NEW CONSTRUCTION TECHNOLOGY A proposal having opportunity to generate Rs 2,10,600 Cr. (US $468 Billion) the saving part only for construction Industry world wide every year “By Marketing New Construction Technology and issuing Licenses World Wide” for a technology which reduces the cost of construction by 36% (Patent Under Process) Mail.id ;email@example.com Innovation by- Suresh Chawla www.sureshchawla.com
INDIA HAD IT ALL • Indian mythology : In Mahabharta, Vishvakrama created “ Dwarika” in one night for Lord Krishna when he fled Mathura for fear of Jarasandh Raksha to save brahmins. • When Pandvas were separated from Duryodhana the barren land of Indraprastha was converted in to their beautiful capital in unbelievable time frame. • It looked like an epic and dream to me before innovation of my technology, but having innovated the technology • “when i found out that on third day, 1000s of families can be settled in 1000sof units of houses made in R.C.C which would last 100 years with electricity, sanitation and water supply in place. • It looked no surprise to me that technology to create long lasting structures in no time was in deed prevail ant in olden times in India. • (This technology is reincarnation of same technology)
NO BODY WILL EVER CONSTRUCT A HOUSE OR CARRY OUT ANY KIND OF R.C.C.CONSTRUCTIONS ON THIS EARTH USING PRESENT CONSTRUCTION TECHNIQUES, ONCE NEW CONSTRUCTION TECHNOLOGY IS MADE PUBLIC • WHY : • 1) When a house owner or a builder who wants to build a house or a multistory building or a Fly -over will see one floor of his dream houses/building which is going to last 100 years is ready in one single day cast in situ ¬ prefabricated that too at 36% lower in cost 2)With all Columns, Beams and Walls including internal tiles/ external stone – cladding etc complete pending curing & painting only 3) With all doors& window duly painted with all Fittings and Glass in place in single day 4) With all concealed electric conduits, all fire fighting and heating pipes in place, with all concealed water supply - pipes, sanitary, plumbing pipes etc in place and for that matter all concealed items in place . 5) With all concealed electrical, T.V. telephone, fire-fighting, heating, air-conditioning and all other kinds of wirings in place in single day. 6) With inside walls ready for POP in 24 hours in one option or left for curing the interior walls as well as exterior as per the period required
NEW TECHNOLOGY CONVERTS THE CONSTRUCTION INDUSTRY INTO MOST SIMPLE PROCESS ON EARTH • 7) Not only that but scaffolding out side the building which is required for entire building & for entire construction period is not required in this technology and in its place scaffolding for only one floor of whole multistory building is required at one time • 8) Not only that but all ornamental exteriors, domes, chajjas, recesses, balconies etc can be in place & cost of construction can be reduced drastically • 9) Not only that but the owner does: not require to look for any labor be it a mason or a plumber or a carpenter, a painter or an electrician or even a single laborer at his site of construction. • 10) Not only that but the technology is so simple that from a villager constructing a single room to a Contractor constructing Fly-Overs, Bridges Dams. Drains, Columns for Mass Transportation ,Water Tanks, Man Hole Covers, and what not will use this technology to save on cost, enormous time . “The cost over run will be a thing of past” • 11) Not only that but the design of the house is by architect and structure designer and not prefabricated or mass construction
NEW TECHNOLOGY CONVERTS THE CONSTRUCTION INDUSTRY INTO MOST SIMPLE PROCESS ON EARTH • 12) Not only that but for a pre -designed house which will now be available on web sites and though albums in workshops round the corner provided by leading corporate houses who will adopt the technology as industry, the owners will not require Architects and Structural Designers and other Consultants also. . Why any one on this earth will ever think of making his house or carry out any kind of civil construction on this earth using present technologieswhen one can avail this technology at much reduced cost i.e. 36% lower than present construction cost as explained here after and in shortest possible time required for all kinds of constructions be it: “Buildings, Bridges, elevated corridors for transport, fly-over's, roads, drainage, dams, water tanks , man hole covers etc.
