global trade analysis introduction to the gtap modelling framework

Global Trade Analysis: introduction to the GTAP modelling framework

Frank van Tongeren

Trade and development division, LEI

  • Introduction: motivation for GTAP
  • Database
  • Model
  • Some economics
  • GTAP organisation
motivation for gtap
Motivation for GTAP
  • Increasing demand for quantitative analysis of global trade issues
  • E.g., WTO Doha round, Kyoto agreement, EU integration, Regional integration
  • Historically analysis has been done “in-house” in a few agencies: USDA, FAO, World Bank
limitations of agency based projects
Limitations of Agency-based Projects
  • Methodology is often poorly documented.
  • Rarely subjected to peer review.
  • Data base is treated as a strategic asset and therefore not shared with others.
  • Projects rarely survive change of administration.
  • Unfavorable findings result in termination.
limitations of projects based in academia
Limitations of Projects Based in Academia
  • Limited financial support.
  • Little incentive to invest in data base.
  • Tendency to keep model and data until it has outlived its usefulness.
  • Limited contact with decision makers who are the ultimate “clientele” for much of this work.
the gtap approach
The GTAP Approach
  • Publicly funded project, based in academia.
  • Data base and standard model:
    • fully documented
    • publicly available at modest cost
    • easy to use with regular courses
    • accessible to non-modelers.
key resources data base
Key Resources: Data Base
  • Philosophy:
    • Find the best person in the world to do the job
    • GTAP as an assembler of information
  • Reconciled bilateral trade data and shipping margins: USDA
  • Protection data: WTO/WBank/UNCTAD, AMAD
  • National data bases: national collaborators
    • e.g Version 5 EU-15 Input-Output tables, LEI with funding from DG-ENVIRON
  • Production cycle database: 18-24 Months
gtap v6 commodities
Primary agriculturePaddy rice


Cereal grains nec

Vegetables, fruit, nuts

Oil seeds

Sugar cane, sugar beet

Plant-based fibers

Crops nec


Animal products nec

Raw milk

Wool, silk-worm cocoons

Natural resource based activities






Minerals nec

Processing agriculture and food

Meat: cattle,sheep,goats,horse

Meat products nec

Vegetable oils and fats

Dairy products

Processed rice


Food products nec

Beverages and tobacco products


Wearing apparel

Leather products

Wood products

Paper products, publishing

Petroleum, coal productsChemical,rubber,plastic prodsMineral products nec

Ferrous metals

Metals nec

Metal products

Motor vehicles and parts

Transport equipment nec

Electronic equipment

Machinery and equipment nec

Manufactures nec


Gas manufacture, distribution




Transport nec

Sea transport

Air transport


Financial services nec


Business services nec

Recreation and other services



GTAP v6 commodities
additional data on energy use
Additional data on energy use:
  • Coal, oil, gas, petroleum products, electricity
  • Volumes (Mtoe) and prices
  • Harmonized and consistent
  • Biomass small share -> not (yet) separate
gtap v6 regions
GTAP v6 regions
  • 87 regions (built from 226 members)
  • Economy-wide coverage
  • Input-Output tables
  • Bilateral trade flows
  • Policy data
  • Benchmarked to year 2001
key resource a standard multi region cge model
Key Resource: a standard multi-region CGE model
  • profit maximizing behaviour of producers (input restraint)
  • utility maximizing behaviour of consumers(budget constraint)
  • Armington approach: bilateral trade
  • Computable General Equilibrium (CGE): all markets clear simultaneously
    • Product markets
    • Factor markets (capital, labour, land, natural res.)
    • Prices and quantities determined by model
economics of production cost minimizing behavior
Economics of production: Cost Minimizing Behavior
  • Behavioural equations are derived from an economic decision problem:
  • Choose cost minimizing input mix, given the technical characteristics of production, and given prices:

Cost function: C(w, q) = min wi xi st.: q = f(x)

C(w, q)

Factor demand: ----------- = xi(q, w) (Shephard’s lemma)


  • Constant returns to scale production function means:average cost = marginal cost
  • Competitive pricing at marginal cost.
  • Therefore revenue = costsZero Pure Profits:
market clearing
Market clearing
  • On all markets we have:

Qd = Qs

  • Product markets: 56 commodities
  • Factor markets: Land, SkLabour, UnskLabour, Capital, Nat resources
  • Savings = Investment ; Global bank
small example eu sugar reforms
Small example: EU sugar reforms

% change in sugar output under EBA and EU reform

  • EBA: LDCs get quota & duty free access to EU
  • EU reforms:
  • Beet quota down,Internal support price down
eu sugar reforms welfare effects
EU sugar reforms: welfare effects

Trade diversion effect

modifications to standard gtap model
Modifications to standard GTAP model
  • Network members add new model developments:
  • For example:
    • imperfect competition and increasing returns to scale
    • international technology spillovers
    • Modelling specific policies, e.g EU CAP
    • Projections in time
    • Dynamic extensions (GTAPDyn)
    • Modelling of agricultural supply
    • GTAP-E: energy model
gtap organization
GTAP organization
  • Core funding from international consortium, 18 international and national agencies, e.g:
  • WTO, World Bank, UNCTAD, USDA/ERS, OECD,
  • MIT, USEPA ...LEI (member since Nov. 96)
  • Each represented on the advisory board
  • Headquarters Purdue Univ., Tom Hertel
growth of gtap consortium
Growth of GTAP Consortium
  • Five international: OECD, WB, WTO, UNCTAD
  • 11 national: Australia, Denmark, Germany, Netherlands, Japan, US
  • Two non-profit
gtap organization ii
GTAP organization (II)
  • Open network of contributors
    • more than 350 course alumni
    • annual global conference
    • Linked through WWW for distribution of database, software and publications:
  • GTAP relatively unique in economics, but similar to consortia in sciences
  • Success of project traced back to courses
  • Consortium key to long term viability: provides $, but also key data inputs and much needed direction
  • Modest contribution by many agencies provides long run stability
  • Network externalities
there are many ways to get involved
There are many ways to get involved
  • Short course attendance = usually first step
  • Purchase database and Gempack software
  • Attend annual GTAP conference (approx 150 specialists in gobal economic analysis meet)
    • 2003: The Netherlands, The Hague
    • 2004: USA, Washington DC
    • 2005: Germany, Lübeck



make or buy?
