Presentation Transcript

  1. ME 429Introduction to Composite Materials Dr. Ahmet Erkliğ 2005-2006 FallSemester www1.gantep.edu.tr/~erklig/me429/introduction.ppt, 13 Dec 2010

  2. Composite materials – Introduction • Definition: any combination of two or more different materials at the macroscopic level. OR • Two inherently different materials that when combined together produce a material with properties that exceed the constituent materials. • Reinforcement phase (e.g., Fibers) • Binder phase (e.g., compliant matrix) • Advantages • High strength and stiffness • Low weight ratio • Material can be designed in addition to the structure

  3. Applications • Straw in clay construction by Egyptians • Aerospace industry • Sporting goods • Automotive • Construction

  4. Matrix phase/Reinforcement Phase Metal Ceramic Polymer Metal Powder metallurgy parts – combining immiscible metals Cermets (ceramic-metal composite) Brake pads Ceramic Cermets, TiC, TiCN Cemented carbides – used in tools Fiber-reinforced metals SiC reinforced Al2O3 Tool materials Fiberglass Polymer Kevlar fibers in an epoxy matrix Elemental (Carbon, Boron, etc.) Fiber reinforced metals Auto parts aerospace Rubber with carbon (tires) Boron, Carbon reinforced plastics Types of Composites MMC’s CMC’s PMC’s Metal Matrix Composites Ceramic Matrix Comp’s. Polymer Matrix Comp’s

  5. Costs of composite manufacture • Material costs -- higher for composites • Constituent materials (e.g., fibers and resin) • Processing costs -- embedding fibers in matrix • not required for metals Carbon fibers order of magnitude higher than aluminum • Design costs -- lower for composites • Can reduce the number of parts in a complex assembly by designing the material in combination with the structure • Increased performance must justify higher material costs

  6. Types of Composite Materials There are five basic types of composite materials: Fiber, particle,flake, laminar or layered and filled composites.

  7. 1-D gives maximum strength in one direction. 2-D gives strength in two directions. Isotropic gives strength equally in all directions. A. Fiber Composites In fiber composites, the fibers reinforce along the line of their length. Reinforcement may be mainly 1-D, 2-D or 3-D. Figure shows the three basic types of fiber orientation.

  8. Inherent fiber strength, Fiber length, Number of flaws Fiber shape The bonding of the fiber (equally stress distribution) Voids Moisture (coupling agents) Compositestrength depends on following factors:

  9. B. Particle Composites • Particles usually reinforce a composite equally in all directions (called isotropic). Plastics, cermetsandmetals are examples of particles. • Particles used to strengthen a matrix do not do so in the same way as fibers. For one thing, particles are not directional like fibers. Spread at random through out a matrix, particles tend to reinforce in all directions equally. • Cermets (1)Oxide–Based cermets (e.g. Combination of Al2O3 with Cr) (2)Carbide–Based Cermets (e.g. Tungsten–carbide, titanium–carbide) • Metal–plastic particle composites (e.g. Aluminum, iron&steel, copper particles) • Metal–in–metal Particle Composites and Dispersion Hardened Alloys (e.g. Ceramic–oxide particles)

  10. C. Flake Composites - 1 • Flakes, because of their shape, usually reinforce in 2-D.Two common flake materials are glass and mica. (Also aluminum is used as metal flakes)

  11. C. Flake Composites -2 • A flake composite consists of thin, flat flakes held together by a binder or placed in a matrix. Almost all flake composite matrixes are plastic resins. The most important flake materials are: • Aluminum • Mica • Glass

  12. C. Flake Composites -3 Basically, flakes will provide: • Uniform mechanical properties in the plane of the flakes • Higher strength • Higher flexural modulus • Higher dielectric strength and heat resistance • Better resistance to penetration by liquids and vapor • Lower cost

  13. D. Laminar Composites - 1 Laminarcomposites involve two or more layers of the same or different materials. The layers can be arranged in different directions to give strength where needed.Speedboat hulls are among the very many products of this kind.

  14. D. Laminar Composites - 2 • Like all composites laminar composites aim at combining constituents to produce properties that neither constituent alone would have. • In laminar composites outer metal is not called a matrix but a face. The inner metal, even if stronger, is not called a reinforcement. It is called a base.

  15. D. Laminar Composites - 3 We can divide laminar composites into three basic types: • Unreinforced–layer composites (1) All–Metal (a) Plated and coated metals (electrogalvanized steel – steel plated with zinc) (b) Clad metals (aluminum–clad, copper–clad) (c) Multilayer metal laminates (tungsten, beryllium) (2) Metal–Nonmetal (metal with plastic, rubber, etc.) (3) Nonmetal (glass–plastic laminates, etc.) • Reinforced–layer composites (laminae and laminates) • Combined composites (reinforced–plastic laminates well bonded with steel, aluminum, copper, rubber, gold, etc.)