SUPER FAST CONSTRUCTION TECHNOLOGY INVENTOR : SURESH CHAWLA INNOVATION : NEW PROCESS APPLICATION: ALL RCC CONSTRUCTIONS A : ALL WOODEN CONSTRUCTIONS PROSPECTS: WORLDWIDE INVENTOR DESIRES : SALE/ SHARING OF REVENUE MARKETING: ISSUE OF LICENSE & SELLING TECH
SUPER FAST CONSTRUCTION A revolution in construction industry is waiting to happen which will turn all present construction techniques upside down and obsolete
DISPLAY OF TECHNOLOGY. IF IT IS OK FOR ONE UNIT IS OK FOR MULTIPLE UNITS
DISPLAY OF TECHNOLOGY IF IT IS OK FOR ONE UNIT IT IS SAME FOR MUTIPLE UNITS
EVEN FLOATING R.C.C. CONSTRUCTIONS OF ALL KINDS CAN BE CREATED IN WATER AS WELL
POSSIBLE TO CREATE FLOATING R.C.C PORTS AT LEAST COST WITH OUT REQUIREMENT OF BACK FILLIG
DEMOSTRATION OF TECHNOLOGY CAN ALSO BE MADE ON DEMAND TECHNOLOGY HAS BEEN PRACTICALLY DEMONSTERATED BUT CAN BE INSTANTLY DEMONSTRATED TO WILLING PARTENERS WHO WANT TO MARKET THE TECHNOLOGY GLOBALLY WHICH HAS CAPACITY TO CHANGE THE CONSTRUCTION SECTOR FOR ALL TIMES TO COME IN TERMS OF COST AND TIME & AT THE SAME TIME BRING BILLIONS OF DOLLARS FROM SALE OF TECHNOLOGY
EXPERIENCE IN CONSTRUCTION SECTOR • As a builder, Suresh Chawla interfaced mechanical engineering with civil engineering to complete numerous projects at fastest speed. • Soon he became most favored class 1 contractor. • Having the surprising energy level and desire to produce fast results, he identified Exhibition Ground in Delhi where emergency works were the order of the day and International and domestic Exhibitions are held on regular basis. Full profile can be seen by visiting web site ---presentations at right top under head (projects executed) some of the mentionable projects are provide here after
EXPERIENCE IN CONSTRUCTION • Civil and interiors of National Museum Delhi 90 days Civil and interiors of Delhi High court 90 days • Civil and Interiors, Hotel Vasant continental Delhi 70 days • Dome type Cinema Theatre50 ft high,70ft Dia including interiors exteriors at APPU GHAR Delhi 6 Days(FASTEST BUILDING EVER MADEANY WHERE IN THE WORLD) • First Amusement Park of India in Delhi (APPU GHAR) 46 Days • Setting up of 11 amusement parks in various cities of India in 18 monthsOr on an average for each park 45 days each
Bihar Pavilion 3 storey building of approx. 12,000 sq ft area right from foundation to exteriors to interiors etc complete at Pragati Maidan-Delhi 40 days • UP Pavilion 5 storey building of approx 20,000 sq ft area right from foundation to exteriors To interiors etc complete at Pragati Maidan-Delhi 90 days • Construction of 12 buildings in engineering college in Raya choti (Andhra Pradesh) 180 days Construction of 5 floor school building Yamuna nagar(Haryana) 42 days
TECHNOLOGY Proposed Construction technology is using the same materials in a different process and IS NOT A PREFAB. It is cast at site in RCC using all existing construction codes and structural designs.
