slide1

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G YS E R V I C E

slide2

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G YS E R V I C E

C O M P L E T E P R O D U C T R A N G E

o u r g u i d i n g t h e m e s a n d v i s i o n s
O U R G U I D I N G T H E M E S A N D V I S I O N S
  • Responsibility for the environment
  • By its absolute tightness to the atmosphere Canned Motor Pumps fulfill the highest requirements in respect to environmental- and immission protection. The complete production line of HERMETIC-Pumpen GmbH is an essential contribution in observing the EC directive 96/61/EC, the so-called IPPC directive (Integrated Pollution Prevention and Control) and the Federal Immission Protection Law and TA-Luft respectively.
  • Seal-less canned motor pumps, are considered as being the “Best Available Technology” acc. to the IPPC directive and its data sheets for conveying fluids, which are dangerous and harmful to the environment.
  • Innovation and experience for your product
  • We are one of the world’s leading manufacturers of seal-less centrifugal pumps. The products of the company HERMETIC-Pumpen GmbH stand for best quality and highest operational safety in the chemical and petrochemical industry, as well as in refrigeration and nuclear industry.
  • We combine materials of high quality and individual solutions to sophisticated products.
  • Our products being at the highest safety level feature a great development in partnership with our customers, exceptionally long service lives of our pumps and low life-cycle costs. Canned motor pumps offer great advantages in the fi eld of operation, maintenance and performance.
  • Technology at the highest stage
  • One critical item when using conventional centrifugal pumps is to seal the shaft passages on the pump casing. Besides the high rate of repairs, this is a reason for the steadily increasing use of seal-less pumps. The praxis shows that seal-less pumps generally have less repairs than in comparison with conventional chemical pumps with mechanical seal and consequently, they feature a longer service life.
  • The refrigeration and cooling industry has also used canned motor pumps for a long time without any problems. Thus, besides the absolute tightness and high safety of these pumps, they additionally offer both, the advantage of minimized maintenance and high availability.
  • For your safety – always being one step ahead
  • We offer a highest level of safety – also with extreme parameters:
  • - High potential risk originating from the medium to be conveyed
  • Fluids to be conveyed at extreme temperatures- High-pressure circulation
  • - Explosion protection
  • HERMETIC – Our name stands for our product line
  • „Nomen est Omen“.
  • The name HERMETIC relates to „Hermes Trismegistos“ the famous magician of Greek mythology, who could seal treasures and pots, that means make it „hermetically „ tight.
  • HERMETIC stands as synonym for absolute tight and leakage free delivery.
c o m p l e t e p r o d u c t r a n g e
C O M P L E T E P R O D U C T R A N G E
  • C A N N E D M O T O R P U M P S
    • CN HERMETIC pump, single stage
    • CNF HERMETIC pump, single stage, liquefied gas design
    • CNK HERMETIC pump, single stage, with external cooler
    • CNP HERMETIC pump, single stage, process pump built to API 685
    • CAM HERMETIC pump, single and multistage
    • CS HERMETIC pump, single and multistage, self-priming

S U B M E R S I B L E P U M P S

    • TCN HERMETIC pump, single stage, with canned motor
    • TCAM HERMETIC pump, multistage, with canned motor
    • MCNV HERMETIC pump, single stage, with magnetic drive
    • MCAMV HERMETIC pump, multi stage, with magnetic drive
c o m p l e t e p r o d u c t r a n g e5
C O M P L E T E P R O D U C T R A N G E
  • M A G D R I V E P U M P S
    • MCNn HERMETIC pump, single stage
    • MCAMn HERMETIC pump, single and multistage
    • MCNK HERMETIC pump, single stage, with external cooler
    • MKCN HERMETIC pump, single stage, plastic lined pump

C O N V E N T I O N A L C E N T R I F U G A L P U M P E N

    • HK HERMETIC pump, single and multistage, closed-coupled design
    • HKL HERMETIC pump, single and multistage, bearing pedestal mounted pump

