THE NEED FOR DOCUMENTATION. To provide objective information for the clinician in order to . monitor the progress of a healing wound assess the influence of clinical interventions verify clinical trials and increasingly important
E N D
1. RECORDING WOUNDS -DOCUMENTING WOUNDCARE This Presentation gives an overview over current technical developments in the assessment of wound parameters.
Part 1: Wound Measurement Techniques - an overview
Part 2: Practical demonstration of wound size measurementThis Presentation gives an overview over current technical developments in the assessment of wound parameters.
Part 1: Wound Measurement Techniques - an overview
Part 2: Practical demonstration of wound size measurement
2. THE NEED FOR DOCUMENTATION Healing progress:
- healing or not?
- If not, change treatment regime as soon as poss.
- detect problems (infection, blood perfusion, etc.)
New clinical interventions:
- new regimes, methods, treatments really better?
- example: anecdotal evidence suggests that biopsy sites in chronic wounds heal faster. Is that true?
Verify trials:
- new bandage, ointment, debridement agent better at a certain moment in time?
NOT: Prediction of healing time for chronic wounds. Healing progress:
- healing or not?
- If not, change treatment regime as soon as poss.
- detect problems (infection, blood perfusion, etc.)
New clinical interventions:
- new regimes, methods, treatments really better?
- example: anecdotal evidence suggests that biopsy sites in chronic wounds heal faster. Is that true?
Verify trials:
- new bandage, ointment, debridement agent better at a certain moment in time?
NOT: Prediction of healing time for chronic wounds.
3. THE NEED FOR DOCUMENTATION (cont.) Apart from the clinical need there is also the increasing likelyhood of professional misconduct litigationApart from the clinical need there is also the increasing likelyhood of professional misconduct litigation
4. 'REAL-TIME' WOUND DOCUMENTATION Real-Time
A term borrowed from computing: In this context, anything that can be done at the patient's bedside and does not require a laboratory - In contrast to laboratory techniques (biochemistry).
1. Temperature - far IR imaging, 8-12um (0.9um near IR) for
Raynaud’s phenomenon, Arthritis, Paguet’s
disease, wound in-flammation, blood perfusion
2. Oxygen - saturation of O2 in haemoglobin molecules
(98% of O2)
- tension of O2 in tissue and blood plasma (2% of
O2)
3. Structure - classify wound status by tissue micro-structure
using high frequency ultrasound.
4. Blood flow - ultrasound dopplers & plethysmography
5. Size - area, volume, circumference, depth of a wound
- limb size: edema, underlying vascular problems
6. Colour - inflammation
- wound status
Protocol
Extremely important for most documentation / measurement techniques in order to guarantee inter and intra observer continuity / avoid errorsReal-Time
A term borrowed from computing: In this context, anything that can be done at the patient's bedside and does not require a laboratory - In contrast to laboratory techniques (biochemistry).
1. Temperature - far IR imaging, 8-12um (0.9um near IR) for
Raynaud’s phenomenon, Arthritis, Paguet’s
disease, wound in-flammation, blood perfusion
2. Oxygen - saturation of O2 in haemoglobin molecules
(98% of O2)
- tension of O2 in tissue and blood plasma (2% of
O2)
3. Structure - classify wound status by tissue micro-structure
using high frequency ultrasound.
4. Blood flow - ultrasound dopplers & plethysmography
5. Size - area, volume, circumference, depth of a wound
- limb size: edema, underlying vascular problems
6. Colour - inflammation
- wound status
Protocol
Extremely important for most documentation / measurement techniques in order to guarantee inter and intra observer continuity / avoid errors
5. OXYGEN MEASUREMENTS
6. 'REAL-TIME' WOUND DOCUMENTATION
7. WOUND COLOUR Prediction of Healing Time
Works for certain types of burn wounds only.
Presence of Inflammation (Infection ?)
Under research at the moment.
Wound Status
Commercially available. / Value subject of discussionPrediction of Healing Time
Works for certain types of burn wounds only.