  16. A lamina (laminae) is any arrangement of unidirectional or woven fibers in a matrix. Usually this arrangement is flat, although it may be curved, as in a shell. A laminate is a stack of lamina arranged with their main reinforcement in at least two different directions. D. Laminar Composites - 4

  17. E. Filled Composites • There are two types of filled composites. In one, filler materials are added to a normal composite result in strengthening the composite and reducing weight. The second type of filled composite consists of a skeletal 3-D matrix holding a second material. The most widely used composites of this kind are sandwich structuresand honeycombs.

  18. It is possible to combine several different materials into a single composite. It is also possible to combine several different composites into a single product. A good example is a modern ski. (combination of wood as natural fiber, and layers as laminar composites) F. Combined Composites

  19. Forms of Reinforcement Phase • Fibers • cross-section can be circular, square or hexagonal • Diameters --> 0.0001” - 0.005 “ • Lengths --> L/D ratio • 100 -- for chopped fiber • much longer for continuous fiber • Particulate • small particles that impede dislocation movement (in metal composites) and strengthens the matrix • For sizes > 1 mm, strength of particle is involves in load sharing with matrix • Flakes • flat platelet form

  20. Fiber Reinforcement • The typical composite consists of a matrix holding reinforcing materials. The reinforcing materials, the most important is the fibers, supply the basic strength of the composite. However, reinforcing materials can contribute much more than strength. They can conduct heat or resist chemical corrosion. They can resist or conduct electricity. They may be chosen for their stiffness (modulus of elasticity) or for many other properties.

  21. Types of Fibers The fibers are divided into two main groups: • Glass fibers: There are many different kinds of glass, ranging from ordinary bottle glass to high purity quartz glass. All of these glasses can be made into fibers. Each offers its own set of properties. • Advanced fibers: These materials offer high strength and high stiffness at low weight. Boron, silicon, carbide and graphite fibers are in this category. So are the aramids, a group of plastic fibers of the polyamide (nylon) family.

  22. Fiberglass properties vary somewhat according to the type of glass used. However, glass in general has several well–known properties that contribute to its great usefulness as a reinforcing agent: Tensile strength Chemical resistance Moisture resistance Thermal properties Electrical properties There are four main types of glass used in fiberglass: A–glass C–glass E–glass S–glass Fibers - Glass

  23. Fibers - Glass • Most widely used fiber • Uses: piping, tanks, boats, sporting goods • Advantages • Low cost • Corrosion resistance • Low cost relative to other composites: • Disadvantages • Relatively low strength • High elongation • Moderate strength and weight • Types: • E-Glass - electrical, cheaper • S-Glass - high strength

  24. Fibers - Aramid (kevlar, Twaron) • Uses: • high performance replacement for glass fiber • Examples • Armor, protective clothing, industrial, sporting goods • Advantages: • higher strength and lighter than glass • More ductile than carbon

  25. Fibers - Carbon • 2nd most widely used fiber • Examples • aerospace, sporting goods • Advantages • high stiffness and strength • Low density • Intermediate cost • Properties: • Standard modulus: 207-240 Gpa • Intermediate modulus: 240-340 GPa • High modulus: 340-960 GPa • Diameter: 5-8 microns, smaller than human hair • Fibers grouped into tows or yarns of 2-12k fibers

  26. Fibers -- Carbon (2) • Types of carbon fiber • vary in strength with processing • Trade-off between strength and modulus • Intermediate modulus • PAN (Polyacrylonitrile) • fiber precursor heated and stretched to align structure and remove non-carbon material • High modulus • made from petroleum pitch precursor at lower cost • much lower strength

  27. Fibers - Others • Boron • High stiffness, very high cost • Large diameter - 200 microns • Good compressive strength • Polyethylene - trade name: Spectra fiber • Textile industry • High strength • Extremely light weight • Low range of temperature usage

  28. Fibers -- Others (2) • Ceramic Fibers (and matrices) • Very high temperature applications (e.g. engine components) • Silicon carbide fiber - in whisker form. • Ceramic matrix so temperature resistance is not compromised • Infrequent use

  29. Fiber Material Properties Steel: density (Fe) = 7.87 g/cc; TS=0.380 GPa; Modulus=207 GPa Al: density=2.71 g/cc; TS=0.035 GPa; Modulus=69 GPa

  30. Fiber Strength

  31. Matrix Materials • Functions of the matrix • Transmit force between fibers • arrest cracks from spreading between fibers • do not carry most of the load • hold fibers in proper orientation • protect fibers from environment • mechanical forces can cause cracks that allow environment to affect fibers • Demands on matrix • Interlaminar shear strength • Toughness • Moisture/environmental resistance • Temperature properties • Cost

  32. Matrices - Polymeric • Thermosets • cure by chemical reaction • Irreversible • Examples • Polyester, vinylester • Most common, lower cost, solvent resistance • Epoxy resins • Superior performance, relatively costly

  33. Matrices - Thermosets • Polyester Polyesters have good mechanical properties, electrical properties and chemical resistance. Polyesters are amenable to multiple fabrication techniques and are low cost. • Vinyl Esters Vinyl Esters are similar to polyester in performance. Vinyl esters have increased resistance to corrosive environments as well as a high degree of moisture resistance.

