  1. MDS Monitoring Software

  2. Contents • Introduction • User Interface • Service Personnel Interface • System Requirement • Demonstration

  3. Introduction

  4. Introduction • Smart Commander • Human to MDS system interface • 32 Outdoors • 48 indoors per indoors • Total1536 indoors • Monitor and control the MDS system both indoors and outdoors • User and Service Personnel Interface

  5. Introduction Smart Commander Layout RS485 Gateway RS232 Computer Indoor units Outdoor units Centralize Control

  6. User Interface

  7. User Interface Indoor Monitoring and Control Interface

  8. User Interface System Monitoring and Control Interface

  9. Single Control: Select a indoor unit only Select many indoor units Multiple Control: All the indoor units in the system Group Control: Features • Type of Control

  10. Select “ ” or “ ”, can turn on or close the units Click “ ” or “ ”, can adjust the set temperature Features • Area of Control • ON/OFF • Temperature Setting

  11. Features • Area of Control (…continue…) • Operating Model (Cool, Heat, Dry or Fan) • Air Swing (Not applicable for MCC model) • Fan Speed • Sleep Mode • Handset Lock Function Select mode (must select) Select fan speed: (must select) Select assistant functions:

  12. Features • Icon for indoor/outdoor unit • Basic control in “Indoor Monitor” page

  13. Features • Group Setting with 7 days programmable timer

  14. Features • Customize grouping with 7 days programmable timer

  15. Features • Error Code

  16. Service Personnel Interface

  17. Service Personnel Interface

  18. Available Data - OD Cooling, Heating, Defrost, Stop Single, Master, Slave Display OD program OD output capacity (Include Slave) Tsh_out: OD superheat Digital compressor output % OD Fan: Stop, Low, High HS: High Pressure (bar) LS: Low Pressure (bar) Heating electronic expansion valve Subcool electronic expansion valve 4-way valve (Heatpump model) Bypass way vale

  19. Available Data - OD TH1: Discharge air temp TH2: The 1st condenser entering temp TH3: The 1st condenser middle temp TH4: The 2nd condenser entering temp TH5: The 2nd condenser middle temp TH6: Entering water temp TH7: Heating water temp TH8: Outdoor temp TH9: Temp before subcool TH10: Temp after subcool TH11: Subcool loop exit temp TH12: Suction temp Sensor is unavailable

  20. Refrigerant Diagram & Sensor Location Outdoor Address Outdoor Model Red Line: Heating Green Line: Cooling / Dry Black Line: Stop Sensor location

  21. Indoor Control and Sensor Reading Indoor Data: Type of indoor and model Tr: Return Air Temperature To: Coil Outlet Temperature Tm: Coil Middle Temperature Ti: Coil Inlet Temperature Ts: Set Temperature EXV: Indoor EXV Opening Indoor address

  22. Indoor Control and Sensor Reading Click “Back Page” or “Next Page”, the page will turn up or down Click “Up” or “Down”, ID address number will move up or down

  23. Indoor Control and Sensor Reading • Click “Ctrl” to change indoor setting • Choose optional parameters to control single unit • Optional mode: Stop, Cooling, Heating, Dry, Fan • Fan Speed: Low, Medium, High & Auto • Assistant function: Aux heater, Swing & Lock

  24. System Requirement

  25. CPU : 800MHz and above • Memory : 256MB RAM or Higher • Hard Drive : 4G or higher for hard disk space • OS : Windows 2000/XP • Resolution : 1024 x 768 • Monitor : Larger than 15 inch, & 17 inch is recommended • Serial port & USB port available System Requirements

  26. Demonstration

  27. The End
