arp spoofing arp

ARP Spoofing-ARP 攻擊-

報告者

A0963328 洪靖雅

slide2
報告大綱
  • 何謂ARP、RARP
  • ARP運作方式
  • ARP Spoofing
  • 防止ARP攻擊的方法
arp rarp
何謂ARP、RARP
  • ARP(Address Resolution Protocol)
    • 位址轉換協定
    • 僅能在區域網路內使用
    • 用IP找MAC
  • RARP(反向ARP)
    • 反向位址轉換協議
    • 用MAC找IP

Strange:像人不知道自己的名字

slide4
ARP運作方式

廣播(ARP request):誰是192.168.0.2?

請告訴我,我是Gateway。

  • 由 ARP request (ARP 查詢) 與 ARP reply (ARP 回應) 兩種封包組成

回應(ARP reply):

我是192.168.0.2

我記住你是Gateway了!

正牌Gateway

arp spoofing
ARP Spoofing

廣播(ARP request):誰是192.168.0.2?

請告訴我,我是Gateway。

回應(ARP reply):

我是192.168.0.2

我記住你是Gateway了!

正牌Gateway

arp spoofing1
ARP Spoofing

這裡是MAC A

我的IP是

192.168.0.2

知道了!

增加MAC A到ARP table

MAC A

IP192.168.0.2

Router

普通HUB

MAC R

IP192.168.0.1

ARP table-Router

MAC IP

A 192.168.0.2

MAC B

IP192.168.0.3

ARP table-PC B

MAC IP

A 192.168.0.2

arp spoofing2
ARP Spoofing

收到資料!

192.168.0.2的資料傳到MAC A

MAC A

IP192.168.0.2

ARP table-PC A

MAC IP

R 192.168.0.1

Router

普通HUB

MAC R

IP192.168.0.1

ARP table-Router

MAC IP

A 192.168.0.2

MAC B

IP192.168.0.3

ARP table-PC B

MAC IP

A 192.168.0.2

arp spoofing3
ARP Spoofing

MAC A

IP192.168.0.2

ARP table-PC A

MAC IP

R 192.168.0.1

B 192.168.0.3

Router

普通HUB

MAC R

IP192.168.0.1

ARP table-Router

MAC IP

A 192.168.0.2

B 192.168.0.3

MAC B

IP192.168.0.3

這裡是B,網域裡有誰?

ARP table-PC B

MAC IP

A 192.168.0.2

arp spoofing4
ARP Spoofing

這是MAC A,

IP是192.168.0.2

這是MAC R,

IP是192.168.0.1

MAC A

IP192.168.0.2

ARP table-PC A

MAC IP

R 192.168.0.1

B 192.168.0.3

Router

普通HUB

MAC R

IP192.168.0.1

ARP table-Router

MAC IP

A 192.168.0.2

B 192.168.0.3

MAC B

IP192.168.0.3

ARP table-PC B

MAC IP

A 192.168.0.2

R 192.168.0.1

arp spoofing5
ARP Spoofing

更新ARP table

更新ARP table

MAC A

IP192.168.0.2

ARP table-PC A

MAC IP

R 192.168.0.1

B 192.168.0.3

B 192.168.0.1

Router

普通HUB

MAC R

IP192.168.0.1

Router的假位址在MAC B

ARP table-Router

MAC IP

A 192.168.0.2

B 192.168.0.3

B 192.168.0.2

MAC B

IP192.168.0.3

電腦A的假位址在MAC B

ARP table-PC B

MAC IP

A 192.168.0.2

R 192.168.0.1

arp spoofing6
ARP Spoofing

將資料傳到Router

(MAC B)

192.168.0.2的資料傳到MAC B

MAC A

IP192.168.0.2

ARP table-PC A

MAC IP

R 192.168.0.1

B 192.168.0.3

B 192.168.0.1

Router

普通HUB

MAC R

IP192.168.0.1

ARP table-Router

MAC IP

A 192.168.0.2

B 192.168.0.3

B 192.168.0.2

MAC B

IP192.168.0.3

ARP table-PC B

MAC IP

A 192.168.0.2

R 192.168.0.1

slide12
防止ARP攻擊的方法
  • 控管MAC address
    • 將MAC address與IP綁定,不允許更改
  • 加裝VLAN Switch
    • 網域內的用戶端只會看到Router
slide13

The End.

Thanks for your attention.
