatelDT Marconi1 Marconi3 Avici2 Avici1 Lambda1 Lambda2 Lambda3

  28. Cisco1 Huawei1 Cisco2 Avici2 Avici1 An example: Telecom Italia Lab Test bed CienaCT Sycamore FT FujitsuVZ Cisco1 Huawei1 Marconi2 Cisco2 AlcatelDT Marconi1 Marconi3 Avici2 Avici1 Lambda1 Lambda2 Lambda3

  29. Summary • OIF overview • OIF Worldwide interoperability demo 2005 • Introduction • Some technical details • OIF & ITU collaboration • Telecom Italia Laboratory in Torino • Conclusions

  30. How big a deal is this? The 20 companies participating in the OIF Interoperability demo had $240 billion revenues in 2004 Source: Ovum-RHKNote: Vendor revenues include ON and switching and routing revenues only; service provider revenues are global wireline only

  31. Significance of 2005 OIF Demonstration • Implementation-focused: OIF Implementation Agreements are targeted at practical, real-world development and test details • Demonstrates maturity and interoperation of control plane specs, vendor solutions and test methods • Provides critical proving ground needed for carriers to gain confidence in deploying the technology • Allows end users to access carrier optical network services using low cost Ethernet interfaces • Allows carriers to offer Ethernet services using their legacy SONET/SDH infrastructure • Gives vendors market opportunities for Ethernet, SONET/SDH and other equipment

  32. For more information on the OIF please visit www.oiforum.com Thank you!

  33. Ethernet call completes Client Ethernet call progresses SONET/SDH call Ethernet call UNI-C Ethernet connection Interlayer call invoked GFP VCAT GFP VCAT connections Interlayer Call Technology • Client makes an Ethernet call to destination • Network triggers SONET/SDH calls to match Ethernet service request • Control plane sets up Ethernet and SONET/SDH connections, and controls GFP/VCAT Client OXC OXC UNI-C UNI-N UNI-N Ethernet Ethernet UNI-N UNI-N SONET/SDH
