ncar command language ncl

NCAR Command Language - NCL

Juli Rew

CISL

SOARS, June 4, 2008

what we will study
Overview of NCL

Strategies for Survival

Work with Example Programs

What We Will Study
what is ncl
NCAR Command Language is a complete programming language for processing data and producing high-quality 2D graphics

NCL commands can be run at the command line, or they can be placed in batch scripts

What is NCL?
ncl history
NCL is built on top of NCAR Graphics, which was originally written in Fortran

NCAR Graphics was re-written in object-oriented form, and NCL works with graphical “objects”

Thanks to Mary Haley of the CISL Visualization and Technology Section for much of the training information given here

NCL History
why use ncl
Freely available

Easier to use than conventional programming

Competes well with expensive products such as IDL

Versatile - it can accept and output data in a variety of formats

Produces publication-quality graphics

Why Use NCL?
strategies for survival
NCL has so many features that it can take a lot of time to master

NCL has around 800 functions

Before writing any new NCL code, look at the downloadable examples to see if one fits

GSUN tutorialhttp://www.ncl.ucar.edu/Document/Manuals/Getting_Started/

GSUN line-by-line exampleswww.ncl.ucar.edu/Document/Manuals/Getting_Started/examples.shtml

Strategies for Survival
strategies for survival cont
Use the gsn and csm libraries

Documentation is available online at:http://www.ncl.ucar.edu/

Help from fellow users by joiningncl-talk@ucar.edu

Subscribe athttp://mailman.ucar.edu/mailman/listinfo/ncl-talk

Support: Mary Haley (haley@ucar.edu, ML 35)

Strategies for Survival, cont.
ncl syntax
begin/end - to start/end scripts (optional)

; - Comment

@ - Attribute, e.g.,temperature@units = “Degrees C”

Operators like Fortran - + - *, .le., .lt., etc.

All parameters are passed by reference (as in Fortran)

NCL Syntax
arrays
Indexes start at 0 (similar to C)

1D, integer: a = (/1,2,3/)

2D, float: b = (/ (/1.1, .01/), /(.001,.0001/) /)

Whole-array syntax is like Fortrana=ba*b (more efficient than looping to copy array)

Arrays
syntax cont
Dimensions can be named:temperature!0 = “frtime”temperature!1 = “lat”temperature!2 = “lon”

Strings - enclosed in double quotes

Syntax, cont.
syntax cont11
Coordinate variables- 1D arrays with same name and size as the dimensions they are assigned to- Represent data coordinates for each index of a named dimension- Must be monotonically increasing/decreasingtemperature&frtime = forecast timestemperature&lat = lat_pointstemperature&lon = lon_points

Coordinate subscriptstemperature (0,{20:60},{-95:-120})

Syntax, cont.
graphics
We will emphasize graphics features here

Some examples of input and output to/from ASCII text and netCDF data files

Graphics
minimum steps needed to create a plot
Load necessary libraries

Open “workstation” to send graphics to

Change the color map (optional)

Set plot resources (optional)

Draw the graphics

Minimum Steps Needed to Create a Plot
1 load the necessary libraries
load "$NCARG_ROOT/lib/ncarg/nclscripts/csm/gsn_code.ncl"

load "$NCARG_ROOT/lib/ncarg/nclscripts/csm/gsn_csm.ncl”

First library contains “generic” interfaces and supplemental routines

Second library contains gsn_csm interfaces that use CSM conventions. Load order is important.

CSM conventions are accepted ways to label data, e.g., units

1. Load the Necessary Libraries
slide15

automatic subtitles

contour line labels

tickmarks out & lat/lon labels

informational label

automatic labelbar

“basic” interface

“metadata aware” interface

2 open graphics workstation
Can be PostScript (PS or EPS), PDF, X11 window, or NCAR CGM (NCGM)

Has a default color map associated with it, but you will probably want to change this (more later)

Can have up to 15 multiple workstations open

2. Open graphics “workstation”

wks = gsn_open_wks(“x11”,”test”) ; x11 window

wks = gsn_open_wks(“ps”,”test”) ; “test.ps”

wks = gsn_open_wks(“eps”,”wrf”) ; “wrf.eps”

wks = gsn_open_wks(“pdf”,”slp”) ; “slp.pdf”

3 change the color map opt l
Do this before drawing anything to the frame.

If you use the same color map a lot, can put in “.hluresfile” (more later)

Can use one of the other 40+ ones, or create your own.

If you don’t change the color map, here’s what you’ll get…

3. Change the color map (opt’l)

gsn_define_colormap(wks,”rainbow”)

default color table yuck

index 0 is the background color

index 1 is the foreground color

Pick a better color table…

or create your own

http://www.ncl.ucar.edu/Document/Graphics/color_table_gallery.shtml

http://www.ncl.ucar.edu/Document/Graphics/create_color_table.shtml

Default color table (yuck)
4 set optional resources
Resources are the heart of your NCL graphics code.

There are over 1,400 resources!

Resources are grouped by object type.