  34. Matrices - Thermosets • Epoxy Epoxies have improved strength and stiffness properties over polyesters. Epoxies offer excellent corrosion resistance and resistance to solvents and alkalis. Cure cycles are usually longer than polyesters, however no by-products are produced. Flexibility and improved performance is also achieved by the utilization of additives and fillers.

  35. Matrices - Thermoplastics • Formed by heating to elevated temperature at which softening occurs • Reversible reaction • Can be reformed and/or repaired - not common • Limited in temperature range to 150C • Examples • Polypropylene • with nylon or glass • can be injected-- inexpensive • Soften layers of combined fiber and resin and place in a mold -- higher costs

  36. Matrices - Others • Metal Matrix Composites - higher temperature • e.g., Aluminum with boron or carbon fibers • Ceramic matrix materials - very high temperature • Fiber is used to add toughness, not necessarily higher in strength and stiffness

  37. Important Note Composite properties are less than that of the fiber because of dilution by the matrix and the need to orient fibers in different directions.

  38. MANUFACTURING PROCESSES OF COMPOSITES • Composite materials have succeeded remarkably in their relatively short history. But for continued growth, especially in structural uses, certain obstacles must be overcome. A major one is the tendency of designers to rely on traditional materials such as steel and aluminum unless composites can be produced at lower cost. • Cost concerns have led to several changes in the composites industry. There is a general movement toward the use of less expensive fibers. For example, graphite and aramid fibers have largely supplanted the more costly boron in advanced–fiber composites. As important as savings on materials may be, the real key to cutting composite costs lies in the area of processing.

  39. The processing of fiber reinforced laminates can be divided into two main steps: • Lay–up • Curing • Curing is the drying and hardening (or polymerization) of the resin matrix of a finished composite. This may be done unaided or by applying heat and/or pressure. • Lay–up basically is the process of arranging fiber–reinforced layers (laminae) in a laminate and shaping the laminate to make the part desired. (The term lay–up is also used to refer to the laminate itself before curing.) Unless prepregs are used, lay–up includes the actual creation of laminae by applying resins to fiber reinforcements.

  40. Laminate lay–up operations fall into three main groups: • Winding and laying operations • Molding operations • Continuous lamination • Continuous lamination is relatively unimportant compared with quality parameters as not good as wrt other two processes. In this process, layers of fabric or mat are passed through a resin dip and brought together between cellophane covering sheets. Laminate thickness and resin content are controlled by squeegee rolls. The lay–up is passed through a heat zone to cure the resin.

  41. The most important operation in this category is filament winding. Fibers are passed through liquid resin, and then wound onto a mandrel. After lay–up is completed, the composite is cured on the mandrel. The mandrel is then removed by melting, dissolving, breaking–out or some other method. A. Winding Operation

  42. Molding operations are used in making a large number of common composite products. There are two types of processes: Open–mold (1) Hand lay–up (2) Spray–up (3) Vacuum–bag molding (4) Pressure–bag molding (5) Thermal expansion molding (6) Autoclave molding (7) Centrifugal casting (8) Continuous pultrusion and pulforming. B. Molding Operations

  43. Hand lay–up, or contact molding, is the oldest and simplest way of making fiberglass–resin composites. Applications are standard wind turbine blades, boats, etc.) 1. Hand Lay-up

  44. In Spray–up process, chopped fibers and resins are sprayed simultaneously into or onto the mold. Applications are lightly loaded structural panels, e.g. caravan bodies, truck fairings, bathtubes, small boats, etc. 2. Spray-up

  45. The vacuum–bag process was developed for making a variety of components, including relatively large parts with complex shapes. Applications are large cruising boats, racecar components, etc. 3. Vacuum-Bag Molding

  46. Pressure–bag process is virtually a mirror image of vacuum–bag molding. Applications are sonar domes, antenna housings, aircraft fairings, etc. 4. Pressure-Bag Molding

  47. In Thermal Expansion Molding process, prepreg layers are wrapped around rubber blocks, and then placed in a metal mold. As the entire assembly is heated, the rubber expands more than the metal, putting pressure on the laminate. Complex shapes can be made reducing the need for later joining and fastening operations. 5. Thermal Expansion Molding

  48. Autoclave molding is similar to both vacuum–bag and pressure–bag molding. Applications are lighter, faster and more agile fighter aircraft, motor sport vehicles. 6. Autoclave Molding

  49. 7. Centrifugal Casting Centrifugal Castingis used to form round objects such as pipes. 8. Continuous Pultrusion and Pulforming Continuous pultrusion is the composite counterpart of metal extrusion. Complex parts can be made.

  50. Pulforming is similar to pultrusion in many ways. However, pultrusion is capable only of making straight products that have the same volume all along their lengths. Pulformed products, on the other hand, can be either straight or curved, with changing shapes and volumes. A typical pulformed product is a curved reinforced plastic car spring. (shown in figure.)