Presence of Inflammation (Infection ?)
Under research at the moment.
Wound Status
Commercially available. / Value subject of discussion
8. PREDICTION OF HEALING TIME(BURN WOUNDS) Prediction of Healing Time
How it works:
- red, green and IR Diodes illuminate the wound site
- refection picked up by a sensor
- amount of relection measured and plotted
Graph:
Graph shows a plot of 40 wounds. The position of each wound (cross or circle) is given by plotting its Red/IR quotient over its green/IR quotient.
Wounds that are likely will heal within 20 days are clustered at the top (crosses), those that won't at the bottom (circles).
The probability of healing within 30 days can be expressed using the mathematical equation shown.
Note:
This is a rare example where the prediction of healing time is possiblePrediction of Healing Time
How it works:
- red, green and IR Diodes illuminate the wound site
- refection picked up by a sensor
- amount of relection measured and plotted
Graph:
Graph shows a plot of 40 wounds. The position of each wound (cross or circle) is given by plotting its Red/IR quotient over its green/IR quotient.
Wounds that are likely will heal within 20 days are clustered at the top (crosses), those that won't at the bottom (circles).
The probability of healing within 30 days can be expressed using the mathematical equation shown.
Note:
This is a rare example where the prediction of healing time is possible
9. DETECTION OF INFLAMMATION Prediction of Inflammation
Based on the observation that a fully infected wound 'looks angry' at the clinician (i.e. bright reddish/purplish).
The hope is, that the transition between normal colour and 'angry' colour can be detected at an early stage in order to deal with the condition as soon as possible.
How it works:
- images of cleansed wounds taken with digital camera
- colour calibration chart included in image
- image digised into HIS format (Hue, Saturation, Inensity), Hue is shown on the graph
- pixels of wound added up into a histogram producing the curves shown
- classification: inflamed: narrow and tall histogram, not inflamed: broad and low histogram
Results: 49 out of 60 wounds classified correctly
Research under way. Results in PhD Thesis end 2001Prediction of Inflammation
Based on the observation that a fully infected wound 'looks angry' at the clinician (i.e. bright reddish/purplish).
The hope is, that the transition between normal colour and 'angry' colour can be detected at an early stage in order to deal with the condition as soon as possible.
How it works:
- images of cleansed wounds taken with digital camera
- colour calibration chart included in image
- image digised into HIS format (Hue, Saturation, Inensity), Hue is shown on the graph
- pixels of wound added up into a histogram producing the curves shown
- classification: inflamed: narrow and tall histogram, not inflamed: broad and low histogram
Results: 49 out of 60 wounds classified correctly
Research under way. Results in PhD Thesis end 2001
10. WOUND STATUS Wound Status
Value questioned by some clinicians.
Underlying idea: to plot the ratio of area occupied by red, yellow and black tissue in order to follow the progress of healing over time form necrotic/sloughy towards granulating.
Has been used in clinical trials (debridement by Krill enzymes)
How it works:
- images taken by specialised Polaroid or digital camera
- images sent to CWA Institute (Sweden) for evaluation by a dermatologist using a computer program
- results are sent back to clinicWound Status
Value questioned by some clinicians.
Underlying idea: to plot the ratio of area occupied by red, yellow and black tissue in order to follow the progress of healing over time form necrotic/sloughy towards granulating.
Has been used in clinical trials (debridement by Krill enzymes)
How it works:
- images taken by specialised Polaroid or digital camera
- images sent to CWA Institute (Sweden) for evaluation by a dermatologist using a computer program
- results are sent back to clinic
11. 'REAL-TIME' WOUND DOCUMENTATION
12. TEMPERATURE MEASUREMENTS Temperatur Measurements
Infrared measurements are fast and non-invasive.
Care must be taken to fully understand the mechanisms that guide IR measurements (Protocol !) Factors such as emissivity of the measured surface can falsify the result if not taken into consideration.
