  1. GEARS Jakub Farkaš 4.C

  2. shaft diameter centering dimple shaft (hřídel) cog wheel (ozubené kolo) outside diameter (vnější průměr) cog (zub) groove (drážka) helical gearing (šikmé ozubení) inside diameter (vnitřní průměr)

  3. Description A gear is a component used to transmit a force from one device to another. Unlike pulley, gears are wheels which have teeth (or cogs), which fit into to teeth of another wheel. Thus the rotational torque can be transferred without any slippage. Various gears can transmit forces from the power source at different speeds or in different directions. The cog wheels usually interlace with another cog wheel, but in fact any device with compatible teeth can be used, such as linear racks.The most important feature of gears is that various wheels with different diameters can be combined. Thus the rotational speed of the second cog wheel gets higher or lower.