M O N I T O R I N G D E V I C E S

    • NTS/OTV Level and temperature monitoring device
    • ARM-2000 Axial-Rotation-Monitor
    • AM-2000 Axial-Monitor
c o m p l e t e p r o d u c t r a n g e6
C O M P L E T E P R O D U C T R A N G E
  • D I S P L A C E M E N T P U M P S
    • KRL/M/H Rotary lobe pump with single and double mechanical seal, or Cartrige
    • LZ Gear pump with single or double mechanical seal
    • LZM Gear pump with magdrive
    • HP Internal gear pump with single or double mechanical seal
    • MHP Internal gear pump with magdrive

V A K U U M P U M P S A N D - S Y S T E M S

    • LVPS Liquid ring vacuum pump, short size (close coupled)
    • LVPL Liquid ring vacuum pump, long size (bearing bracket)
    • LVPG Liquid ring vacuum pump with mechanical seal
    • LVPM Liquid ring vacuum pump with magdrive
    • LVPH Liquid ring vacuum pump with canned motor
    • ALVS Vacuum system
    • EVAP dry screw vacuum pump
c a n n e d m o t o r p u m p c n

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N
  • Single stage
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 1200 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. -120°C to +100°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 and PN 25

c a n n e d m o t o r p u m p c n f

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N F
  • Single stage, liquified gas design
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 1200 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. -120°C to +100°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 and PN 25

c a n n e d m o t o r p u m p c n f9

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N F
  • Single stage, liquified gas design
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858

Flow max. 50 m³/h

Head max. 57 m

Speed 2800 U/min

Operating temp. -50°C to +30°C

Viscosity max. 20 mm²/s

Pressure rating PN 25 / PN 40

c a n n e d m o t o r p u m p c n u n d c n f

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N U N D C N F
  • Single stage, high temperature design, without external cooler
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T3

Flow max. 300 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. +100°C to +360°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 and PN 25

c a n n e d m o t o r p u m p c n u n d c n f11

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N U N D C N F
  • Single stage, for liquids with high melting points with heating jacket
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T3

Flow max. 300 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. max. +360°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 and PN 25

c a n n e d m o t o r p u m p c n h

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N H
  • Single stage, for high system pressures
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 180 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. -120°C to +100°C

Viscosity max. 300 mm²/s

Pressure rating max. PN 1200

c a n n e d m o t o r p u m p c n k

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N K
  • Single stage, with cooler
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 1200 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. max. +360°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 and PN 25

c a n n e d m o t o r p u m p c n k14

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N K
  • Single stage, with air cooler
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 1200 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. max. +360°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 and PN 25

c a n n e d m o t o r p u m p c n k15

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N K
  • Single stage, with cooler and integrated dosing pump
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 1200 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. max. +360°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 and PN 25

c a n n e d m o t o r p u m p c n k h

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N K H
  • Single stage, with cooler, for high system pressures
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 180 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. max. +360°C

Viscosity max. 300 mm²/s

Pressure rating max. PN 1200

c a n n e d m o t o r p u m p c n p

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N P
  • Single stage, single entry
  • Centerline-mounted, fully comply with the API 685 (ISO 15783)
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 1200 m³/h

Head max. 200 m

Speed 1450 and 2900 U/min

Operating temp. -120°C to +100°C

Viscosity max. 300 mm²/s

Pressure rating PN 50

c a n n e d m o t o r p u m p c n p f

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N P F
  • Single stage, single entry, liquified gas design
  • Centerline-mounted, fully comply with theAPI 685 (ISO 15783)
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 1200 m³/h

Head max. 200 m

Speed 1450 and 2900 U/min

Operating temp. -120°C to +100°C

Viscosity max. 300 mm²/s

Pressure rating PN 50

c a n n e d m o t o r p u m p c n p k

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N P K
  • Single stage, single entry, with external cooler
  • Centerline-mounted, fully comply with the API 685 (ISO 15783)
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 1200 m³/h

Head max. 200 m

Speed 1450 and 2900 U/min

Operating temp. max. +425°C

Viscosity max. 300 mm²/s

Pressure rating PN 50

c a n n e d m o t o r p u m p c n p k20

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C N P K
  • single stage, single entry with air cooler
  • Centerline-mounted, fully comply with the API 685 (ISO 15783)
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 1200 m³/h

