Presentation Transcript
slide1

Comparison of topography-guided (TGL) to standard LASIK (SL) for hyperopia. How important is adjustment for angle kappa?ASCRS 08

A. John Kanellopoulos, MD

Associate Professor NYU, New York

Director, Laservision.gr, Athens, Greece

www.brilliantvision.com

slide2
We have reported our topo-guided experience in LASIK utilizing the Wavelight-platform(Kanellopoulos-JRS Sept05)
  • The software feeds 8 high quality topographies (Oculus) and offers surgeon adjustment for final ablation for:

1-sphere

2-Cylinder

3-Axis

4-Q value (asphericity)

angle-kappa adjustment is done by default. So the ablation is decentered to target the visual axis

www.brilliantvision.com

slide3

We have reported our experience

with LASIK for treating hyperopia

with the standard Wavelight

platform

Kanellopoulos-JRS 2006

Initial topography guided Hyperopic and Hyperopic Astigmatism LASIK

Experience with the WaveLight ALLEGRETTO WAVE

excimer laser in 120 Consecutive Eyes

ARVO 2006-JRS 2006

is angle kappa significant in hyperopes
Is Angle kappa significant in hyperopes?
  • We published the study: Measurement of angle kappa with synoptophore and Orbscan II in a normal population Hikmet Basmak, MD1; Afsun Sahin, MD2; Nilgun Yildirim, MD3; Thanos D. Papakostas, MD4,5; and A. John Kanellopoulos, MD4,52007 J Refract Surg-
  • We showed as previous investigators have that there is a significant correlation between positive refractive errors and large positive angle kappa values. Refractive surgeons must take into account angle kappa especially in hyperopic patients in order to avoid complications related to decent ration of ablation zone.

www.brilliantvision.com

purpose why really use topo guided for hyperopia
Purpose-why really use topo-guided for hyperopia?
  • We evaluated the Safety and efficacy of Topo-Guided LASIK (that compensates for angle kappa) versus standard hyperopic LASIK
  • Compare to previous data from previous published standard treatments(including ours)
  • Can we safely and effectively compensate for angle-kappa by using this platform?

www.brilliantvision.com

slide6

An example of a topo-guided hyperopic correction (1 is after, 2 is pre-op and 1 minus 2 the difference showing that the ablation is decentered when referenced to the pupil): Treatment axis is centered on the visual axis and not pupil center

methods
METHODS:

SETTING: Laservision.gr Institute, Athens, Greece. 35 patients treated with TGL in one eye, SL in the other.

  • The Wavelight and Intralase systems were used.
  • Refraction, UCVA, BSCVA, angle kappa; effective ablation diameter (EAD), wavefront analysis (WA) and contrast sensitivity (CS) were evaluated with 18 months follow-up.

www.brilliantvision.com

how is angle kappa adjusted with topo link
How is Angle kappa adjusted withtopo-link

These figures depict the same planned excimer profile for the correction of hyperopic astigmatism on the left: centered on the pupillary center and on the right :adjusted by topography to take into consideration and adjust for angle kappa

www.brilliantvision.com

slide9

A LASIK flap with a microkeratome needs to be de-centered as well to accommodate the de-centered ablation this may beChallenging for the surgeon. The Intralase offers a better option to customise the flap cnetration

www.brilliantvision.com

results
Results
  • Mean pre-op sphere for both groups
  • +3.08 (SD+/- 1.56) D.
  • Cylinder: +1.80 (SD+/- 1.01 D).
  • Post-op: Mean post-values Topo guided compared tp Standard
  • UCVA: 20/20 to 20/23.
  • Regression: + 0.32 to +0.55.
  • Cylinder: + 0.25 to +0.54.
  • Ablation diameter: 6.8 to 6.2 mm,
  • Wavefront: 0.25 to 0.37.
  • Contrast sensitivity: +40% to + 15%.

www.brilliantvision.com

slide11
A head on comparison of the post-hyperopic LASIK Pentacam map in the same patient The topo-guided eye on the left and standard on the right

www.brilliantvision.com

conclusions
Conclusions
  • Topo Guided LASIK and Standard LASIK with the Intralase and the Wavelight laser appear to be safe and effective for hyperopia.
  • Topo-guided appears be superior in regard to regression, residual astigmatism, Contrast and ablation diameter
  • This platform achieves superior visual axis centration with a smaller re-treatment rate compared to our previously published series.
  • It reduces the chance of a surgeon-related de-centration error.
  • Oculyzer-link maybe faster and more-accurate

www.brilliantvision.com
