Presentation Transcript
design and creation of superwetting antiwetting surfaces

Bionic technology Lab

Design and creation of superwetting /antiwettingsurfaces

Xinjian Feng and Lei Jiang

Advanced Materials

Vol. 18, 3063–3078 (2006)

KUAS Chemical Engineering

outline

KUAS Chemical Engineering

4

Superamphiphilic Surfaces

Outlook and Summary

Superhydrophobic Surfaces

Surfaces with Reversible Superhydrophobicity and Superhydrophilicity

7

6

8

5

1

3

2

Surfaces with Superhydrophobicity and Superoleophilicity

Fundamental Theories

Introduction

Bionic technology Lab

Outline

Superamphiphobic Surfaces

abstract

KUAS Chemical Engineering

Bionic technology Lab

Abstract
  • Recent achievements in the construction of surfaces with special wettabilities,such as superhydrophobicity, superhydrophilicity, superoleophobicity,superoleophilicity, superamphiphilicity, superamphiphobicity,superhydrophobicity/superoleophilicity, and reversible switching between superhydrophobicity and superhydrophilicity, are presented.
  • Particular attention is paid to superhydrophobic surfaces created via various methods and surfaces with reversible superhydrophobicity and superhydrophilicity that are driven by various kinds of external stimuli.
abstract1

KUAS Chemical Engineering

Bionic technology Lab

Abstract
  • The control of the surface micro-/nanostructure and the chemical composition is critical for these special properties.
  • These surfaces with controllable wettability are of great importance for both fundamental research and practical applications.
introduction wetting property

KUAS Chemical Engineering

θ

θ

θ

Bionic technology Lab

Introduction- Wetting property

5˚<θ<90˚

Hydrophilic

θ<5˚

Superhydrophilic

θ>150˚

Superhydrophobic

90˚<θ <150˚

Hydrophobic

Roughness substrate

with hydrophilic material

Smooth substrate

with hydrophilic material

Smooth substrate

with hydrophobic

material

Roughness substrate

with hydrophobic

material

introduction superhydrophobic property in nature

KUAS Chemical Engineering

Bionic technology Lab

Introduction- superhydrophobic property in Nature

圖一、(A) water-strider legs(B) Iridescent peacock feathers(C) mosquito(D) lotus leaves

KesongLiua and Lei Jianga,Nano Today 6, 155—175(2011)

introduction lotus effect

KUAS Chemical Engineering

Bionic technology Lab

Introduction- Lotus effect
  • Hierarchical structure
  • Low surface energy material

10μm

wax

100nm

http://nanotechweb.org/cws/article/tech/21936/1/0504031

introduction

KUAS Chemical Engineering

Bionic technology Lab

Introduction
  • Artificial surfaces
    • Creating micro-/nanostructures on hydrophobic substrates
    • Chemically modifying a micro-/nanostructured surface with materials of low surface free energy
introduction1

KUAS Chemical Engineering

Bionic technology Lab

Introduction

low surface free energy

high surface free energy

Figure 1. Illustration of the relationships between the four kinds of fundamental superwetting/antiwetting properties (in blue boxes) and the further special surface superwetting/antiwetting functions (in yellow boxes) that are obtained by combining either two of the fundamental properties. Herein, the double arrow indicates coexistence of the two

properties, and the reversible arrow indicates switching of the two properties.

fundamental theories

KUAS Chemical Engineering

Bionic technology Lab

Fundamental Theories

(液滴適用於平坦表面)

  • Young’s equation
  • γLV cosθ =γSV –γSL
  • (液滴適用於完全潤濕固體)
  • Wenzel’s equation
  • Cassie and Baxter equation

(液滴適用於粗糙固體表面)

artificial superhydrophobic surfaces

KUAS Chemical Engineering

Bionic technology Lab

Artificial Superhydrophobic Surfaces
  • Template Synthesis
  • Phase Separation
  • Electrochemical Deposition (ECD)
  • Electrohydrodynamics (EDH)
  • Crystallization Control
artificial superhydrophobic surfaces1

