Presentation Transcript
slide1

Radioiodine Collection Filter Efficiency Testing Program at F&J Specialty Products, Inc.by Frank M. Gavila

12TH Annual RETS/REMP Workshop

presentation overview
Presentation Overview
  • Radioiodine Collection Cartridge Efficiency Testing
  • Standardized Testing
  • Factors Affecting Efficiencies of Radioiodine Collection Cartridges
  • F&J Quality Assurance and Quality Control Programs
radioiodine collection cartridges efficinecy testing program
Radioiodine Collection Cartridges Efficinecy Testing Program

Key elements

  • Testing is performed on every batch of adsorbent material
  • Testing is performed at different flow rates
  • Integration of new batch data from individual batches into

data of all previous batches

  • Development of data for different sampling scenarios
  • Determination of pressure drop data vs. flow rate for each

type of adsorbent material

  • Creation of graphical representation of collection efficiency vs. flow data and determination of mathematical equations that represent efficiency vs. flow relationship
radioiodine collection filter geometries
Radioiodine Collection Filter Geometries

Dimensions Material F&J Geometry

Diameter Height Casing Series

2.25” 1.03” plastic C, CS, CSM

2.50” 1.00” plastic B

2.51” 1.01” metal M

2.54” 1.62” metal M.5

(WRGM Monitor)

3.43” 1.23” plastic 3x1

3.20” 2.20” plastic 3x2

1.63” 0.76” plastic Lapel Filter

1.24” 1.11” plastic 744/844

(Victoreen Monitor)

2.25” 1.04” metal FJ100/200

typical adsorbents and mesh sizes available
Typical Adsorbents and Mesh Sizes Available

TEDA Silver Impregnated

Impregnated Carbon Silver Zeolite Silica Gel

5% by wt. TEDA 37% by wt. Ag 12% by wt. Ag

US Sieve US Sieve US Sieve

TEDA-1 8x16 16x40 10x16

TEDA-2 30x50 30x50

TEDA-3 20x40 50X80

TEDA-4 12x20

slide6

Activated Carbon Particulate Selector

To determine approximate mesh size of an activated carbon sample, compare representative particles of the largest and smallest size to the printed solid circles. Mesh size is given in two numbers, e.g., "6x10." The first number is a mesh slightly larger than the largest representative particle, and the second is a mesh slightly smaller than the smallest particle. Normal manufacturing tolerances allow for a few non- representative particles in each sample.

Standard Mesh Opening Particle Standard Mesh Opening Particle

Tyler U.S. mm inches Tyler U.S. mm inches

4 4 4.70 0.185  35 40 .417 .016 

6 6 3.33 .131  42 45 .351 .014 

8 8 2.36 .094  48 50 .295 .012 

10 12 1.65 .065  60 60 .246 .0097 

12 14 1.40 .056  80 80 .175 .0069 

14 16 1.17 .047  100 100 .147 .0058

16 18 .991 .039  150 140 .104 .0041

20 20 .833 .033  200 200 .074 .0029

24 25 .701 .028  250 230 .061 .0024

28 30 .589 .023  325 325 .043 .0017

32 35 .495 .020  400 400 .038 .0015

product specifications
Product Specifications
  • Detailed physical and performance specifications provided with each radioiodine collection cartridge manufactured by F&J.
slide8
Charcoal Mesh Size

Charcoal Type

TEDA Impregnation

Dimensions

Casing

Filter Labeling

Performance Test Data

Quality Assurance Requirements

Individual Filter Package

Intermediate Packaging

Exterior Packaging

Incineration Approval

20 X 40 Mesh

Coconut Shell Carbon

5% By Weight

H = 1.05” +/- 0.01”

D = 2.26” +/- 0.01”

Plastic Cased

Color coded YELLOW to distinguish it from other material

types and indicating flow direction

% CH3I vs flow rate from 0.5 CFM to10 CFM as per ASTM

D 3803-1989

ISO 9001-1994 Quality Assurance Program and statistical

process control program for diameter and height parameters

Sealed individually in plastic bags with model #, batch # ID

and mesh size. The expiration date on the bag.

50 Filters/Box (6 Pounds)

200 or 250 Filters/Case (24 or 30 Pounds)

Yes. By GTS Duratek, Oak Ridge, Tennessee

TECHNICAL SPECIFICATIONS

TEDA IMPREGNATED CHARCOAL FILTERS

2-1/4"

D X 1" H

F&J PRODUCT CODE: TE3C

slide9

TECHNICAL SPECIFICATIONS

SILVER ZEOLITE

2-1/4"

D X 1" H

F&J PRODUCT CODE: AGZC35

  • Charcoal Mesh Size
  • Charcoal Type
  • TEDA Impregnation
  • Dimensions
  • Casing
  • Filter Labeling
  • Performance Test Data
  • Quality Assurance Requirements
  • Individual Filter Package
  • Intermediate Packaging
  • Exterior Packaging
  • Incineration Approval

30 X 50 Mesh

Silver Zeolite

37% Ag By Weight

H = 1.05” +/- 0.01”

D = 2.26” +/- 0.01”

Plastic Cased

Color coded BLUE to distinguish it from other material

types and indicating flow direction

% CH3I vs flow rate from 0.5 CFM to5 CFM as per ASTM

D 3803-1989

ISO 9001-1994 Quality Assurance Program and statistical

proecess control program for diameter and height parameters

Sealed individually in plastic bags with model #, batch # ID

and mesh size. The expiration date on the bag.

