IDEM TMDL 101 Everything you wanted to know about Total Maximum Daily Loads

1. IDEM TMDL 101 Everything you wanted to know about Total Maximum Daily Loads Deep River - Portage Burns Watershed TMDL Stakeholder Meeting March 13, 2013

2. The Total Maximum Daily Load Program (TMDL) The TMDL Process The TMDL Document Presentation Overview

3. The Total Maximum Daily Load Program (TMDL) The TMDL Process The TMDL Document Presentation Overview

4. Identifying the pollutant Determining the current level of the pollutant Calculating the amount of the pollutantthat a waterbody can receive and still meet water quality standards A report of pollutant sources, needed reductions, and actions necessary to improve water quality A tool to guide watershed planning What Is a Total Maximum Daily Load?

5. History of Indiana TMDL Program • 2001 IDEM submits first TMDL • 2005 IDEM meets submission goals from U.S. Environmental Protection Agency (U.S. EPA) • 2006 IDEM develops and submits TMDLS • IDEM developed first state-led multistate TMDL • 2012 • U.S. EPA submission goals have been continuously met since 2005 • IDEM has developed a TMDL template designed to meet the nine elements of a Watershed Management Plan (WMP) • IDEM has 1,055 approved TMDLs developed

6. What Is a Watershed?

7. The sum of allowable loads from point sources, wasteload allocation (WLA) and nonpoint sources, load allocations (LA) plus a margin of safety (MOS) The Definition of a TMDL

8. Allocations • Wasteload Allocation (WLA) • WLAs are the contributions from point sources • WLAs are much easier to identify since they have a discharge point or direct outlet to the stream • WLAs have some type of monitoring or information and are therefore easier to assign loadings

9. Allocations • Load Allocation (LA) • LAs are the contributions from nonpoint sources, which are unregulated • "Diffuse" pollution, generated from large areas with no particular point of pollutant origin, but rather from many individual places • Pollution which cannot be traced to a regulated direct outlet or discharge point

10. Allocations • Margin of Safety (MOS) • MOS may be either implicit or explicit • Implicit • Incorporated into the TMDL through conservative assumptions in the analysis • Explicit • Expressed in the TMDL as loadings set aside for the MOS

11. Tool to help plan local actions to address water quality issues Provide overview of current watershed conditions and goal watershed conditions Improve water quality in the watershed Why Do TMDLs?

12. Information- A description of the watershed and the water quality data on the impairment Sources- Overview of the potential sources of the pollutant Loads- The amount of the impaired pollutant that a waterbody can receive and still meet water quality standards or targets that applies to the watershed Reductions- A list of the reductions necessary to meet the water quality standard or target that applies to the watershed Implementation- A tool to guide watershed planning and restoration activities What Does a Total Maximum Daily Load Provide?

13. TMDL Development Selection Process • Water Quality Reports • 305(b) - assess water quality and report to U.S. EPA, Congress • 303(d) - compile list of impaired waters • Product - Indiana Integrated Water Monitoring and Assessment Report • 303(d) list • Start with 1998 and use subsequent list to complete watershed assessment • Other • Watershed group request • Special projects

14. The Total Maximum Daily Load Program (TMDL) The TMDL Development Process The TMDL Document Presentation Overview

15. Review 303(d) list and sampling data Kickoffstakeholder meeting Conduct additional monitoring Reassess waterbodies Gather information Gather additional information and produce draft TMDL report Draft TMDL stakeholder meeting 30-day comment period Revise draft TMDL and respond to comments on draft final TMDL Submit TMDL to U.S. EPA and receive final TMDL approval What Is the TMDL Process?

16. Waterbodies sampled for water quality, assessed by IDEM and listed on the 303(d) list of impaired waters Waterbodies where a “use” is adversely affected Fishable, Swimmable, Drinkable Waterbodies then sampled for TMDL magnitude and extent of impairment Streams are then reassessed What Are Impaired Waters?

17. Indiana’s Most Common Water Quality Impairments • Problems: • E. coli • Impaired Biotic Communities • Statewide fish consumption advisory • Mercury • PCB

18. Evaluate listing inconsistencies Evaluate new monitoring data Determine extent of impairment Incorporate new data into the TMDL process Refine loading for load reduction development Reassessing a Waterbody

19. Water Quality Monitoring • Targeted design • Averages 30-40 samples per sampling run • Recreational season monitoring April 1-October 31 • Sites sampled monthly for water chemistry parameters • Sites sampled monthly for pathogens and sampled for a five-week geometric mean • Sites sampled for impaired parameters and standard parameters

20. Water Quality Monitoring • Year-round monitoring, 12 monthly samples • These are the 12 digit pour points • Averages eight-12 samples per sampling run • This location provides the most information to be used for the 12-digit watershed • Sites sampled monthly for water chemistry parameters • Sites sampled for impaired parameters and standard parameters • Sites sampled monthly for flow

21. ArcGIS map of area 303(d) listing information Assessment database Land Use GAP Confined Feeding Operations Concentrated Animal Feeding Operations NPDES permits NPDES violations Enforcement cases Internal Data Gathering

22. External Data Gathering • Stakeholders • Soil and Water Conservation Districts • Health Departments • Federal and State Government Agencies • Watershed Groups • Purdue Extension Offices • Universities

23. Two Public Meetings • Explain the process • Ask for information • Present information • Build local partnerships

24. The Total Maximum Daily Load Program (TMDL) The TMDL Process The TMDL Document Presentation Overview

25. The TMDL Document • Overview of watershed condition • Identification of sources • Discussion of analytical process • Load reductions needed • Current and past water quality improvement efforts • Recommended actions

26. Information- A description of the watershed and the water quality data on the impairment Sources- Overview of the potential sources of the pollutant Loads- The amount of the impaired pollutant that a waterbody can receive and still meet water quality standards or targets that apply to the watershed Reductions- A list of the reductions necessary to meet the water quality standards or targets that apply to the watershed Implementation- A tool to guide watershed planning and restoration activities What Does a Total Maximum Daily Load Provide?

27. IDEM is committed to a stakeholder-driven process Collecting information from local stakeholders Providing staff to present information Watershed specialists assist with watershed management plan (WMP) development TMDL Goals

28. Nonpoint Source Grants Program 303(d) List and 305(b) Report Locally Led Work to Improve Water Quality Total Maximum Daily Loads (TMDL) Watershed Specialists Putting It All Together

29. Questions? Staci Goodwin Senior TMDL Project Manager Office of Water Quality Indiana Department of Environmental Management 100 North Senate Avenue Indianapolis, Indiana 46204 Phone: (317) 308-3387 Fax: (317) 308-3219 E-mail: sgoodwin@idem.IN.gov
