Presentation Transcript
slide1

Contamination Control Breathers

for

Enclosed Fluid Systems

Air Sentry® Breathers · 930 Whitmore Drive · Rockwall, TX 75087 · 800-699-8631 · www.airsentry.net

the problem
The Problem…

Harmful Contaminants

Component Wear

Fluid Degradation

Equipment Failure

Rust and Oxidation

without air sentry
Without Air Sentry®
  • Condensation
  • Rust
  • Oxidation
  • Particulates
  • Sludge
  • Corrosion
the solution
The Solution…

Remove Water Vapor

Remove Fumes and Odors

Improve Performance

Reduce Maintenance

Filter Particulates

the design
The Design...

Bi-Directional Airflow

Durable Construction

Triple Filter System

Color Indicator

Safety Sealed

Click Image to See Animation

the results
The Results…

Longer Fluid Life

Reduced Contaminants

Longer Service Life

Reduced Downtime

air sentry d series breathers
Air Sentry® D-Series Breathers

Air Sentry® D-Series Breathers are designed for most hydraulic tanks, reservoirs, transformers and gearboxes. They easily replace standard breather caps or vent systems.

Model D-102

d 108 d 109
D-108 & D-109

The Airflow Workhorses of the Air Sentry® line, the D-108 and D-109 Breathers are designed for applications with airflow requirements of up to 250 cfm (equivalent of 1875 gallons per minute of fluid volume change).

z series mini breathers
Z-Series Mini Breathers

The Mini Breather line was designed for applications where space is limited, or airflow is minimal (10 cfm or less). Applications include gearboxes and small hydraulic reservoirs.

slide11

Steel Breathers (M-Series)

Steel Breathers were designed for the most severe environments and are made of heavy duty industrial materials. The breathers are rechargeable – the silica gel bag filter is replaced by removing the hood. The 2-micron particle filter can be washed and reused.

M-107

slide12

R-Series Breathers

R-Series breathers were designed to withstand continuous vibration on railroad equipment. Since their introduction, they have gained acceptance in other industries where vibration is a concern.

Model R-102

slide13

X-Series Breathers

The X-Series Breather line was designed for extreme humidity. Ideal environments include paper mills, or anywhere that humid air is a problem.

Model X-102

slide14
Aluminum Extrusion, Forging & Rolling Mills

Hydraulic Systems

Gear Reducers

Storage tanks

Appliance Manufacturing

Hydraulic Presses

Gear Reducers

Air Systems

Robotics

Aerospace

Vacuum Systems

Air exchange and control systems

Chemical & Petrochemical

Process systems

Lube Oil degassing and conditioning

Turbines

Storage Tanks

Gear Reducers

Transport Tanks

Typical Industries & Applications

slide15
Pulp & Paper

Gear reducers

Hydraulic systems

Turbine Oil systems

Calander stack bearing oil systems

Steel Mills & Foundries

Hydraulic systems

Gear Reducers

Rolling Oil systems

Storage tanks

Typical Industries & Applications

examples
Examples

Air Sentry® Breather on an Industrial Pump

examples1
Examples

Drag Case

Propel Gearboxes

Swing Gearboxes

Hoist Case

Air Sentry® Breather on Draglines and Cranes

examples2
Examples

Hydraulic Reservoirs

Air Sentry® Breather on Railroad Maintenance of Way Equipment

examples3
Examples

Air Sentry® Breather – Lubricant Drum

examples4
Examples

Air Sentry® Breather on a Compressor Intake

examples5
Examples

Air Sentry® Breathers Used on Reservoirs Outside at a Refinery

examples6
Examples

Air Sentry® Breathers on Distribution Transformers

examples7
Examples

Air Sentry® Breather Venting 8 Lubrication Drums

slide24

1999 Product of the Year Finalist

Air Sentry® Z-Series Contamination Control Breathers

slide25

2003 Product of the Year Finalist

Air Sentry® X-Series Contamination Control Breathers

slide26

Seventy-five percent…

…of all hydraulic system failures are caused by contaminated fluid. Most of these contaminants enter the fluid through the standard breather cap.

  • Keep dirt and moisture OUT of your fluids.
  • Extend your fluid life.
  • Reduce your maintenance costs.
slide27

Air Sentry® Contamination Control Breathers

A Complete Family of Products for every Application

The Cost of Contamination Control is Always Less than the Cost of Repair