APPLICATIONS THIS TECHNOLOGY MAKES IT POSSIBLE TO CONSTRUCT • PERSONALIZED HOUSES, BUILDINGS • FLY OVERS, BRIDGES, DAMS, HYDEL PROJECTS • FOOTPATHS, DRAINAGES, SEWAGE & MAN HOLES ETC. • WATER STORAGE TANKS AND TREATMENT PLANTS • NUCLEAR PLANTS • STRUCTURES FOR ELEAVTED MASS TRANSPORT SYSTEMS • ALL KINDS OF RCC CONSTRUCTIONS IN SHORTEST POSSIBLE TIME AT ALMOST 25% LESS COST • THE TECHNOLOGY MAKES IT POSSIBLE TO CONSTUCT EVEN WOODEN HOUSES IN SHORTEST POSSIBLE TIME WHILE FOLLOWING ALL CODES OF CONSTRUCTIONS OF DIFFERENT REGIONS APPLICABLE AS IN CASE OF USA AND ELSEWHEE IN THE WOLRD
ADVANTAGES • Your Dream Houses, Multi-Story Buildings, Bridges, Flyovers and other Civil Structures made as per designs of your Architects, Structural Designers &Consultants in shortest possible time frame at lowest cost & with no cost over runs. Technology offers freedom to construct many floors at one time. • Don’t need to put up with Carpenters, Masons, Plumbers, Electricians, Workers and even Supervisors anymore. • More Earthquake resistant, longer life span constructions than brick work constructions which have 35 years of life where as R.C.C. Constructions have 100 years of life span at less cost as compared to present technologies. • No mass construction or similar designs as in prefabricated buildings. • The word delay for Mega Projects planned by Governments World wide will become “Past Tense” and cost over runs because of inflation and increase in cost of basic materials will become rare and projects planned by Governments will meet required “Schedules in Cost & Time Frames”
ADVANTAGES OF USING THIS TECHNOLOGY • Lot of companies will benefit from this technology like Steel & Cement Manufacturers, Truck Mounted Concrete Pump Manufacturers, Cement Concrete Mixing Plant Manufacturers, Batching Plant Manufacturers and Building Material Manufacturers etc. due to sudden spurt in demand for basic materials and machinery once technology is made public. • Corporate will latch on to the technology to convert construction sector in to an industry & provide constructions on web sites & through their net work of work shops around the world to provide machine finished constructions & provide a respect to the sector by providing their trade name to Constructions. Corporate will not only provide their names to the trade but Technology will open one more opening for Architects Structural Designers and Consultants to provide innovative designs to Corporate who will conduct competitions to extract best designs and constructions world wide. • Companies taking long time to construct wooden houses in USA will benefit in time cost, labor and cost over runs by using our technology which is suitable for wooden constructions as well.
OBJECTIVE • To limit time required for • Reinforcement binding • Scaffolding • Door window frames fixing • Concealed Conduits • Electric boxes • GI Pipes • CI Pipes • Rainwater Pipes • Traps To ZERO
TIME FRAME TECHNOLOGY OFFERS FOR VARIOUS KINDS OF CONSTRUCTIONS • EXAMPLE 2 • Fly- Over • Day zero- Order For fly-Over placed, upper layer of ground clearing starts • Day -15 Ground prepared, PCC Cast • Day -20 basic work complete, Concrete casting begins Day-22 Beams, slabs work starts Day -30-40 over fly over ready for Traffic
TIME FRAME TECHNOLOGY OFFERS FOR VARIOUS KINDS OF CONSTRUCTIONS • EXAMPLE 3 • Columns for Elevated Transport Day Zero- Order placed for all Columns Digging starts Day -15 - Digging complete, PCC in Position Day-16 - Concrete casting starts for as many Columns as, the capacity of Truck mounted Concreting Pumps
TECHNOLOGY TURNS TABLES * The advent of this technology will make present day method of construction redundant and obsolete *It converts the most tedious method of constructions to most simplest act on this planet.
OPTIONS ON INTERNET Now multinational companies engaged in development of software can also sell houses, buildings and all kinds of constructions online. The new technology opens one more sector for multinational companies not only for RCC constructions but wooden buildings as made in USA taking long time for each house to all such constructions world wide.
PRESENT CONSTRUCTION CYCLE DIAGRAM FOUNDATION CAST PRESENT TECHNOLOGY SHUTTERING & SCAFFOLDING REINFORCEMENT BOUND AT SITE REINFORCEMENT BOUND TO EXTENDED STEEL MEMBER CONSTRUCTION METHODS SHUTTERING & SCAFFOLDING DIGGING WALLS ERrECTED ELECTRICAL & PLUMBING WORK STARTS WALLS PLASTERED AGAIN
SUPER FAST CONSTRUCTION Progress Diagram STEP 2 STEP 1 STEP 3 Once ready with digging, construction team will reach with basic infrastructure, which can be inspected by architect, electrical, plumbing and other inspectors • Concreting starts once clearances from inspectors is obtained. • Basic structure with doors, windows, tiles, stone cladding i/c concealed water pipes, electrical wiring & conduits etc will be handed over by next day. • Place the order with workshop who has license to undertake this process of construction • Provide structural, electrical, plumbing architectural drawings • Start digging at your site
WHERE CONSTRUCTIONS WILL BE BUILT NOW • NOT ONLY HOUSES BUT ALL KINDS OF RCC CONSTRUCTIONS FROM NOW ON WILL BE CARRIED OUT IN SMALL AND BIG WORK SHOPS WHO WILL GET LICENSES FROM US OR OUR ASSOCIATE MARKETING COMPANY TO BUILD ALL KINDS OF CONSTRUCTIONS , BE IT FLY OVERS, BRIDGES, STRUCTURES FOR MASS TRANSPORT, WOODEN HOUSING SYSTEMS,DAMS, WATER STORAGE TANKS,NUCLEAR PLANTS ETC IN SHORTEST POSSIBLE TIME AT LOWEST COST AND WITH LEAST LABOR FORCE.
