  1. Externaltroposphericfiles in VieVS Matthias Madzak

  2. Externaltroposphericfiles • Troposphericdelays in onetxtfile per session • Different modelsavailable • Easy exchangeability • Useofowndatapossible VieVS User Workshop 2011

  3. Content of .trpfiles Session Date,Time α, ε, p, T Partial derivatives Station Slantdelay VieVS User Workshop 2011

  4. Steps • Troposphericparameterfile • Whatmodelstobeused ? • Externaltroposhericfile (.trp) • Forwhichsession(s) ? • Use in VieVS  Processsession(s) VieVS User Workshop 2011

  5. Troposphericparameterfile (1) • Created via GUI • Definesmodelsfor all stations • Run TRP\ PROGRAM\ GUI\ createTropoParameterFilesGUI.m VieVS User Workshop 2011

  6. Troposphericparameterfile (2) • Set troposphericmodelsfor all stations (1 | 0) - Save textfile VieVS User Workshop 2011

  7. Models fortroposphericfiles • Mapping Functions • VMF1 • GMF • Delay • ECMWF (h/w) • Surfacepressure • Global PressureandTemperature • Gradients • LHG • DAO • APG • Partial derivatives • VMF1w • GMFw VieVS User Workshop 2011

  8. Externaltroposphericfiles • Define (just created) parameterfile 2. Select stations 3. Choosesubfolder 4. Click „Create“  \TRP [\subfolder] \*.trp VieVS User Workshop 2011

  9. Note • Session must beprocessedbeforeonce • Read log (Command Window) forinformation VieVS User Workshop 2011

  10. Usefiles in VieVS • GUI vie_mod • Click „External (.trp) file“ • Select subfolder (ifchosen) • Delaysareapplied VieVS User Workshop 2011
