An Infantryman's basic battlefield tool is his weapon. To effectively employ his weapon, marksmanship from the basics of rifle marksmanship to the advanced stages of target engagement must be mastered. This will greatly enhance the infantryman's capability to close with and destroy the enemy.. NOMEN
E N D
3. NOMENCLATURE OF THE M16
4. NOMENCLATURE OF THE M16
5. CHARACTERISTICS LMGAS
Lightweight, magazine-fed, gas operated, air-cooled, shoulder fired weapon
Max Ranges
3534m
550m (point target)
800m (area target)
6. CHARACTERISTICS
7. CHARACTERISTICS
8. Types of Ammunition M193 Ball
M855 Ball (Green Tip)
M196 and M856 Tracer (Red Tip)
M199 Dummy
M200 Blank (Violet Tip)
9. Filling and Stowing Magazines Filling
Individual
Each round place in separately
Speed Loader
10-round stripper clip.
Maximum of 30 rounds per magazine Stowing
Magazine Pouch
Load-Bearing Vest (LBV)
21. How to Determine the Weapon Condition Determine if a magazine is present
Ensure the rifle is on safe
Conduct a chamber check
Bring left hand back against the magazine well
Extend fingers of the left hand and cover the ejection port
22. Weapons Carries Tactical Carry
No immediate threat
Butt of Rifle on hip
Barrel pointing upward in safe direction
Alert Carry
Contact with enemy is likely
Butt of Rifle on shoulder
Barrel pointing to dirt Ready Carry
Contact with enemy is imminent
Butt of Rifle on shoulder
Barrel pointing directly ahead
23. IMMEDIATE ACTION -- Slap up on the Magazine
-- Pull the Charging Handle
-- Observe the Chamber
-- Release the Charging Handle
-- Tap the Forward Assist
-- Squeeze the Trigger
24. Function check M16A2, SAFE position (1) Pull charging handle to the rear and release.
(2) Place selector switch on SAFE.
(3) Pull the trigger; the hammer should not fall.
25. Function check M16A2, SEMI position (1) Place the selector on SEMI.
(2) Pull the trigger and hold to the rear; the hammer should fall.
(3) While holding the trigger back, pull the charging handle to the rear and release it.
(4) Release the trigger and pull it again; the hammer should fall.
26. Function check M16A2, BURST position (1) Place the selector on BURST.
(2) Pull the charging handle to the rear and release.
(3) Pull the trigger and hold to the rear; the hammer should fall.
(4) Pull the charging handle to the rear THREE times and release.
(5) Release the trigger and pull it again; the hammer should fall.
27. Task, Conditions and Standards TASK- Zero an M16A2 RifleCONDITIONS- On a 25-meter range, given an M16A2 rifle, 18 rounds of 5.56-mm ammunition, a 300-meter zero target, and sandbags for support.STANDARDS- Using 18 rounds or less, the soldier must battlesight zero his rifle by achieving five out of six rounds in two consecutive shot groups within the 4-centimeter circle. Bullets that break the line of the 4-centimeter circle will be used in evaluating the soldier's performance.
28. M16A2 Initial Front Sight Setting For 25 Meter Zero
29. M16A2 Initial Rear Sight Setting for 25Meter Zero
30. M16A2 Initial Sight Setting
31. Marksmanship Fundamentals The four fundamentals are:
Steady position
Aim
Breath control
Trigger squeeze
32. Steady Position A shooter must assume a comfortable, steady position in order to hit targets consistently.
The elements of a steady position include: Non-firing hand grip, rifle butt position, firing hand grip, firing elbow placement, non-firing elbow placement, stock weld, support, muscle relaxation, and natural point of aim.
33. Aiming Aiming involves correct site alignment, correct sight picture, and focusing on the front sight.
Once a shooter learns to aim correctly, he must do the same procedure every shot.
Accuracy is consistency; consistency is accuracy.
34. Breath Control During zeroing or slow fire on single targets, a shooter simply holds his breath momentarily and shoots.
The shot must be fired before any discomfort results or the lay of the rifle will be disturbed.
35. Trigger Control All of the fundamentals are important but, trigger control is the most critical!!!
It is also the fundamental that shooters perform incorrectly most often.
36. Shot-Group Analysis
37. Improper Trigger Squeeze
38. Shooter Error
39. Shot-Group Analysis
40. 25 Meter Zero The shooter fires two separate, three-round shot groups and numbers them.
Based on the shot groups and info provided on the target, the shooter computes the changes needed.
41. 25 Meter Zero Here the shooter needs to move the strike of his rounds down 2 clicks and to the left 10 clicks.
After the sight adjustment, 2 more 3-round groups are fired to confirm they are hitting center mass.
42. 25 Meter Zero
43. Zeroed By applying the four fundamentals and using shot group analysis, a shooter should have no problem achieving a good zero and moving on to becoming qualified with his rifle.
45. CLEAR the WEAPON Place the Weapon on SAFE
Remove the Magazine
Lock the Bolt Open
Check the Ejection Port and
Chamber for ammo
With Selector Lever on SAFE,
let the bolt go forward
46. DISASSEMBLY
47. DISASSEMBLY
48. CLEANING
49. CLEANING
51. INSPECT
52. REASSEMBLY (Reverse Order) Charge the weapon and place it on SAFE, pull the trigger. Hammer should NOT fall
Place the weapon on SEMI, pull the trigger and hold it to the rear. Hammer SHOULD fall. Charge the weapon, release the trigger and pull again. Hammer SHOULD fall
Place the selector lever on BURST. Charge the weapon, pull the trigger and hold to the rear, hammer SHOULD fall. Pull the charging handle to the rear three times and release. Release the trigger and pull again. Hammer SHOULD fall.