COMPARISON OF COST BETWEEN PRESENT AND PROPOSED TECHNOLOGY Context : India ASSUMPTIONS Basis for rates in market as on 1/05/11 CONSIDERING COSTS 1:2:4 (in INR) • CEMENT CONCRETE/cum 4500 • STEEL/ton 40000 • Bricks (1000) 3000 • Building materials current prices • Normal building 3 bedroom, 3 stories • Cost comparison up to basic structure
COMPARISON OF COST BETWEEN PRESENT AND PROPOSED TECHNOLOGY PRESENT TECHNOLOGY NORMAL CONSTRUCTIONS(Basic structure) A normal construction up to basic structure, 3 stories, involves: A) Basic Materials @ Rs 550per sq ft B) Labor @ Rs 150 per sq ft C) Supervision, over heads @ Rs 50 per sq ft -------------------------------- TOTAL Rs 750 per sq ft D) Cost overruns 10-15% Considering 12 months ( normal time ) Rs 80 average -------------------------- COST ESTIMATES Rs 830 per sq ft
COMPARISON OF COST BETWEEN PRESENT AND PROPOSED TECHNOLOGY PROPOSED TECHNOLOGY NORMAL COSTRUCTION • A) basic materials Rs 550 • B) labor and supervision Rs 60 ------------------------- Cost Rs 610 per sq ft • cost over runs considering max 20 days required up to three stories basic structure nil • COST ESTIMATES Rs 610 per sq ft • Saving = Rs 830-Rs 610 =Rs 220/sft or 36%
ANA LYSIS OF SAVINGS FROM PROPOSED TECHNOLOGY Following factors result in savings for proposed technology as compared to present technology • It is only labor , supervision and cost over runs which cause difference in costs. • The more the time the more labor, supervision and cost over run • The more the activities the more the labor cost PRESENT TECHNOLOGY • A) Labor 27% • B) supervision ,overheads 10% • C) Cost overrun (average) 11% ------------------------------------ TOTAL 48%
SAVINGS FROM PROPOSED TECHNOLOGY PROPOSED TECHNOLOGY • A) Labor cost due to less activities 9% • B) Supervision, over head savings 3% • c) Cost overrun due to less time nil --------------------- TOTAL 12% • SAVING 48-12 36% THERE WILL BE FURTHER SAVING BECAUSE NO PLASTER IS REQUIRED ON CONCRETE WALLS THERE WILL BE MORE SAVING BECAUSE OF LESS THICKNESS REQUIRED FOR R.C.C. WALLS AS COMPARED TO BRICK WALLS THESE FACTORS HAVE NOT BEEN CONSIDERED AT THIS STAGE.
COMPARISON OF COST BETWEEN PRESENT AND PROPOSED TECHNOLOGY • COST SAVINGS 36% SAVING IN OVERALL COST OF CONSTRUCTIONS RESULTING FROM ^ labor ^ supervision ^ cost overrun ^ no plaster reqd less thick ness of walls rqd • TIME SAVING 500 %
3-D Pie Chart Cost overrun saving 11% Supervision Saving 10% Labor& No plaster Saving -27% Time savings-500%
PROJECTED COST SAVINGS FOR THE CONSTRUCTION INDUSTRY WOLDWIDE (statistics for year 2010) ASSUMPTIONS: • 85 % of cement produced in the world goes for new constructions • 15% goes for repairs • 90% of cement used for new constructions is used for R.C.C. • 50% of structural Steel being used at present world wide as construction material for buildings, bridges and other civil structures for faster Construction at 30% higher cost than RCC will shift to RCC ,once our technology is released ( because of cost and time reduction) • Total consumption of cement for year 2010 is ( 3294 million Tones)
PROJECTED COST SAVINGS FOR THE CONSTRUCTION INDUSTRY WOLDWIDE • Total consumption of Steel for year 2010 world wide as 1257 million tones • Steel consumption for civil works as 50% of total consumption will be 628 million tones or say 600 million tones • Considering 120 Million tones of steel used at present as building materials at 30% higher cost for constructions will shift to RCC once our technology is made public • Considering cost of cement as 40% of cost of RCC constructions For mix of 1:2:4 (average mix) @ Rs 4500/cum (US$100 /cum) • Once our technology is made public, the use of brick work, block &stone work etc will become obsolete (because of cost, time, labor reduction & no requirement of plaster) • Considering 5% increase in volumes of construction every year till Year 2020
