cs193h high performance web sites lecture 5 make fewer http requests

CS193H:High Performance Web SitesLecture 5: Make Fewer HTTP Requests

Steve Souders

Google

souders@cs.stanford.edu

announcements
Announcements

Second HTTPWatch request list was sent today

rule 1 make fewer http requests
Rule 1: Make Fewer HTTP Requests

80-90% of load time is the frontend

the frontend time is dominated by HTTP

HTTP requests growth since 2003: 25 to 50*

each HTTP request has overhead – even with persistent connections

reducing HTTP requests has the biggest impact

bigger benefit for users with higher latency

parallelization reduces the need for this

*http://www.websiteoptimization.com/speed/tweak/average-web-page/

rule 1 make fewer http requests4
Rule 1: Make Fewer HTTP Requests

But...

is it possible to reduce HTTP requests without reducing richness?

Yes:

combine JS, CSS

image maps

CSS sprites

inline images

combine js and css
Combine JS and CSS

not combining scripts with stylesheets

multiple scripts => one script

multiple stylesheets => one stylesheet

apache module:

http://code.google.com/p/modconcat/

YUI Combo Handler

http://yuiblog.com/blog/2008/07/16/combohandler/

http://stevesouders.com/examples/combo.php

myspace
MySpace

my "Improving Top Site" site

image maps
Image Maps

<img usemap="#map1" border=0 src="/images/imagemap.gif">

<map name="map1">

<area shape="rect" coords="0,0,31,31" href="home.html">

<area shape="rect" coords="36,0,66,31" href="gifts.html">

<area shape="rect" coords="71,0,101,31" href="cart.html">

<area shape="rect" coords="106,0,136,31" href="settings.html">

<area shape="rect" coords="141,0,171,31" href="help.html">

</map>

old school, CSS sprites is preferred

image maps still useful when x,y coordinates are useful, for example, in maps

http://stevesouders.com/examples/imagemap.php

css sprites
CSS Sprites

multiple CSS background images => one image

<div style="background-image:

url('a_lot_of_sprites.gif');

background-position:

-260px -90px;

width: 26px;

height: 24px;">

</div>

overall size reduced

generator: http://spritegen.website-performance.org/

http://stevesouders.com/examples/sprites.php

inline images data urls
inline images (data: URLs)

embed the content of an HTTP response in place of a URL

<IMG ALT="Red Star"


if embedded in HTML document, probably not cached => embed in stylesheet instead

base64 encoding increases total size

works in IE8 (not IE7 and earlier)

http://stevesouders.com/examples/inline-images.php

data urls
data: URLs

not just for images

Hammerhead:

<frame src="data:text/html,%3Chtml%3E%3Cbody%20style%3D%22background..."></frame>

homework
Homework

Combine scripts and stylesheets on your "Improving Top Site" class project

Test improvement using Hammerhead

Add sheet to Web 100 spreadsheet for your web site; record results