Head max. 200 m

Speed 1450 and 2900 U/min

Operating temp. max. +425°C

Viscosity max. 300 mm²/s

Pressure rating PN 50

c a n n e d m o t o r p u m p c a m

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C A M
  • Single- and multistage
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 300 m³/h

Head max. 700 m

Speed 2900 U/min

Operating temp. -120 °C to +100°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 to PN 100

c a n n e d m o t o r p u m p c a m22

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C A M
  • Single- and multistage

Flow max. 35 m³/h

Head max. 130 m

Speed 2800 U/min

Operating temp. -50 °C to +30°C

Viscosity max. 20 mm²/s

Pressure rating PN 25 / PN 40

c a n n e d m o t o r p u m p c a m r

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C A M R
  • Single- and multistage

Flow max. 12,5 m³/h

Head max. 72 m

Speed 2800 U/min

Operating temp. -50 °C to +30°C

Viscosity max. 20 mm²/s

Pressure rating PN 25 / PN 40

c a n n e d m o t o r p u m p c a m24

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C A M
  • Single- and multistage, high temperature design, without external cooler
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T3

Flow max. 120 m³/h

Head max. 300 m

Speed 2900 U/min

Operating temp. max +360°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 to PN 100

c a n n e d m o t o r p u m p c a m t a n d e m

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C A M - T A N D E M
  • Multistage. tandem design
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 300 m³/h

Head max. 1200 m

Speed 2900 U/min

Operating temp. -120°C to +100°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 to PN 100

c a n n e d m o t o r p u m p c a m k

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C A M K
  • Single- and multistage, with cooler
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 300 m³/h

Head max. 700 m

Speed 2900 U/min

Operating temp. max. +360°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 to PN 100

c a n n e d m o t o r p u m p c a m h

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C A M H
  • Multistage, for high system pressures, barrel pump
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 300 m³/h

Head max. 700 m

Speed 2900 U/min

Operating temp. -120 °C to +100°C

Viscosity max. 300 mm²/s

Pressure rating to PN 500

c a n n e d m o t o r p u m p c a m h28

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C A M H
  • Multistage, for high system pressures, tandem design
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 300 m³/h

Head max. 700 m

Speed 2900 U/min

Operating temp. max. +100°C

Viscosity max. 300 mm²/s

Pressure rating max. PN 500

c a n n e d m o t o r p u m p c s 3 2

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C S 3 2
  • Multistage, self-priming
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 20 m³/h

Head max. 110 m

Speed 1450 U/min

Operating temp. -40°C to +240°C

Viscosity max. 75 mm²/s

Pressure rating PN 16 to PN 40

c a n n e d m o t o r p u m p c s

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P C S
  • Single stage, self-priming
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 100 m³/h

Head max. 85 m

Speed 2900 U/min

Operating temp. -30°C to +90°C

Viscosity max. 75 mm²/s

Pressure rating PN 10

c a n n e d m o t o r p u m p t c n

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P T C N
  • Single stage, submersible pump, vertical and horizontal design
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 200 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. max. +100°C

Viscosity max. 300 mm²/s

Pressure rating PN 10 and PN 25

c a n n e d m o t o r p u m p t c a m

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C A N N E D M O T O R P U M P T C A M
  • Single- and multistage, submersible pump, vertical and horizontal design
  • Explosion protection as per EC-type examination certificate according to directives 94/9/EG

II 2 G EEx dec II C T1 to T6

Flow max. 300 m³/h

Head max. 700 m

Speed 1450 and 2900 U/min

Operating temp. max. +100°C

Viscosity max. 300 mm²/s

Pressure rating max. PN 100

m a g d r i v e p u m p m c n n

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

M A G D R I V E P U M P M C N n
  • Single stage
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858

Flow max. 450 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. max. +220°C

Viscosity max. 100 mm²/s

Pressure rating PN 16 and PN 25

m a g d r i v e p u m p m c n n b l o c k

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

M A G D R I V E P U M P M C N n - B L O C K
  • Single stage, closed coupled design
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858