KUAS Chemical Engineering

Bionic technology Lab

Artificial Superhydrophobic Surfaces
  • Template Synthesis

膜板

基材

奈米轉印

脫膜

圖四、奈米轉印製備柱狀陣列

圖三、奈米轉印技術示意圖

袁 等人,軟模板法制備導電高分子微結構陣列,國高分子材料科學與工程研討會論文集, 2004

奈米轉印技術介紹 , 蔡宏營 博士

artificial superhydrophobic surfaces2

KUAS Chemical Engineering

Bionic technology Lab

Artificial Superhydrophobic Surfaces
  • Phase Separation

圖五、

Ma et al., Electrospun Poly(Styrene-block-dimethylsiloxane) Block

Copolymer Fibers Exhibiting Superhydrophobicity, Langmuir 2005, 21, 5549-5554

artificial superhydrophobic surfaces3

KUAS Chemical Engineering

Bionic technology Lab

Artificial Superhydrophobic Surfaces
  • Electrochemical Deposition (ECD)

Figure 6. SEM image of an aligned poly(alkylpyrrole) microtube film preparedvia the ECD method. The inset shows a water droplet on the film(scale bar: 500 lm). Reprinted from

artificial superhydrophobic surfaces4

KUAS Chemical Engineering

Bionic technology Lab

Artificial Superhydrophobic Surfaces
  • Electrohydrodynamics (EDH)

Figure 7. SEM images of superhydrophobic polystyrene films with special

microsphere/nanofiber composite structures prepared via the EHDmethod. Reprinted from

artificial superhydrophobic surfaces5

KUAS Chemical Engineering

Bionic technology Lab

Artificial Superhydrophobic Surfaces
  • Crystallization Control

圖六、

王 等人,超疏水网状结构对水中气泡的转移作用, 高等學校化學學報, 29, 12,2484, 2008

multifunctional superhydrophobic surfaces

KUAS Chemical Engineering

Bionic technology Lab

Multifunctional Superhydrophobic Surfaces
  • Increasing the surface roughness
    • decrease many other important properties
  • For practical industrial processes and our daily life.
    • Therefore, much attention has been devoted to the fabrication of multifunctional superhydrophobic films.
multifunctional superhydrophobic surfaces1

KUAS Chemical Engineering

Bionic technology Lab

Multifunctional Superhydrophobic Surfaces
  • Superhydrophobic Surfaces with Optical Properties

圖七、透明超疏水薄膜

multifunctional superhydrophobic surfaces2

KUAS Chemical Engineering

Bionic technology Lab

Multifunctional Superhydrophobic Surfaces
  • Superhydrophobic Surfaces with Highly Adhesive Forces

Figure 8. Superhydrophobic aligned PS nanotube films with high adhesive

force. Shapes of the water droplets on the as-prepared PS nanotube

films at tilt angles of a) 0° and b) 180°. c) SEM top image of the as-prepared

aligned PS nanotubes films. Reprinted from

multifunctional superhydrophobic surfaces3

KUAS Chemical Engineering

Bionic technology Lab

Multifunctional Superhydrophobic Surfaces
  • Superhydrophobic Surfaces with High Electrical Conductivity

Figure 9. SuperhydrophobicZnOnanoporous films with good conductivity.a) Atomic force microscopy 3D image of the as-prepared thin films.b) Simultaneous current scanning image of the as-prepared film at a biasvoltage of 0.5 V. Reprinted with permission from

multifunctional superhydrophobic surfaces4

KUAS Chemical Engineering

Bionic technology Lab

Multifunctional Superhydrophobic Surfaces
  • Superhydrophobic Surfaces over the Entire pH Range

Figure 10. The relationship between pH values and contact angles onnanostructuredgraphitelike carbon films. The high contact angle of theacid, water, and alkali on the film indicates that the as-prepared film issuperhydrophobic over the entire pH range.

