Presentation Transcript
slide1

StreamInsight04 – Installing, Deploying and Maintaining the SQL Server 2008 R2 StreamInsight Runtime Engine

SQL10R2UPD05-DECK-04

[Presenter Name][Presenter Title] [Company Name]

module overview
Module Overview
  • Introducing StreamInsight
  • Querying Events in StreamInsight
  • Designing StreamInsight Event Models and Adapters
  • Installing, Deploying, and Maintaining the StreamInsight Runtime Engine
agenda
Agenda
  • Choosing a Development Model
  • Choosing a Deployment Model
  • Demo: Working with a Development Model
  • Installing, Monitoring, and Maintaining StreamInsight
  • Demo: Event Flow Debugger
  • Lab: Debugging Event Flows
streaminsight development models
StreamInsight Development Models
  • Two development models:
    • Implicit Server (Easiest)
    • Explicit Server (Most Flexible)
implicit server development model
Implicit Server Development Model
  • Easy development model to use
  • Hides most complexity
  • StreamInsight server acts as an implicit host
    • Creates and registers required objects
  • Allows developers to focus on query logic
    • Good test environment for query developers
implicit server process
Implicit Server: Process
  • Server created implicitly for each query
  • Query is automatically hosted
    • Stored in memory, not on stable storage (disk)
  • Developer provides:
    • Input/output adapter bindings
    • Query logic and binding
  • Server manages objects
    • Creates event type (accesses it via reflection)
    • Registers input/output adapters
    • Registers query template and query
    • Creates objects when query starts
    • Disposes of objects when query is disposed
implicit server query example
Implicit Server: Query Example

varinputConf = newTextFileInputConfig("MyData.csv");

varoutputConf = newTextFileOutputConfig("Result.csv");

varinputStream = CepStream<PayloadType>.Create("inputStream",

typeof(TextFileInputFactory),inputConf,

EventShape.Point);

CepStream<PayloadType> filter = from e ininputStream

wheree.value > 10

select e;

Query query = filter.ToQuery(typeof(TextFileOutputFactory),

outputConf,

EventShape.Interval,

StreamEventOrder.FullyOrdered);

query.Start();

// perform work or wait for output adapter to signal complete

query.Stop();

explicit server development model
Explicit Server Development Model
  • Developer explicitly creates and registers all objects
  • Provides complete control of
    • StreamInsight application
    • Development environment (via client-side object model API)
  • Allows for reuse of
    • Queries
    • Adapters
    • Event Types
    • Third-party Query Templates
explicit server process
Explicit Server: Process
  • Code creates or connects to server
  • Code creates all objects and registers them into server
    • Query Template
    • Query Instance
    • Event Types
    • Input/Output Adapters
  • Server can store metadata in memory or persist to disk
  • Server can run locally or remotely via Web service
explicit server query example 1 of 2
Explicit Server: Query Example 1 of 2

Server server = Server.Create();

Applicationapplication = server.CreateApplication("app1");

InputAdapteria =

application.CreateInputAdapter<MyInputAdapterFactory>(

"InputAdapterName", "Some description");

OutputAdapteroa =

application.CreateOutputAdapter<MyOutputAdapterFactory>(

"OutputAdapterName", "Some other description");

CepStream<PayloadType> inputStream

= CepStream<PayloadType>.Create("inputStream");

varhighWaterMarkAlert = from e ininputStream

wheree.value > 99

select e;

explicit server query example 2 of 2
Explicit Server: Query Example 2 of 2

QueryTemplate qt1 = application.CreateQueryTemplate(

"highWaterMarkAlert", highWaterMarkAlert);

QueryBinderqb = newQueryBinder(qt1);

qb.BindProducer("inputStream", ia, newMyInputAdapterConfig(),

EventShape.Interval);

qb.AddConsumer("queryresult", oa, newMyOutputAdapterConfig(),

EventShape.Point, StreamEventOrder.FullyOrdered);

Query q1 = application.CreateQuery(

"query1", qb, "Query Description");

q1.Start();

explicit server connect to existing server
Explicit Server: Connect to Existing Server

// Connect to a remote CEP server.

Server server = Server.Connect(

newSystem.ServiceModel.EndpointAddress(

@"http://localhost:12345/CEP"));

// Retrieve the application app1 from the server.

Applicationapplication = server.Applications["app1"];

// Retrieve existing query template, qt1, from server.