Flow max. 220 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. max. +140°C

Viscosity max. 100 mm²/s

Pressure rating PN 16 and PN 25

m a g d r i v e p u m p m c a m n

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

M A G D R I V E P U M P M C A M n
  • Single- and multistage

Flow max. 45 m³/h

Head max. 200 m

Speed 2900 U/min

Operating temp. max. +220°C

Viscosity max. 100 mm²/s

Pressure rating PN 16 and PN 25

m a g d r i v e p u m p m c a m n b l o c k

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

M A G D R I V E P U M P M C A M n - B L O C K
  • Single- and multistage, closed coupled design

Flow max. 45 m³/h

Head max. 200 m

Speed 2900 U/min

Operating temp. max. +140°C

Viscosity max. 100 mm²/s

Pressure rating PN 16 and PN 25

m a g d r i v e p u m p m c n k

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

M A G D R I V E P U M P M C N K
  • Singl stage, with external cooling
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858

Flow max. 450 m³/h

Head max. 150 m

Speed 1450 and 2900 U/min

Operating temp. max. +360°C

Viscosity max. 100 mm²/s

Pressure rating PN 16 and PN 25

m a g d r i v e p u m p m k c n n

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

M A G D R I V E P U M P M K C N n
  • Single stage, plastic lined pump
  • Dimensions and performance curves in accordance to EN 22858; ISO 2858

Flow max. 50 m³/h

Head max. 57 m

Speed 1450 and 2900 U/min

Operating temp. max. +150°C

Viscosity max. 30 mm²/s

Pressure rating PN 16

c o n v e n t i o n a l c e n t r i f u g a l p u m p e n h k

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C O N V E N T I O N A L C E N T R I F U G A L P U M P E N H K
  • Single- and multistage in closed coupled design, with packing gland or mechanical seal

Flow max. 140 m³/h

Head max. 200 m

Speed 2900 U/min

Operating temp. max. +350°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 and PN 25

c o n v e n t i o n a l c e n t r i f u g a l p u m p e n h k l

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

C O N V E N T I O N A L C E N T R I F U G A L P U M P E N H K L
  • Single- and multistage, bearing pedestal mounted pump, with packing gland or mechanical seal

Flow max. 140 m³/h

Head max. 200 m

Speed 2900 U/min

Operating temp. max. +350°C

Viscosity max. 300 mm²/s

Pressure rating PN 16 and PN 25

slide41

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

M O N I T O R I N G D E V I C E S A R M - 2 0 0 0a n dA M - 2 0 0 0

  • Balancing of the axial thrust is an important factor of the final testing.
  • Improper axial thrust balancing is the primary pump failure.
  • Axial thrust balance is influenced by the plant itself or by pumped liquid.
  • For early failure detection, rotor position monitoring is recommended.
  • By separate monitoring of the bearing clearance and the direction of rotation, several models of pump failure can be detected.

For example: ARM-2000 AM-2000

Axial bearing wear 33

Cavitation 33

deposits and clocking 33

wrong direction of rotation 3 –

flow reduction 33

threatened damage of the can 33

reduced motor cooling flow 33

m o n i t o r i n g d e v i c e s n t s
M O N I T O R I N G D E V I C E S N T S

Thermostat T30

Level sensor N30

N 30.1 to 100°

gasket

40

Ø12

Moveable reed

contact insert for

functional checking

113

PG 16

thread R 1/2“

73

Ø130

28

PG 13,5

76

170

275

DN15

76

246

Switching amplifier S30

105

1,8

18

DN15

2,5

112

Ø21,3

110

80

N 30.2 to 370°

18

210

m o n i t o r i n g d e v i c e s o t v
M O N I T O R I N G D E V I C E S O T V

Thermostat T30

Level sensor O30

thread R 1/2“

gasket

Ø18

40

Ø12

Ø45

113

thread R 1/2“

73

28

PG 13,5

170

76

76

246

EL 24

EL +4

ELmax = 960 mm

89

EL = insert length

Switching amplifier V30

Connection box (Macrolon casing)

120

75

200

Insert card 19“

r o t a r y l o b e p u m p k r h k r m

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

R O T A R Y L O B E P U M P K R H / K R M
  • Rotary lobe pump for process applications
  • Suitable for low lubricating, viscous, corrosive and toxic fluids
  • Shaft sealing by double mechanical seal