Hot wound area: inflammation
Cold wound area: little perfusion, impaired healing
IR Cameras:
- cooled with liquid Nitrogen or by Sterling engines to minus 196 degrees take the images (modern cameras (Bolometers) are un-cooled)
- expensive (Ł 15,000 to Ł 45,000)
Applications:
Diagnosis of rheumatism, Paguest's disease, "Vibration white finger", early detecion of Osteomyelitis due to diabetic foot ulcer (see next slide)
Temperatur Measurements
Infrared measurements are fast and non-invasive.
Care must be taken to fully understand the mechanisms that guide IR measurements (Protocol !) Factors such as emissivity of the measured surface can falsify the result if not taken into consideration.
Hot wound area: inflammation
Cold wound area: little perfusion, impaired healing
IR Cameras:
- cooled with liquid Nitrogen or by Sterling engines to minus 196 degrees take the images (modern cameras (Bolometers) are un-cooled)
- expensive (Ł 15,000 to Ł 45,000)
Applications:
Diagnosis of rheumatism, Paguest's disease, "Vibration white finger", early detecion of Osteomyelitis due to diabetic foot ulcer (see next slide)
13. DIABETIC FOOT ULCER Example of Infrared Imaging
At admission both, and x-ray and a thermogram were taken. No pathological signs on the x-ray, but the thermogram shows clear signs of inflammation. 5 weeks later a further x-ray confirmed the underlying problem (Osteomyelitis).
Clinical trial (St. Woolos Hospital, Newport) under way, results on more than 15 patients confirmed so far: Thermography can predict Osteomyelitis.Example of Infrared Imaging
At admission both, and x-ray and a thermogram were taken. No pathological signs on the x-ray, but the thermogram shows clear signs of inflammation. 5 weeks later a further x-ray confirmed the underlying problem (Osteomyelitis).
Clinical trial (St. Woolos Hospital, Newport) under way, results on more than 15 patients confirmed so far: Thermography can predict Osteomyelitis.
14. 'REAL-TIME' WOUND DOCUMENTATION
15. BLOOD FLOW Ultrasound Dopplers
Well known in clinics, no need to explain (?)
Plethysmography
Constriction followed by relief of blood flow in the leg. Not without its dangers.
Laser Dopplers
Non-contact imaging method. Reveals blood perfusion on the surface.Ultrasound Dopplers
Well known in clinics, no need to explain (?)
Plethysmography
Constriction followed by relief of blood flow in the leg. Not without its dangers.
Laser Dopplers
Non-contact imaging method. Reveals blood perfusion on the surface.
16. LASER DOPPLER IMAGING Laser Doppler Imaging Example
Shows increased blood perfusion around and inside the wound. Surface measurement only (up to 2 mm deep).
Measures speed of blood flow - not volume!
Laser doppler imagers scan the area of interest in a process that can take up to several minutes -> patient must not move!
Applications:
- burn wounds
- open heart surgery
- inflammaory reactions
- psoriasisLaser Doppler Imaging Example
Shows increased blood perfusion around and inside the wound. Surface measurement only (up to 2 mm deep).
Measures speed of blood flow - not volume!
Laser doppler imagers scan the area of interest in a process that can take up to several minutes -> patient must not move!
Applications:
- burn wounds
- open heart surgery
- inflammaory reactions
- psoriasis
17. 'REAL-TIME' WOUND DOCUMENTATION
18. TISSUE STRUCTURE High Resolution Ultrasound
Reveals structure of the healing tissue. Structural complexity can be quantified by application of fractal analysis.
High Resolution Ultrasound
Reveals structure of the healing tissue. Structural complexity can be quantified by application of fractal analysis.
19. 'REAL-TIME' WOUND DOCUMENTATION
20. WOUND SIZE: ESTABLISHED TECHNIQUES LENGTH/DEPTH
rulers
AREA
transparency tracings
photographic methods VOLUME
saline method
alginate casts
OTHER METHODS
stereophotogrammetry
ultrasound
MRI scanners
Kundin device These techniques are currently in use (or have been used traditionally).