QueryTemplate qt1 = application.QueryTemplates["qt1"];

agenda13
Agenda
  • Choosing a Development Model
  • Choosing a Deployment Model
  • Demo: Working with a Development Model
  • Installing, Monitoring, and Maintaining StreamInsight
  • Demo: Event Flow Debugger
  • Lab: Debugging Event Flows
streaminsight deployment scenarios
StreamInsight Deployment Scenarios
  • Full integration into host application as embedded DLL
  • Standalone server
    • Multiple applications
    • Multiple users
    • Option for a Windows Service on install
deployment hosted dll
Deployment: Hosted DLL
  • Use this option for the following scenarios:
    • Using Implicit Server development model
    • Needing to minimize memory footprint
    • Wanting to use a single process for both application and CEP server
    • Wanting to tightly control access to the CEP server
  • Do not use this option if:
    • You require shared access to the metadata
    • You require shared access to the streaming event data
deployment standalone server
Deployment: Standalone Server
  • Use this option for the following scenarios:
    • Metadata objects need to be shared between applications
      • Event Types
      • Adapter Types
      • Query Templates
    • A data source registered with the server provides an event stream for another existing application
  • Can choose to set up Windows Service during install
    • SQL Server CE Metadata Store
deployment other potential scenarios
Deployment: Other Potential Scenarios
  • StreamInsight-enabled device
  • Building operational intelligence
working with a development model

Working with a Development Model

SQL10R2UPD05-DEMO-06

Demo

agenda19
Agenda
  • Choosing a Development Model
  • Choosing a Deployment Model
  • Demo: Working with Development Models
  • Installing, Monitoring, and Maintaining StreamInsight
  • Demo: Event Flow Debugger
  • Lab: Debugging Event Flows
streaminsight installation requirements
StreamInsight Installation Requirements
  • Admin privileges required
  • .NET Framework 3.5 SP1
  • Must remove any existing SQL Server CE installation
  • Uninstall by Control Panel or re-running the setup msi
supplied samples
Supplied Samples
  • Many samples available
  • CodePlex project hosting for samples
    • http://streaminsight.codeplex.com
monitoring streaminsight
Monitoring StreamInsight
  • Need to track
    • Overall health of system
    • Query performance
  • Diagnostic views using ManagementService API
    • Use URIs for resource naming
    • GetDiagnosticView()
    • SetDiagnosticSettings()
    • ClearDiagnosticSettings()
    • Can be accessed via PowerShell
available diagnostic granularity
Available Diagnostic Granularity
  • Individual
    • Query
    • Adapter
    • Operator
    • Stream
    • Scheduler
  • Server-wide
    • Event Manager
    • Plan Manager
    • Scheduler
    • Query
accessing diagnostics from powershell
Accessing Diagnostics from Powershell

PS C:\> [System.Reflection.Assembly]::LoadWithPartialName(

"Microsoft.ComplexEventProcessing")

PS C:\> $server = [Microsoft.ComplexEventProcessing.Server]::Connect(

"http://localhost/StreamInsight")

PS C:\> $server | gm

TypeName: Microsoft.ComplexEventProcessing.Server

PS C:\> $dv=

$server.GetDiagnosticView("cep:/Server/EventManager")

PS C:\> $dv= $server.GetDiagnosticView("cep:/Server/PlanManager")

PS C:\> $dv= $server.GetDiagnosticView(

"cep:/Server/Application/ObjectModelSample/Query/SensorQuery")

event flow debugger
Event Flow Debugger
  • Analyzes events through time
    • Step through time
  • Follows events from one operator to the next
  • Can inspect all events on all streams and locate events
  • Helps answer: “How did this event get to this state?”
    • Root-cause analysis
  • Shows the effect of one event on downstream events
    • Event propagation analysis
  • Shows query execution statistics
event flow debugger27

Event Flow Debugger

SQL10R2UPD05-DEMO-07

Demo

resources
Resources
  • StreamInsight Website
    • http://www.microsoft.com/sqlserver/2008/en/us/R2-complex-event.aspx
  • StreamInsight Books Online
    • http://msdn.microsoft.com/en-us/library/ee362541(SQL.105).aspx
  • StreamInsight Forums
    • http://social.msdn.microsoft.com/Forums/en-US/streaminsight/threads
  • StreamInsight Whitepaper
    • http://download.microsoft.com/download/F/D/5/FD5E855C-D895-45A8-9F3E-10AFADBE51A/Microsoft%20CEP%20Overview.docx