II 2 G EEx II c T1 to T6

Flow max. 300 m³/h

Differential pressure max. 30 bar

Speed max. 700 U/min

Operating temp. -50°C to +250°C

Viscosity max. 1000.000 mm²/s

Pressure rating PN 25 to PN 100

g e a r p u m p l z

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

G E A R P U M P L Z
  • Gear pumps for process applications
  • Suitable for low lubricating, viscous, corrosive and toxic fluids
  • Single or double mechanical seal

II 2 G EEx II c T1 to T6

Flow max. 100 m³/h

Differential pressure max. 100 bar

Speed max. 1450 U/min

Operating temp. -50°C to +250°C

Viscosity max. 1000.000 mm²/s

Pressure rating PN 25 to PN 100

g e a r p u m p l z m

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

G E A R P U M P L Z M
  • Gear pumps for process applications
  • Suitable for low lubricating, viscous, corrosive and toxic fluids
  • Magdrive

II 2 G EEx II c T1 to T6

Flow max. 100 m³/h

Differential pressure max. 100 bar

Speed max. 1450 U/min

Operating temp. -50°C to +250°C

Viscosity max. 10.000 mm²/s

Pressure rating PN 25 to PN 100

i n t e r n a l g e a r p u m p h p

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

I N T E R N A L G E A R P U M P H P
  • Internal gear pump for process applications
  • Suitable for low lubricating, viscous, corrosive and toxic fluids
  • Single or double mechanical seal

II 2 G EEx II c T1 to T6

Flow max.60 m³/h

Differential pressure max. 12 bar

Speed max. 900 U/min

Operating temp. -50°C to +150°C

Viscosity max. 1000.000 mm²/s

i n t e r n a l g e a r p u m p h p m h p

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

I N T E R N A L G E A R P U M P H P / M H P
  • Internal gear pump for process applications
  • Suitable for low lubricating, viscous, corrosive and toxic fluids
  • Magdrive

II 2 G EEx II c T1 to T6

Flow max.60 m³/h

Differential pressure max. 12 bar

Speed max. 900 U/min

Operating temp. -50°C to +150°C

Viscosity max. 10.000 mm²/s

v a k u u m p u m p e l v p

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

V A K U U M P U M P E L V P
  • Liquid ring vacuum pumps for process applications
  • According to API 681
  • Casing for high tightness requirements
  • Single or double mechanical seal
  • Available in special materials e.g. Hastelloy, titanium

II 2 G EEx II c T1 to T6

Flow max.2000 m³/h

Differential pressure max. 2 bar

Speed max. 3000 U/min

Operating temp. -50°C to +150°C

Pressure rating PN 10

v a k u u m p u m p e l v p m l v p h

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

V A K U U M P U M P E L V P M / L V P H
  • Liquid ring vacuum pumps for process applications
  • According to API 681
  • Casing for high tightness requirements
  • Magdrive or canned motor
  • Available in special materials e.g. Hastelloy, titanium

II 2 G EEx II c T1 to T6

Flow max.2000 m³/h

Differential pressure max. 2 bar

Speed max. 3000 U/min

Operating temp. -50°C to +150°C

Pressure rating PN 10

v a c u u m s y s t e m a l v s

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

V A C U U M S Y S T E M A L V S
  • Our liquid ring vacuum systems are custom-made according to your process requirements. Combinations with steam ejectors, roots blower pumps, in several stages are executable one behind the other.
  • The plants can be supplied completely equipped with measuring and automatic control.
  • The plants are adapted in material and execution to the respective process conditions
d r y s c r e w v a c u u m p u m p e v a p

C H E M I C A L

P E T R O C H E M I C A L

R E F R I G E R A T I O N

E N E R G Y

D R Y S C R E W V A C U U M P U M P E V A P
  • Single stage, dry running, non-contact screw type vacuum pump.
  • The screw rotor construction with directly water-cooled screws is patented.
  • Therefore the pump is particularly suitable for applications in chemistry, pharmacy and polymer production.

II 2 G c T3 to T4

Flow max. 840 m³/h

Differential pressure max. 1300 mbar

Speed max. 3500 U/min

Operating temp. to +100°C

Pressure rating PN 10
