biztalk 2009 performance characteristics on hyper v and physical platforms

BizTalk 2009: Performance Characteristics on Hyper-V and Physical Platforms

Ewan Fairweather & Paolo Salvatori

Customer Advisory Team

Microsoft

session objectives

Quantify BizTalk Server 2009 performance vs. BizTalk Server 2006 R2

Quantify performance of BizTalk Server 2009 on “Hyper-V”

Provide guidance on how to effectively performance test BizTalk 2009

Session Objectives
session agenda
Background

Goals

Use cases

R2 vs. 2009 Performance Comparison

Optimizing platform

Optimizing application design

Hyper-V Performance

Conclusion

Session Agenda
csd cx field engagement teams
CSD CX Field Engagement Teams

CX Field Engagement Teams

Institutionalized services delivered by specialized product team to support field and partner resources in the sale, delivery and on-going support of BizTalk projects

Field PM

Customer Advisory Team

Customer Response Engineering

  • Opportunity development
  • Sales Assistance
  • Readiness and Training
  • POC, Pilot
  • Virtual TS team
  • ADS
  • District Planning
  • Reactive services
  • Proactive Services
  • Architecture Design Review
  • Operational Readiness Review
  • Performance and Stability Review
  • Field Services Enablement
  • Key Learnings
  • Product Escalations
  • QFE & DCR
  • Service Packs
  • Beta Support
  • Serviceability

Field and Partner Resources

MCS, PFE,

Partners, Virtual TS

TS & SSP

Partners, Virtual TS

CSS,

Premier Field Engineering, Partners

4

field services enablement

All Guides are published to:

MSDN, Download Center

End to end samples:

Sample application

BizUnit scripts

LogParser scripts

Visual Studio Load Tests

Field Services Enablement

Product Release Cycle

Beta

RTM

RTM + 90

CAT & UE

4

Deliver ADR to TAP Customers

Enterprise Customer Engagements

Deliver MSDN Operational Guidance

2

1

Performance and Hyper-V Boot Camp

Deliver MSDN Hyper-V Guidance

3

Denotes investment

Deliver MSDN Performance Guidance

Denotes delivery

assessing application performance

The usual story

We all know testing is important for every solution

Testing is neglected

This is a problem

Solutions using BizTalk tend to be business critical and tolerate little downtime

Poor testing increases the risk profile of your project

This runs the risk of huge technical and political problems

Our labs have shown you can double performance if you are careful

Assessing Application Performance
session agenda7
Background

Goals

Use cases

R2 vs. 2009 Performance Comparison

Optimizing infrastructure

Optimizing application design

Hyper-V Performance

Conclusion

Session Agenda
biztalk 2009 performance lab goals

Technical Goals:

Quantify BizTalk Server 2009 (2009) vs. BizTalk Server 2006 R2 (R2)

Quantify performance of BizTalk Server 2009 on “Hyper-V”

Use Case 1:

Logical Ports WCF Orchestration scenario

Use Case 2:

Inline Sends Orchestration Scenario

Conditions:

Perform optimizations on 2009, R2, Hyper-V

Determine delta of:

Throughput # of calls within 8 hours

Latency

Identical infrastructure for all platforms

Apply infrastructure optimizations first, then application optimizations

BizTalk 2009 Performance Lab Goals
session agenda9
Background

Goals

Use cases

R2 vs. 2009 Performance Comparison

Optimizing infrastructure

Optimizing application design

Hyper-V Performance

Conclusion

Session Agenda
inline sends and logical ports
Inline Sends and Logical Ports

Logical Port Orchestration

Vs.

Inline Sends

Orchestration

code walk through

Code Walk-Through

Demo

Inline Sends and Logical Ports examples

session agenda12
Session Agenda
  • Background
  • Goals
  • Use cases
    • R2 vs. 2009 Performance Comparison
      • Optimizing platform
      • Optimizing application design
    • Hyper-V Performance
    • Conclusion
platform optimizations

They are grouped into the following categories:

Platform Optimizations

SQL Server Optimizations: General (all SQL Servers)

SQL Server Optimizations: BizTalk Databases

BizTalk Optimizations

If appropriate:

SQL Server Optimizations: Custom Databases

Platform Optimizations
optimizing platform results summary

~27% throughput improvement R2

~77% throughput improvement 2009

*Excessive dehydration was occurring, dehydration settings were non-optimal for 64 bit host

~25% latency improvement R2

~45% latency improvement 2009

Optimizing Platform Results Summary

1

2

3

4

7

8

5

6

troubleshooting dehydration

Counters to use:

Process\Virtual Bytes VirtualMemoryThrottlingCriteria

Process\Private Bytes PrivateMemoryThrottlingCriteria

Troubleshooting Dehydration

1

2

optimizing dehydration
Default

<xlangs>

<Configuration MaxThreshold="1800" MinThreshold="1" ConstantThreshold="-1">

<Dehydration>

<VirtualMemoryThrottlingCriteriaOptimalUsage=“900" MaximalUsage=“1300" IsActive=“true" />

<PrivateMemoryThrottlingCriteriaOptimalUsage="700" MaximalUsage="1000" IsActive="true" />

<PhysicalMemoryThrottlingCriteriaOptimalUsage="700" MaximalUsage="1000" IsActive="false" /> </Dehydration>

</Configuration>

 </xlangs>

Optimized

<xlangs>

<Configuration MaxThreshold="1800" MinThreshold="1" ConstantThreshold="-1”>

<Dehydration>

<VirtualMemoryThrottlingCriteriaOptimalUsage="6000" MaximalUsage="6300" IsActive="true" />

<PrivateMemoryThrottlingCriteriaOptimalUsage="700" MaximalUsage="1000" IsActive="true" />

<PhysicalMemoryThrottlingCriteriaOptimalUsage="700" MaximalUsage="1000" IsActive="false" /> </Dehydration>

</Configuration>

 </xlangs>

Optimizing Dehydration
dehydration optimization summary
Dehydration Optimization Summary

1

2

3

4

5

7

6

  • Tuning dehydration settings on 64 bit host:
    • Improved throughput by 27% (R2)
    • Improved throughput by 33% (2009)
session agenda22
Background

Goals

Use cases

R2 vs. 2009 Performance Comparison

Optimizing platform

Optimizing application design

Hyper-V Performance

Conclusion

Session Agenda
session agenda24
Background

Goals

Use cases

R2 vs. 2009 performance comparison

Optimizing platform

Optimizing application design

Hyper-V Performance

Conclusion

Session Agenda
hyper v architecture

VHD - single file sits on root NTFS volume

Fixed, Dynamic, Differencing

Pass-through – exclusive disk access to guest

Root Partition

Child Partition

Child Partition

Server

Server

VSPs

VSPs

I/OStack

I/OStack

I/OStack

OS Kernel Enlightenments (WS08+)

Drivers

VSCs

VSCs

VMBus

VMBus

VMBus

Shared Memory

Hypervisor

Devices

Processors

Memory

Hyper-V Architecture

1

3

2

4

5

biztalk virtualization licensing

License required for each physical processor

License for each virtual processor in each virtual operating system

Exception: BizTalk Enterprise Edition

License for the number of physical processors in the server

Enables unlimited Virtual Processors

http://www.microsoft.com/biztalk/en/us/pricing-licensing-faq.aspx

BizTalk Virtualization Licensing
physical biztalk 2009 vs hyper v biztalk 2009
Physical BizTalk 2009 vs. Hyper-V BizTalk 2009

Comparison Tier

Vs.

  • Physical and Hyper-V BizTalk Servers part of the same Group
slide28
Hyper-V provides ~87% throughput*

Hyper V ~15% worse latency*

*Note: Calculated from Logical Ports Test

Hyper-V Results To Complete

1

2

3

4

8

5

7

6

slide29

Virtual Processor Allocation

1 to 1 Mapping

Overload Scenario

1

2

BizTalk Server

BizTalk Server

BizTalk Server

BizTalk Server

BizTalk Server

BizTalk Server

BizTalk Server

BizTalk Server

Virtual Processors

Virtual Processors

Virtual Processors

Virtual Processors

Virtual Processors

Virtual Processors

Virtual Processors

Virtual Processors

0

0

0

0

0

0

0

0

1

1

1

1

1

2

3

1

2

3

Logical Processors

Logical Processors

0

0

processor lessons learned

To measure Guest processors:

\Hyper-V Hypervisor Virtual Processor(*)\% Guest Run Time

\Hyper-V Hypervisor Virtual Processor(*)\% Total Run Time

To measure Physical processors:

\Hyper-V Hypervisor Logical Processor(*)\% Total Run Time

To measure Host processors:

\Hyper-V Hypervisor Root Virtual Processor(*)\% Total Run Time

Processor Lessons Learned
disk lessons learned

For VHDs use:

<RootPartition>\Logical Disk(*)\Avg. sec/s

<RootPartition>\Logical Disk(*)\Avg. sec/Write

<Guest>\Logical Disk(*)\Avg. sec/Read

<Guest>\Logical Disk(*)\Avg. sec/Write

For PassThrough Disk Analysis use:

“Hyper-V Virtual Storage Device” counters

xPerf Tool http://msdn.microsoft.com/en-us/library/dd871252.aspx

Disk Lessons Learned
pass through disk perf
Pass-Through Disk Perf

* Other factors such as SAN performance could have been a factor

disk lessons learned33

Use PassThrough disks for high disk I/O:

BizTalk MessageBox Database

BizTalk Tracking Database

BizTalk File Adapter

%temp directory if BizTalk is streaming large files

Disk Lessons Learned
memory lessons learned

Virtual machines require non-paged memory (physical memory)

Ensure you have enough physical memory on both the host and guest computers

Use Traditional Counters:

<RootPartition>\Memory\Available Mbytes

<Guest>\Memory\Available Mbytes

<RootPartition>\Memory\Pages/sec

<Guest>\Memory\Pages/sec

Memory Lessons Learned
network lessons learned

For high network I/O:

Use a 1:1 mapping of physical to virtual network adapters

For measuring network adapters use:

<RootPartition>\Network Interface

Bytes Total Per Second

Output Queue Length

<RootPartition>\Hyper-V Virtual Network Adapter

Bytes Per Second

<RootPartition>\Hyper-V Virtual Switch

Network Lessons Learned
msdn http msdn microsoft com en us library cc558617 aspx
MSDN

http://msdn.microsoft.com/en-us/library/cc558617.aspx

BizTalk Server Performance Optimization Guide
helpful tools

BizTalk BPA 1.2

PerfMon

LoadGen

BizUnit

Log Man

Relog

Log Parser

PAL

SQLIO

BizTalk Orchestration Profiler

Helpful Tools
why tune biztalk now more than ever

Reduce costs and expenses

Win market share from expensive competitors

Optimize to do more with less!

Delight our customers

Why Tune BizTalk Now - More than Ever?
resources

BizTalk Server 2006: Managing a Successful Performance Lab

http://msdn2.microsoft.com/en-us/library/aa972201.aspx

Scaling Your Solutions

http://msdn2.microsoft.com/en-us/library/aa561567.aspx

Configuration Parameters that Affect Adapter Performance

http://msdn2.microsoft.com/en-us/library/aa561380.aspx

Persistence and the Orchestration Engine

http://msdn2.microsoft.com/en-us/library/aa547090.aspx

Troubleshooting MessageBox Latency Issues

http://msdn2.microsoft.com/en-us/library/aa561709.aspx

Performance Tips and Tricks

http://msdn2.microsoft.com/en-us/library/aa560694.aspx

Rule Engine Configuration and Tuning Parameters

http://technet.microsoft.com/en-us/library/aa548008.aspx

Performance Considerations When Using the Rule Engine

http://msdn2.microsoft.com/en-us/library/aa952929.aspx

Resources
filegroup resources

BizTalk Server Database Optimization

http://msdn.microsoft.com/en-us/library/bb743398.aspx

Understanding Files and Filegroups

http://msdn2.microsoft.com/en-us/library/ms189563.aspx

How to: Add Data or Log Files to a Database (SQL Server Management Studio)

http://msdn2.microsoft.com/en-us/library/ms189253.aspx

How to: Move an Existing Index to a Different Filegroup (SQL Server Management Studio)

http://msdn2.microsoft.com/en-us/library/ms175905.aspx

Physical Database Files and Filegroups

http://msdn.microsoft.com/en-us/library/ms179316(SQL.90).aspx

Working with tempdb in SQL Server 2005

http://www.microsoft.com/technet/prodtechnol/sql/2005/workingwithtempdb.mspx

Optimizing Server Performance Using I/O Configuration Options

http://msdn2.microsoft.com/en-us/library/ms189892.aspx

Filegroup – Resources
slide42

© 2008 Microsoft Corporation. All rights reserved. Microsoft, Windows, Windows Vista and other product names are or may be registered trademarks and/or trademarks in the U.S. and/or other countries.

The information herein is for informational purposes only and represents the current view of Microsoft Corporation as of the date of this presentation. Because Microsoft must respond to changing market conditions, it should not be interpreted to be a commitment on the part of Microsoft, and Microsoft cannot guarantee the accuracy of any information provided after the date of this presentation. MICROSOFT MAKES NO WARRANTIES, EXPRESS, IMPLIED OR STATUTORY, AS TO THE INFORMATION IN THIS PRESENTATION.