COST OF CONSTRUCTIONS WORLDWIDE (using costs in Indian rupee and converting in Dollar Terms) • (Cement prices have increased considerably since 2004) CEMENT, CONCRETE, COARSE SAND + LABOR • Consumption of cement in year 2010 3294 million tones • say 3200 million tones • or 3200000000000 kg • CONSIDERING 6.4 BAGS or 320kg of cement will produce 1 cu.m of R.C.C. =3200000000000/320 : TOTAL CONCRETE CU.M 10000000000 cu m • Cost of constructions • 10000000000 cu mtr x Rs 4500 per cum Rs 45000000000000 • or 4500000 crores • Or • (considering Rs 4500 crores as US$1 Billion • 4500000 /4500 =US$1000 Billion • Taking 75% for new constructions • the cost of R.C.C =US$750 Billion • Total cost of RCC world wide = US$ Billion 500 (A)
COST OF CONSTRUCTIONS WORLDWIDE (using costs in Indian rupee and converting in Dollar Terms) STEEL CONSUMPTION in RCC work • Steel prices have increase dramatically in last 7 years from Rs 16 per kg to Rs 40 per kg now for plain and twisted bars used in RCC • Any project started five years before and not completed till now has seen 100% increase in steel prices. • Time factor plays a very vital role in construction industry. • Here under we are considering only normal saving while taking consumption of average steel consumption. • 10000000000 cum of RCC @60 Kg Per cum/average= 600000000000 kg • 0r 50% of total world consumtion = 600 million tones • Cost of steel used taking basic • cost at Rs 40000 per tone • + Rs 2000 per tones as labor • + Rs 1000 per tone as wastage etc • Cost of steel used • =600000000 tones x Rs 43000/tone= Rs 25800000000000 or2580000cr/4500cr/billion • Or US $Billion 573 • Say US$570 billion • Taking 75% as new constructions the cost of steel used world wide will be US$ 427.5 billion or say US$ 430 Billion (B)
COST OF CONSTRUCTIONS WORLDWIDE(using costs in Indian rupee and converting in Dollar Terms) FORM WORK AND OTHER COSTS FOR RCC • Taking 10% as cost of form work, over head etc • COST OF FORM WORK OVER HEAD= • 750+430 =1180/10 US$ 118 BILLION • Say US$ 120 BILLION (C)
SAVING FOR PRESENT RCC CONSTRUCTIONS WORLDWIDE (using costs in Indian rupee and converting in Dollar Terms) D) SAVING FOR RCC CONSTRUCTIONS 35% of (A+B+C+D) or Of US$ 750 +430+120 = US$ Billion 1300 Saving world wide= 36%of 1300Billion = US$468 Billion
TOTAL SAVING TILL 2020WITH 5% INCREASE YEAR AFTER YEAR SAVING FOR YEAR 10-11 US $ Billion 468 • 11-12 US $ Billion 490 • 12-13 US $ Billion 515 • 13-14 US $ Billion 540 • 14-15 US $ Billion 567 • 15-16 US $ Billion 600 • 16-17 US $ Billion 630 • 17-18 US $ Billion 660 • 18-19 US $ Billion 693 • 19-20 US $ Billion 726 • -
MARKETING STRATEGY SUGGESTED • First of all we target big builders of all countries to sell the technology as well as to issue licenses to use the technology to get big chunk of money to begin with. • Second target could be one agency for each city of the world who could be made sole distributor for each city who in turn can appoint sub distributors for each locality to issue licenses to small workshop. • It will be for that distributor to monitor violations as fixed return can be fixed on each distributor. • For villages, we can fix district wise distributors for them to take care of each village or town in that district
Marketing Diagram PROPOSED MARKETING STRATEGY Purchase/sale Of technology Issue of licenses Sole distributorship Monitor piracy
BENEFITS TO ASSOCIATING COMPANY • There will be savings in construction cost to Company associating, if the company is in construction business • Company Associating with us will issue licenses for a license fee for the use of this technology • Considering the size of construction business the associating company can generate Billions by marketing new construction technology and issuing licenses
