GEMİ YAPISI TARİFİ VE NOTLAR (SHIP CONSTRUCTION SKETCHES AND NOTES)

1.GEMİ ÖLÇÜLERİ ( SHIP DIMENSIONS)

2. GEMİ YÖNLERİ VE GÜVERTELERİ ( SHIP DIRECTIONS AND DECKS )

3. GEMİ GENEL YAPISI ( SHIP GENERAL STRUCTURE )

4. BASİT AMBAR PLANI (BASIC HOLD PLAN)

5. SU ÇEKİMİ VE TRİM ( DRAFT AND TRIM )

6. YÜKLEME MARKALARI (TONNAGE MARKS)

slide3

GEMİ YAPISI TARİFİ VE NOTLAR (SHIP CONSTRUCTION SKETCHES AND NOTES)

GEMİ ÖLÇÜLERİ ( SHIP DIMENSIONS)

TAM BOY ( OVERALL LENGHT )

KARİNA (BOTTOM OF THE VESSEL)

GENİŞLİK ( BREADTH )

FAÇA (BOOT TOP)

BORDA (BOARD)

slide4

İSKELE

(PORT)

FİLİKA GÜVERTE

BOAT DECK

ALT GÜVERTE

(LOWER DECK)

PORT SIDE

SANCAK

(STARBOARD)

STARBOARD SIDE

KIÇ ÜSTÜ

(POP DECK)

BAŞÜSTÜ

(FORE CASTLE DECK)

KÖPRÜÜSTÜ GÜVERTE

(BRIDGE DECK)

MİYAR GÜVERTE

(STANDARD COMPASS DECK)

GEMİ YAPISI TARİFİ VE NOTLAR (SHIP CONSTRUCTION SKETCHES AND NOTES)

GEMİ YÖNLERİ VE GÜVERTELERİ ( SHIP DIRECTIONS AND DECKS )

CAN FİLİKASI

(LIFE BOAT)

OMUZLUK

(BOW)

PUPA (AFT)

PRUVA (HEAD)

ANA GÜVERTE

(MAİN DECK)

slide5

GRANDİ DİREĞİ

(MAIN MAST)

AMBAR AĞZI

(HATCH)

YAŞAM MAHALİ

(ACCOMMODATION)

KÖPRÜÜSTÜ

(BRIDGE)

BAŞ DİREK

AMBAR (HOLD)

BAŞ TARAF

AMBAR KAPAĞI

(HATCH COVER)

BACA

(FUNNEL)

BAŞ ÜSTÜ

KIÇ ÜSTÜ

BAŞALTI

5

4

3

2

1

BAŞ BODOSLAMA

KIÇ TARAF

BULP

FUEL OIL TANKI

BALLAST TANKI

KIÇ PİK TANKI

(AFT PEAK TANK)

DIESEL OIL TANKI

BAŞ PİK TANKI

(FORE PEAK TANK)

LUB. OIL TANKI

DÜMEN YELPAZESİ

(RUDDER FRAME)

PERVANE

(PROPELLER)

ANA MAKİNE

(MAIN ENGINE)

GEMİ YAPISI TARİFİ VE NOTLAR

SU SEVİYESİ

GEMİ GENEL YAPISI ( SHIP GENERAL STRUCTURE )

slide6

ALABANDA

(WING)

GEMİ YAPISI TARİFİ VE NOTLAR (SHIP CONSTRUCTION SKETCHES AND NOTES)

BASİT AMBAR PLANI (BASIC HOLD PLAN)

AMBAR KAPAĞI (HATCH COVER)

KAPAK PİSTONU

MANİKA

(WIND CATCHER)

AMBAR MERDİVENİ

(HOLD LADDER)

GLADORA

(TWEENDECK)

İSKANDİL DELİĞİ

(SOUNDING HOLE)

KEMERE

(BEAM)

ASMA TANK

(TOP SIDE)

KATLANIR KAPAK

İSKANDİL BORUSU

(SOUNDING PIPE)

DİP AMBAR

(HOLD)

POSTA

(FRAME)

HAVALANDIRMA BORUSU

(VENT. PUMP)

AMBAR SİNTİNESİ

İSKANDİL KUYUSU

(WIND CATCHER)

ÇİFT DİP

(DOULE BOTTOM)

OMURGA

(KEEL)

DÖŞEK

(FLOOR)

slide7

?

MEAN DRAFT = (AFT DRAFT + FORE DRAFT) / 2

Ø

FREE BOARD

AFT DRAFT

MEAN DRAFT

FORE DRAFT

KEEL CLEARANCE

LINE OF DEEP REFERENCE

GEMİ YAPISI TARİFİ VE NOTLAR (SHIP CONSTRUCTION SKETCHES AND NOTES)

SU ÇEKİMİ VE TRİM ( DRAFT AND TRIM )

Gemilerdeki Free board değerleri INTERNATIONAL CONVENTION ON LOAD LINE’da belirlenmiştir.

TRIM = AFT DRAFT - FORE DRAFT

slide8

TF : TROPICAL FRESH WATER

F : FRESH WATER

T : TROPICAL WATER

S : SUMMER WATER

W : WINTER WATER

WNA : WINTER NORTH ATLANTIC

L : LUMBER

GEMİ YAPISI TARİFİ VE NOTLAR (SHIP CONSTRUCTION SKETCHES AND NOTES)

YÜKLEME MARKALARI (TONNAGE MARKS)

slide9

THIS PRESENTATION WAS PREPARED

BY SELÇUK NAS

E MAIL : snas@deu.edu.tr

Mobile Phone : 0 532 331 51 31

Phone : 0 90 232 278 22 30

Address : Dokuz Eylul Universitesi, Deniz Isletmeciligi ve Yonetimi Yuksekokulu, Kaynaklar Yerleskesi, Buca, Izmir, TURKEY

You can use all my product where ever you want.