Most frequently used techniques are indicated by a red square. They are well documented and well understood.These techniques are currently in use (or have been used traditionally).
Most frequently used techniques are indicated by a red square. They are well documented and well understood.
21. EMERGING TECHNIQUES AREA (2D)
digital photography VOLUME (3D)
laser scanners
stereo vision
structured light devices New Kids on the Block
-digital cameras
-computers
----> available, relatively inexpensive (??)
In the following:
- brief introduction into 2-D digital
photographic measurement techniques
- then a look at 3-D techniques and
methodsNew Kids on the Block
-digital cameras
-computers
----> available, relatively inexpensive (??)
In the following:
- brief introduction into 2-D digital
photographic measurement techniques
- then a look at 3-D techniques and
methods
22. 2D MEASUREMENTS Process:
prepare wound: cleanse, reference patch
take photo
download onto PC
use PC software to analyse photo
enter in database (incl. other data)
Problems:
often ill defined edges (strict protocol required)
flexible wounds (see this example)
curvature of wound area (out of sight, geometric
distortion -> wound ideally flat)
Process:
prepare wound: cleanse, reference patch
take photo
download onto PC
use PC software to analyse photo
enter in database (incl. other data)
Problems:
often ill defined edges (strict protocol required)
flexible wounds (see this example)
curvature of wound area (out of sight, geometric
distortion -> wound ideally flat)
23. PRECISION OF 2D MEASUREMENT TECHNIQUES 2D Measurement Techniques: Precision
Graph shows the precision of three groups of area measurement techniques. Precision is expressed in standard deviations as percentages of the respective area. This is necessary because the precision changes with varying wound areas.
Rulers: - least precise
Tracings: - more precise
Photographic methods: - most precise
Small wounds produce higher imprecision. Reason: quantisation error. In large wounds errors have a tendency of cancelling each other out.2D Measurement Techniques: Precision
Graph shows the precision of three groups of area measurement techniques. Precision is expressed in standard deviations as percentages of the respective area. This is necessary because the precision changes with varying wound areas.
Rulers: - least precise
Tracings: - more precise
Photographic methods: - most precise
Small wounds produce higher imprecision. Reason: quantisation error. In large wounds errors have a tendency of cancelling each other out.
24. 3D MEASUREMENT METHODS 3D Measurement techniques
Various tricks used to obtain a 3-D map of the wound area
Laser scanners,
Stereo vision
Structured light 3D Measurement techniques
Various tricks used to obtain a 3-D map of the wound area
Laser scanners,
Stereo vision
Structured light
25. 3D MEASUREMENTS MAVIS Measurement of Area and Volume Instrument System developed at University of Glamorgan
Stripes in colours for identification by image processing programme
Stripes follow contours of the limb and the wound
Computer produces 3-D map and reconstructs former healthy skin surface
Wound volume sandwiched between measured and reconstructed surface
MAVIS Measurement of Area and Volume Instrument System developed at University of Glamorgan
Stripes in colours for identification by image processing programme
Stripes follow contours of the limb and the wound
Computer produces 3-D map and reconstructs former healthy skin surface
Wound volume sandwiched between measured and reconstructed surface
26. PRECISION OF 3D MEASUREMENT METHODS Precision of 3-D Measurement Techniques
Graph shows the precision of 5 volumetric wound measurement techniques. Precision is expressed in standard deviations as percentages of the respective volume. This is necessary because the precision changes with varying area to volume ratios.
Area/volume ratio is important due to the need of reconstructing the original healthy skin surface in order to measure volume.
If a wound if large and only 1mm deep, than reconstruction is difficult (a large area to interpolate) and a reconstruction error of only 1mm constitutes an error of 100%.
If, in contrast, a wound is small and, say, 20mm deep, than a reconstruction error of 1mm will result in an error of only 5%.Precision of 3-D Measurement Techniques
Graph shows the precision of 5 volumetric wound measurement techniques. Precision is expressed in standard deviations as percentages of the respective volume. This is necessary because the precision changes with varying area to volume ratios.
