  1. San Jose State University Department of Mechanical Engineering Large Optics Diamond Turning Machine Presented by Vu Dao Gilbert Wong ME 250 Precision Machine Design

  2. Agenda • Introduction • Advantages • Precision • Design • Summary • Q&A ME 250 Precision Machine Design

  3. Introduction • LODTM • Large Optics Diamond Turning Machine • High precision two axis vertical lathe • Diamond cutting tool • 64 in diameter, 20 in height, 3000lb • Most precise vertical axis lathe currently available. ME 250 Precision Machine Design

  4. ME 250 Precision Machine Design

  5. Advantages of LODTM • Produce complex geometries • Achieve high accuracy and repeatability • Produce mirror finish surface ME 250 Precision Machine Design

  6. Precision • Radial • 28 nm (280Å) • Surface finish • 4.3 nm (42Å) • Analogy 280Å is ~ 3500 times smaller than diameter of human hair ME 250 Precision Machine Design

  7. Metrology System • Metrology frame • Kinematically mounted to LODTM frame by three blade flexures • Super Invar • Very low CTE, 0.63*10-6/°C • Liquid Cooling • Double-walled panels surrounding the metrology frame • Uniform temperature of 0.001°F ME 250 Precision Machine Design

  8. Motion Control • Interferometer • Resolution .618nm • Closed loop • Relative measurement Baird, 1999 ME 250 Precision Machine Design

  9. Motion Control Baird, 1999 ME 250 Precision Machine Design

  10. Motion Control • Bearings • Fluid-film for smooth friction free motion • Radial, Thrust • Water cooled to prevent heat generation • Analog Servos • One for X and Z axis • 25.4 mm/sec machining speed • Fast Tool Servo ME 250 Precision Machine Design

  11. Cutting Motion Donaldson, 1983 ME 250 Precision Machine Design

  12. Environmental Control • Four pneumatic isolators • Acoustic vibration isolation • Air Flow (External) • Uniform temperature of 0.01°F Patterson, 1987 ME 250 Precision Machine Design

  13. Summary • Highest accuracy turning machine • Strict temperature control • Primarily used to produce precision lens ME 250 Precision Machine Design

  14. References • Baird, E.D., Patterson, S.R, Donaldson, R.R., “The Laser Interferometer System for the Large Optics Diamond Turning Machine,” UCRL-ID-134693, Lawrence Livermore National Laboratory, 1999. • Donaldson, R.R., Patterson, S., “Design and Construction of A Large Vertical Axis Diamond Turning Machine,” UCRL-89738, Lawrence Livermore National Laboratory, 1983. • McCue, H., “The Motion Control System for the Large Optics Diamond Turning Machine,” UCRL-86438, Lawrence Livermore National Laboratory, 1981. • Patterson, S., “Inspection of the Large Optics Diamond Turning Machine,” UCRL-97696, Lawrence Livermore National Laboratory, 1987. • Hamilton, Jim., “Large Optics Diamond Turning Machine,” UCRL-TB-147593, Lawrence Livermore National Laboratory, 2002. ME 250 Precision Machine Design