There are 11 “graphical” objects: contours, labelbars, legends, maps, primitives, streamlines, text strings, tickmarks, titles, vectors, XY plots

4. Set optional resources
detour anatomy of a resource
Starts with 2 or 3 lower-case letters based on object it is associated with. Some examples:

“xy” - XY Plots “cn” - Contour plots

“vc” - Vector plots “ti” - Titles

“tm” - Tickmarks “gsn” - special resources not associated with any object

Made up of full words with first letter of word capitalized:

“xyLineColor”, “cnFillOn”, “tiMainString”, “vcRefMagnitudeF”, “gsnMaximize”

Some have an “F” on the end to indicate a floating point resource: “xyLineThicknessF”

Detour: Anatomy of a resource
slide21
Resources are set by attaching them as attributes to an NCL logical variable:

res = True

res@mpMinLatF = 30 ; decimal not necessary

Most have default values.

There are many types:

res@tiMainString = “This is a title”

res@tmXBLabelFontHeightF = 0.01

res@cnLineLabelsOn = True

res@xyLineColors = (/5,7,11/)

res@xyLineColors = (/“red”, “green”, “blue”/)

Anatomy of a resource (cont’d)

http://www.ncl.ucar.edu/Document/Graphics/Resources/

5 draw the graphics
Call one of the gsn_csm_xxxxx functions from the second library we loaded.

The general format is:

plot = gsn_csm_contour(wks,data,res)

plot = gsn_csm_vector(wks,u,v,res)

plot = gsn_csm_contour_map(wks,data,res)

plot = gsn_csm_pres_hgt(wks,data,res)

5. Draw the graphics

http://www.ncl.ucar.edu/Document/Graphics/Interfaces/

now for some ncl graphics code examples
NCL scripts that follow can be downloaded from the web:Now for Some NCL Graphics Code Examples

http://www.ncl.ucar.edu/Training/Workshops/Scripts/

Scripts have names like xy1a.ncl, xy1b.ncl, …

The first one is usually one with no resources set, and each subsequent script adds a few more resources.

running ncl
setenv NCARG_ROOT ~/ncl-4.2.0.a034

Go to example NCL scripts directory:cd SOARS/NCL

To run these scripts:ncl xy1a.ncl

Let’s look at what’s in our first script using vi:vi xy1a.ncl

Running NCL
example xy1b ncl gsn csm y
Line color changed

(using color index values)

Default color map used

Resource introduced:

xyLineColor - sets curve color

Example xy1b.nclgsn_csm_y
example xy1c ncl gsn csm xy
X values added

Line color changed (using named color)

Line thickness increased

“long_name” attributes set

Resource introduced:

xyLineThicknessF - sets line thickness

Example xy1c.nclgsn_csm_xy
example xy1d ncl gsn csm xy
Axes limits changed

Resources introduced:

trYMinF, trYMaxF, trXMinF, trXMaxF - sets mins and maxes for X and Y axes (transformation resources)

These resources can also apply to contour, vector, and streamline plots

Example xy1d.nclgsn_csm_xy
example xy1e ncl gsn csm xy
Dash pattern set for curve

Title resources set

Resources introduced:

xyDashPattern - sets dash pattern for curve (17 available)

tiMainString, tiXAxisString, tiYAxisString - sets strings for axes and main title, can also be used for contour, vector, etc, plots

If have both long_name attributes and tiX/YString set, ti* resources will take effect

Example xy1e.nclgsn_csm_xy
example xy1f ncl gsn csm xy
Explicitly set the bottom tickmark labels

Resources introduced:

tmXBMode, tmXBValues, tmXBLabels - sets strings for bottom tickmarks

Note about tickmark resources: all four sides of the axes have their own set of tickmarks, for example:

tmYLMode (Y left), tmYRMode (Y right), tmXTMode (X top)

Example xy1f.nclgsn_csm_xy
example rose 1 ncl
Generating some bogus wind data

Each array entry has two components: wind speed and wind direction

There is a special function for creating wind roses, called WindRoseBasic

Data will be written to an ASCII file

This example online athttp://www.ncl.ucar.edu/Applications/rose.shtml

Example rose_1.ncl
example rose 1a ncl
Now we are reading our data from an ASCII file called “Bogus.dat” that we created previously

Recall that there are two components to each array entry

Example rose_1a.ncl
example contour ncl
This example reads from a netCDF file and contours the temperature fields

Fourth plot uses a predefined color table; seewww.ncl.ucar.edu/Document/Graphics/color_table_gallery.shtml

Original example online at:www.ncl.ucar.edu/Document/Manuals/Getting_Started/Examples/gsun02n.shtml

Example contour.ncl
animation
Animate NCL image files using idt (part of NCL)

Movies: Save series of images to Postscript files. Convert images to mpg using “convert” utility of ImageMagick

Or use utility such as ncview to view netCDF data file

Example movie:http://www.cisl.ucar.edu/docs/hpc_modeling/graphics.jsp

Animation
more training available
NCL Workshop this summer July 8-11

Register by July 1

Info:http://www.ncl.ucar.edu/Training/Workshops/

More Training Available
