ENGAGING STUDENTS WITH THE PHYSICS OF MOTORSPORTS

1. ENGAGING STUDENTS WITH THE PHYSICS OF MOTORSPORTS

2. Outline • Introduction • What is Quantum Racing? • Teaching physics through racing • Physics of Racing • 1-D motion • 2-D motion • experiments • Classroom Activities • Turn Radius • Gear Ratio • Rolling Friction

3. Part of the Society of Physics Student in the Department of Physics and Astronomy. • Formed to participate in the Grand Prix of BGSU (2nd annual held April 14th, 2007) Viewed as an exciting way to learn physics in many different capacities.

4. What can racing bring to physics? Racing can be an effective and exciting tool in physics education. A Champ Car produces enough downforce at race speeds that it could drive upside down on the ceiling. A Top Fuel Dragster accelerates from 0-335 mph in under 4.4 seconds pulling almost 5 g’s.

5. The Physics of Racing • Thermodynamics • Ideal gas law • P-V diagrams • Entropy • Structural Mechanics • Beam flexure • Center of Mass • Weight Transfer • Kinematics • Position/velocity/acceleration relations • F=ma • 1-D/2-D motion • Rotational motion • Torque • Energy/work • Conservation of energy • Collisions • Linear/Angular Momentum • Elasticity • Fluids/pressure

6. Undergraduate Research • Two Parts • Day to day working involved with the kart • Individual Projects

7. The Physics of Racing

8. BGSU Physics and Astronomy Quantum Racing “The turn right before the longest straight is the most important” WHY?

9. BGSU Physics and Astronomy Quantum Racing 1-D motion[straights] • Theory: • Application: Being slightly faster into a straight will end in a larger advantage at the end.

10. BGSU Physics and Astronomy Quantum Racing

11. BGSU Physics and Astronomy Quantum Racing

12. BGSU Physics and Astronomy Quantum Racing What does that mean on the track? The time difference for between a car entering at 28 vs 30 mph is: 0.1182 s for 73 feet 0.06 s for 40 feet That means a 5.89 foot advantage for the 73 foot straight -about a kart length and a 3.06 foot advantage for the 40 foot straight -about half a kart length

13. BGSU Physics and Astronomy Quantum Racing What is the fastest way to get through a corner?

14. BGSU Physics and Astronomy Quantum Racing 2-D motion[corners] • Theory: • Application: Taking the line with the largest radius, will be the fastest

15. BGSU Physics and Astronomy Quantum Racing Racing Lines • Racing lines refers to the variations of paths that a driver can take through a corner.

16. BGSU Physics and Astronomy Quantum Racing Variations in speed… Obviously the different lines have a difference in radii, and therefore allowed speeds for a given setup. Corner : 75 ft radius at centerline 30 foot track width Line Radii/max velocity (1.1g turn): effective red line – 63 feet/32.16 mph effective green line – 87 feet/37.79 mph effective blue line – 145 feet/48.78 mph Calculations taken from Brian Beckman’s “Physics of Racing”

17. BGSU Physics and Astronomy Quantum Racing …lead to a variation in time • The allowed speed leads directly to fastest times for the different lines. Calculations taken from Brian Beckman’s “Physics of Racing”

18. BGSU Physics and Astronomy Quantum Racing …track width is also a factor • The track width effects the allowed velocities… Calculations taken from Brian Beckman’s “Physics of Racing”

19. BGSU Physics and Astronomy Quantum Racing Calculations are great… …but what about the real world?

20. BGSU Physics and Astronomy Quantum Racing Data Acquisition(DAQ) • Alfano • Records: RPM Head Temp Wheel Speed G-force Lap times • 10 hz ~90 min

21. BGSU Physics and Astronomy Quantum Racing

22. BGSU Physics and Astronomy Quantum Racing 1-D experiment • Measure both starting and ending velocities as well as the acceleration and distance. IR beacon #2 IR beacon #1 Known distance -show relationship and measure μs

23. BGSU Physics and Astronomy Quantum Racing

24. BGSU Physics and Astronomy Quantum Racing 2-D experiment • Measure known radius, acceleration, and speed r -show relationship and measure μc