Area/volume ratio is important due to the need of reconstructing the original healthy skin surface in order to measure volume.
If a wound if large and only 1mm deep, than reconstruction is difficult (a large area to interpolate) and a reconstruction error of only 1mm constitutes an error of 100%.
If, in contrast, a wound is small and, say, 20mm deep, than a reconstruction error of 1mm will result in an error of only 5%.
27. STEREO VISION : ‘3dMD’formerly: Tricorder Technology plc., UK 3dMD
Picture illustrates principle well. Here an implementation with 4 cameras.
Features:
Observed volume quite large: 25x25x30cm
fast acquisition, processing 1-3 minutes
wound measurement software available
evaluation: around 5 minutes
not very portable
Not for sale to end users. Sale via licensed manufacturers / distributors.
Expected price: approx Ł15,000
Clinical Trial with Bradford Royal Infirmary, Dr. Rob Cameron
3dMD
Picture illustrates principle well. Here an implementation with 4 cameras.
Features:
Observed volume quite large: 25x25x30cm
fast acquisition, processing 1-3 minutes
wound measurement software available
evaluation: around 5 minutes
not very portable
Not for sale to end users. Sale via licensed manufacturers / distributors.
Expected price: approx Ł15,000
Clinical Trial with Bradford Royal Infirmary, Dr. Rob Cameron
28. Laser Scanner: ‘VIVID 700’ Minolta Corporation Minolta VIVID 700
portable (to a degree…..)
small scanning volume: cube of 11 cm side length
exports 3D files for analysis, but no wound analysis
package available at present.
nice price….. ( Ł70,000)
not dedicated for wound measurement (lack of software)Minolta VIVID 700
portable (to a degree…..)
small scanning volume: cube of 11 cm side length
exports 3D files for analysis, but no wound analysis
package available at present.
nice price….. ( Ł70,000)
not dedicated for wound measurement (lack of software)
29. STRUCTURED LIGHT: ‘MAVIS’ University of Glamorgan, UK This slide shows the MAVIS instrument developed by our group at the UoG in operation.
MAVIS is the acronym for Measurement of Area and Volume Instrument System.
MAVIS is
portable within a hospital environment
measures wounds within 5 minutes
provides mini database and reporting facility
This slide shows the MAVIS instrument developed by our group at the UoG in operation.
MAVIS is the acronym for Measurement of Area and Volume Instrument System.
MAVIS is
portable within a hospital environment
measures wounds within 5 minutes
provides mini database and reporting facility
30. STRUCTURED LIGHT: ‘MAVIS-II’ University of Glamorgan, UK Further Development of MAVIS
In collaboration with Minolta (who supply the 3-D camera)
Fully portable system: 1.5 kg
Expected price: approx Ł 5000 (max)
Summer 2001Further Development of MAVIS
In collaboration with Minolta (who supply the 3-D camera)
Fully portable system: 1.5 kg
Expected price: approx Ł 5000 (max)
Summer 2001
31. SUMMARY Summary
Every wound documentation method needs a clear protocol that gets strictly adhered to.
In recent years a range measurements techniques have been developed. Competition should lead to a fall in prices. The current prices, the physical size of these devices, the time consumption, and the considerable computing skills required will mean that simple devices (rulers, tracings) will be with us for quite a while in the normal clinical setting and in the community. Watch out for digital photography.
Finally remember: no measurement method is perfect: In the case of size measurement: area: 5% precision achievable (strict protocoll), volume: 10% for well defined and well shaped wounds.Summary
Every wound documentation method needs a clear protocol that gets strictly adhered to.
In recent years a range measurements techniques have been developed. Competition should lead to a fall in prices. The current prices, the physical size of these devices, the time consumption, and the considerable computing skills required will mean that simple devices (rulers, tracings) will be with us for quite a while in the normal clinical setting and in the community. Watch out for digital photography.
Finally remember: no measurement method is perfect: In the case of size measurement: area: 5% precision achievable (strict protocoll), volume: 10% for well defined and well shaped wounds.