surfaces with superhydrophobicity and superoleophilicity

KUAS Chemical Engineering

Bionic technology Lab

Surfaces with Superhydrophobicity and Superoleophilicity

Figure 11. PTFE-coated copper mesh and its extreme wettability response for oil/water. The as-prepared films show superhydrophobicity, while, when a diesel oil droplet contacts it, the oil spreads quickly on the film and permeates through the film within 240 ms, showing good superoleophilicity

surfaces with reversible superhydrophobicity and superhydrophilicity

KUAS Chemical Engineering

Bionic technology Lab

Surfaces with Reversible Superhydrophobicityand Superhydrophilicity

Figure 12. Relationship between the water CA and the chain length of nalkanoic acids on dual-scale rough copper films that are prepared via electrodeposition. The insets show the shapes of the water droplets on films modified with n-propanoic acid (left) and n-octanoic acid (right).

surfaces with reversible superhydrophobicity and superhydrophilicity1

KUAS Chemical Engineering

Bionic technology Lab

Surfaces with Reversible Superhydrophobicityand Superhydrophilicity
  • Light Irradiation

Figure 13. Reversible switching between superhydrophobicity and superhydrophilicity of inorganic nanorod films. a) Field-emission SEM top image of the as-prepared ZnOnanorod film. b) Lotuslike TiO2 nanorod film. Reprinted with permission from. c) Changes in the water-droplet shape on aligned ZnOnanorod films before (left) and after (right) UV illumination. Reprinted with permission from .

surfaces with reversible superhydrophobicity and superhydrophilicity2

KUAS Chemical Engineering

Bionic technology Lab

Surfaces with Reversible Superhydrophobicityand Superhydrophilicity
  • Thermal Response

Figure 14. a) Schematic diagram of the reversible competition between inter- and intramolecular hydrogen bonding, which is the molecular mechanism of the temperature-responsive switching on a PNIPAAm film. b) Water-drop profile for thermally responsive switching between superhydrophobicity and superhydrophilicity of PNIPAAm-modified micro-and nanostructured Si surfaces at 25 °C (left) and 40 °C (right), respectively.

surfaces with reversible superhydrophobicity and superhydrophilicity3

KUAS Chemical Engineering

Bionic technology Lab

Surfaces with Reversible Superhydrophobicityand Superhydrophilicity
  • Solvent Effect
    • When mixed polymer contain incompatible hydrophobic and hydrophilic components are attached to a substrate.
  • Y-shaped molecule composed of hydrophobic polystyrene and hydrophilic poly(acrylic acid) (PAA) chains was designed and grafted to a silicon surface.
  • After the film was treated with toluene, a good solvent for PS, the top surface layer was enriched with PS arms,whereas the PAA arms collapsed into cores
surfaces with reversible superhydrophobicity and superhydrophilicity4

KUAS Chemical Engineering

Bionic technology Lab

Surfaces with Reversible Superhydrophobicityand Superhydrophilicity
  • Electric-Field Response

圖九、電潤濕原理

http://www.materialsnet.com.tw/DocView.aspx?id=7284

surfaces with reversible superhydrophobicity and superhydrophilicity5

KUAS Chemical Engineering

Bionic technology Lab

Surfaces with Reversible Superhydrophobicityand Superhydrophilicity
  • Mechanical Force Induction
  • When PTFE was extended axially with anextension ratio change from 0 to 190 %, the water CA increasedfrom 108° to 165°.
  • The reason for thischange in wettability is due to the change of the density of thePTFE crystals during the axial extension.
outlook and summary

KUAS Chemical Engineering

Bionic technology Lab

Outlook and Summary
  • superhydrophobicity or superhydrophilicity
    • requires a rough surface structure.
  • Smart devices
    • surface wettability can be reversibly switched.
  • Future work
    • improve the mechanical stability of functional rough surfaces.
    • design new multifunctional materials.
    • intelligent materials can be tuned by dual or multiple external stimuli