50 Filters/Box (6 Pounds)

200 or 250 Filters/Case (24 or 30 Pounds)

Not Applicable

key physical parameters of radioiodine collection filter cartridge efficiencies
Key Physical Parameters of Radioiodine Collection Filter Cartridge Efficiencies
  • Adsorbent bed thickness
  • Flow rate of pollutant stream passing

through filter

  • Temperature of pollutant stream
  • Specific pollutant species
  • Relative humidity of pollutant stream
  • Type of adsorbent
  • Mesh size of adsorbent in filter
  • Sample duration
  • Bed compaction
astm d3803 1989 parameters
ASTM D3803, 1989 Parameters
  • Pressure 1 atm
  • Temperature 30o C
  • Pre-equilibration Period 16 hours
  • Equilibration Period 120 minutes
  • CH3I Concentration 1.75 mg/m3
  • Loading Duration 60 minutes
  • Post Sweep Period 60 minutes
  • Bed Depth 2 inches
  • Velocity of Gas Stream 11.6 to 12.8 m/min.
  • Relative Humidity 95%
f j s modifications to astm d3803 1989 test method
F&J’s Modifications to ASTM D3803, 1989 Test Method
  • The 2 inch bed depth is modified to the bed depth of the specific filter cartridge geometry.
  • Variable flow rates are utilized to determine the relationship of efficiency vs. flow rate for each filter cartridge manufactured by F&J.
  • Various sample durations were utilized to represent typical field sampling scenarios.
test conditions for f j sampling scenarios
Test Conditions For F&J Sampling Scenarios

SHORT- INTERMEDIATE- LONG-

PARAMETERS TERM TERM TERM

Pre-equilibration period (hrs.) None 16 16

Equilibration period (hrs.) None 2 2

Loading duration (hrs.) 1 1 1

Post sweep duration (hrs.) 1 1 168

CH3I concentration (mg/m3) 1.75 1.75 1.75

Pressure (atm) 1 1 1

Bed depth Actual filter Actual filter Actual filter

Flow rate ~14 to 198 LPM ~14 to 198 LPM ~14 to 198 LPM

Temperature (ºC) 30 30 30

Relative Humidity (%) 90-95 95 95

slide14

Equations for Methyl Iodide Collection Efficiency vs. Flow Rate for

TEDA Impregnated Charcoal Cartridges and Silver Zeolite

Cartridges Applicable to Series C, CS, CSM, B and M

Short-Term Sampling Scenario

Adsorbent Type X = CFM Equations X = LPM Equations

AGZ58 y = -0.3725x2 + 0.8855x + 99.328 y = -0.0005x2 + 0.0313x + 99.328

TEDA-1 y = 0.3845x2 – 7.1557x + 106.04 y = 0.0005x2 – 0.2529x + 106.04

TEDA-2 y = -0.4758x2 + 0.8722x + 99.689 y = -0.0006x2 + 0.0308 + 99.689

TEDA-3 y = -0.1253x2 – 3.4068x + 101.52 y = -0.0002x2 – 0.1188x + 101.54

TEDA-4 y = -1.06x2 + 3.43x + 97.24 y = -0.0013x2 + 0.1212x + 97.24

Intermediate-Term Sampling Scenario

Adsorbent Type X = CFM Equations X = LPM Equations

AGZ164 y = 0.2946x2 – 7.2553x + 105.73 y = 0.0004x2 –0.2562x + 105.73

AGZ35 y = 0.0845x2 – 4.0033x + 103.36 y = 0.0001x2 –0.1414x + 103.36

AGZ58 y = 0.39x2 – 1.4622x + 101.06 y = -0.00007x2 –0.018x + 100.36

TEDA-1 y = 1.8549x2 – 20.107x + 107.86 y = 0.0023x2 –0.7102x + 107.86

TEDA-2 y = 0.2646x2 – 0.3535x + 100.45 y = -0.0003x2 –0.0125x + 100.45

TEDA-3 y = 0.0467x2 – 4.3026x + 104.13 y = 0.00006x2 –0.1519x + 104.13

TEDA-4 y = 3.5938x2 – 26.102x + 110.58 y = 0.0045x2 –0.922x + 110.59

Long-Term Sampling Scenario

Adsorbent Type X = CFM Equations X = LPM Equations

TEDA-1 y = 2.295x2 – 20.365x + 103.33 y = 0.0029x2 –0.7192x + 103.33

TEDA-2 y = -0.1414x2 – 0.3481x + 99.923 y = -0.0002x2 –0.0123x + 99.923

TEDA-3 y = -0.4928x2 – 1.3921x + 100.91 y = -0.0006x2 –0.0492x + 100.91

TEDA-4 y = -1.22x2 – 6.23x + 100.49 y = -0.0015x2 –0.2211x + 100.52

factors affecting efficiencies of radioiodine collection cartridges
Factors Affecting Efficiencies of Radioiodine Collection Cartridges
  • Species Impact

Collection efficiency of I2(g) > Collection efficiency of CH3I(g)

  • Temperature Impact

Efficiency increases with an increase in temperature

  • Relative Humidity Impact

Efficiency decreases with an increase in relative humidity

  • Flow Rate Impact

Efficiency decreases with an increase in flow rate

  • Bed Depth Impact

Efficiency increases with an increase in bed depth of the cartridge

  • Sample Duration Impact

Efficiency decreases with an increase in sample duration

  • Particle Size Impact

Efficiency increases with a decrease in particle size of the

adsorbent
