resistive circuits
Resistive Circuits
  • Resistors in series
  • Resistors in parallel
  • Voltage divider
  • Current divider
  • The bridge
electrical resistance
Electrical resistance

Resistor’s obey Ohm’s Law:

V = I R

The voltage “drop” across a resistor is linearly proportional

to the current passing through the resistor

the bridge
The bridge

The bridge is “balanced”

when the ammeter reads zero

  • If ammeter current = 0, I1 = I3 and I2 = Ix
  • The points A and B are at the same potential
  • So I3R3 = IxRx and I1R1 = I2R2
classwork 1
Classwork #1

Find the total current emitted by the voltage source
