slide1

Project: IEEE P802.15 Working Group for Wireless Personal Area Networks (WPANs)

Submission Title: 802.15.4f Task Group Closing Report for San Francisco, California

Date Submitted: July 16, 2009

Source: Mike McInnis, The Boeing Company

Contact: Mike McInnis, The Boeing Company

Voice: E-Mail: michael.d.mcinnis@boeing.com

Re: 802.15.4f Active RFID Closing Report for the July 2009 Session

Abstract: Closing Report for the Active RFID Session in San Francisco, California.

Purpose:This amendment defines a Physical Layer (PHY), and those Medium Access Control Layer (MAC) modifications required to support it, for Active Radio Frequency Identification (RFID) readers and tags. It allows for efficient communications with active RFID tags and sensor applications in an autonomous manner in a promiscuous network, using very low energy consumption (low duty cycle), and low PHY transmitter power. The PHY parameters are flexible and configurable to provide optimized use in a variety of active RFID tag operations including simplex and duplex transmission (reader-to-tag and tag-to-readers), multicast (reader to a select group of tags), uni-cast as in reader to a single tag, tag-to-tag communication, and multi-hop capability.

Notice: This document has been prepared to assist the IEEE P802.15. It is offered as a basis for discussion and is not binding on the contributing individual(s) or organization(s). The material in this document is subject to change in form and content after further study. The contributor(s) reserve(s) the right to add, amend or withdraw material contained herein.

Release: The contributor acknowledges and accepts that this contribution becomes the property of IEEE and may be made publicly available by P802.15.

Mike McInnis, The Boeing Company

slide2

IEEE 802.15.4f Active RFID

Closing Report

4th Meeting as a Task Group

San Francisco, California

July 16, 2009

Mike McInnis, The Boeing Company

802 15 4f par purpose
802.15.4f PAR Purpose

Paragraph from 802.15.4f Project Authorization Request (PAR) document.

5.4 Purpose of Proposed Standard:

To provide a standard for low cost, ultra low energy consumption, flexible and highly reliable communication means and air interface protocol for Active RFID and sensor applications. The air interface should be able to support a wide range of needs for which active RFID systems can be useful and enable improved performance and flexibility for future mass deployments of active RFID systems around the world.

Mike McInnis, The Boeing Company

slide4

IEEE 802.15.4f Active RFID Meeting Overview

  • Chair: Mike McInnis
  • Vice-Chair: Tim Harrington
  • Secretary: George Cavage
  • Six each meeting time slots were allocated during this session and one joint meeting time slot with 802.15.4e and 802.15.4g.
  • 3. Administrative meeting Documents during this session:
  • 0499-00 -Agenda-July-2009.xls
    • 0498-01 -Opening-Introduction-July-2009.ppt
    • 0559-00 -Active-RFID-Minutes-SFO-July-2009.doc
  • Presentations during this meeting session:
    • 0497-01 -Decawave-preliminary-PHY-proposal.ppt
    • 0500-00 -433 MHz PHY and MAC for TG4f preliminary proposal.ppt
    • 0513-00 -Ubisense preliminary PHY proposals for TG4f.ppt

Mike McInnis, The Boeing Company

tg4f meeting sessions this week
TG4f Meeting Sessions This Week

Mike McInnis, The Boeing Company

active rfid meeting achievements july 2009
Active RFID Meeting AchievementsJuly 2009
  • Heard three Call for Preliminary Proposal (CFPP) presentations in response to:
    • 802.15.4f Call-for-Preliminary-Proposals document.
      • https://mentor.ieee.org/802.15/dcn/09/15-09-0418-01-004f-call-for-preliminary-proposals.doc
    • Preliminary Proposal Presentations were optional during this meeting.
  • Discussed the 802.15.4 MAC as it pertains to 802.15.4f alternate PHYs and Application requirements.
  • Continued team building between the anticipated PHY proposers.
  • Final PHY Proposals are to be heard during the September 2009 meeting session in Hawaii as defined in the 802.15.4f Call for Preliminary PHY Proposal document. (0418-01)

Mike McInnis, The Boeing Company

draft 802 15 4f timeline
Draft 802.15.4f Timeline

July Plenary Meeting

Heard and Discussed Preliminary PHY Proposals and 802.15.4 MAC

September Interim meeting

Hear and Discuss PHY Proposals

November Plenary meeting

Vote on PHY Proposals

Mike McInnis, The Boeing Company

project meeting dates and locations http grouper ieee org groups 802 15 pub meeting plan html
Project Meeting Dates and Locationshttp://grouper.ieee.org/groups/802/15/pub/Meeting_Plan.html

Next Meeting

Mike McInnis, The Boeing Company

next tg4f meeting goals and agenda september 2009 in hawaii
Next TG4f Meeting Goals and AgendaSeptember 2009 in Hawaii
  • Note: Per the Call for Preliminary PHY Proposals document (0418-01), 802.15.4f PHY proposals are to be heard at the September 2009 meeting in Hawaii.
  • Hear response presentations to the Call For PHY Proposals document which was released at May 2009 meeting (document 0418-01)
  • Discuss the PHY proposals heard.
  • Continue to build consensus and collaboration between PHY proposers.
  • Hear any non-proposal presentations which are offered, time permitting.
  • Participate in joint 802.15.4e/f/g session to discuss 802.15.4 MAC enhancement for 802.15.4f applications and PHYs:
    • Main issue is ‘transmit only’ mode required by 802.15.4f.
  • Any other 802.15.4 MAC enhancement issues which need discussion.
  • Discuss next steps and the November 2009 meeting in Atlanta, GA.

Mike McInnis, The Boeing Company

slide10

Sign up for 802.15.4f Active RFID e-mail reflector

      • Sign-up at: http://grouper.ieee.org/groups/802/15/pub/Subscribe.html
      • Email reflector address is: STDS-802-15-4f@listserv.ieee.org
  • Next Meeting
    • September 21-24 in Hawaii.
      • Hilton Waikoloa Village, Big Island, HI
      • Note: Register ASAP to save big $$$
      • Registration fees for Hawaii are;
        • $600.00US Before 6pm Pacific Time (PT), Friday, July 31, 2009
        • $850.00US After July 31, 2009
        • $1150.00US After September 11, 2009.
    • Register for the next meeting at:
      • http://ieee802.facetoface-events.com/wireless

Mike McInnis, The Boeing Company
