signals and systems 1 lecture 3 dr ali a jalali august 23 2002
Signals and Systems 1

Lecture 3

Dr. Ali. A. Jalali

August 23, 2002

signals and systems 1
Signals and Systems 1

Lecture # 3

Introduction to Signals

EE 327 fall 2002

example 1
Example 1
  • Example 1
  • Interpret and sketch the generalized function x(t) where

EE 327 fall 2002

example 1 solution
Example 1:Solution:
  • To determine the meaning of x(t) we place it in an integral
  • Let  = t+4 so that
  • From the definition of the unit impulse,

The integral equals e-1 . Therefore

EE 327 fall 2002

example 1 graphical solution
Example 1: Graphical solution
  • The result can also be seen graphically. The left panel shows both and (t+4), and the right panel shows their

t

EE 327 fall 2002

unit impulse what do we need it for
Unit impulse- what do we need it for?
  • The unit impulse is a valuable idealization and is used widely in science and engineering. Impulses in time are useful idealizations.
  •  Impulse of current in time delivers a unit charge instantaneously to network.
  •  Impulse of force in time delivers an instantaneous momentum to a mechanical system.

EE 327 fall 2002

unit impulse what do we need it for7
Unit impulse- what do we need it for?
  • Impulses in space are also useful.
  •  Impulse of mass density in space represents a point mass.
  •  Impulse of charge density in space represents a point charge.
  •  Impulse of light intensity in space represents a point of light.
  • We can imagine impulses in space and time
  •  Impulse of light intensity in space and time represents a brief flash of light at a point in space.

EE 327 fall 2002

unit step function
Unit Step Function
  • Integration of the unit impulse yields the unit step function

which is defined as

EE 327 fall 2002

unit step function figure 1 7a text
Unit Step Function (Figure 1.7a text)

%F1_7a Unit step function

t=-2:0.01:5; % make t a vector of 701 points

q=size(t);

f=zeros(q(1),q(2)); % set f = a vector of zeros

q=size(t(201:701));

f(201:701)=ones(q(1),q(2));% set final 500 points of f to 1

plot(t,f),title('Fig.1.7a Unit step function');

axis([-2,5,-1,2]); % sets limits on axes

xlabel('time, t');

ylabel(' u(t)');

grid;

Generic step

function

EE 327 fall 2002

f1 7b signal g t multiplied f 101 501 2 5 cos 5 t 101 501 by a pulse functions u t 1 u t 3
%F1_7b Signal g(t) multiplied f(101:501)=2.5-cos(5*t(101:501) by a pulse functions ([u(t+1)-u(t-3)]

%F1_7b Signal g(t) multiplied by a pulse functions

t= -2:0.01:5;

q=size(t);

f=zeros(q(1),q(2));

f(101:501)=2.5-cos(5*t(101:501));

plot(t,f),title('Fig.1.7b Signal g(t) multiplied by a pulse functions');

axis([-2,5,-1,4]);

xlabel('time, t');

ylabel(' g(t)[u(t+1)-u(t-3)]');

grid;

EE 327 fall 2002

unit impulse as the derivative of the unit step
Unit impulse as the derivative of the unit step
  • As an example of the method for dealing with generalized functions consider the generalized function
  • Since u(t) is discontinuous, its derivative does not exist as an ordinary function, but it does as a generalized function. To see what x(t) means, put it in an integral with a smooth testing function
  • And apply the usual integration-by-parts theorem
  • to obtain

EE 327 fall 2002

unit impulse as the derivative of the unit step cont d
Unit impulse as the derivative of the unit step. Cont’d
  • The result is that
  • which, from the definition of the unit impulse, implies that
  • That is, the unit impulse is the derivative of the unit step in a generalized function sense.

EE 327 fall 2002

real exponential functions
Real Exponential Functions
  • Exponential signals are characterized by exponential function

Where e is the Naperian constant 2.718… and a and A are real constants.

f(t)

Time, t

ramp functions
Ramp Functions
  • A shifted ram function with slop B is defined as

Unit ramp function being at t=0 by making B=1 and t0=0 and multiplying by u(t), giving

f(t)

r(t)=tu(t)

Time, t

successive integration of the unit impulse
Successive integration of the unit impulse
  • Successive integration of the unit impulse yields a family of functions.
  • Later we will talk about the successive derivatives of (t), but these are too horrible to contemplate in the first lecture.

EE 327 fall 2002

sinusoidal functions
Sinusoidal Functions
  • A sinusoidal function

frequency in hertz or cycles per second, the phase shift in radians, the radian frequency is rad/s and the period

is s

Exponential functions, as in

Where B is the amplitude, is angular frequency in radians/second, and is the phase shift in radians.

EE 327 fall 2002

exponentialy modulated sinusoidal functions
Exponentialy Modulated Sinusoidal Functions
  • If s sinusoid is multiplied by a real exponential, we have an exponentially modulated sinusoid

that also can arise as a sum of complex exponentials, as in

Example:

Turned on at t = +1

by multipling shifted

unit stepu(t-1)

EE 327 fall 2002

building block signals can be combined to make a rich population of signals
Building-block signals can be combined to make a rich population of signals
  • Eternal complex exponentials and unit steps can be combined to produce causal and anti-causal decaying exponentials.

EE 327 fall 2002

building block signals can be combined to make a rich population of signals20
Building-block signals can be combined to make a rich population of signals
  • Unit steps and ramps can he combined to produce pulse signals.

EE 327 fall 2002

example
Example:

f(t)

  • Describe analytically the signals shown in

Solution: Signal is (A/2)t at , turn on this signal at t = 0 and turn it off again at t = 2. This gives,

A

t

0

2

See page 9 of text for more examples.

EE 327 fall 2002

sequences
Sequences
  • Unite Sample Sequence
  • The unit sample sequence is the discrete-time version of the unit impulse in CT situations.
  • Definition of unit sample sequence:
  • Thus it is possible to represent an arbitrary sequence as the weighted sum of unit sample sequences.

1

1

0

0

n

1

3

2

n

m = n

m = n-3

Plots of Unite Sample Sequence

sequences23
Sequences
  • Unite Step Sequence
  • The unit step sequence is the discrete-time version of the unit step in CT situations.
  • Definition of unit step sequence:
  • The unit step sequence u(n) is related to unit sample sequence by

U(n)

1

Generic step sequence

0

1

3

2

n

Plots of Unite Step Sequence

sequences24
Sequences
  • Ramp Sequence
  • A shifted ramp sequence with slop of B is defined by:
  • The unit ramp sequence and shifted ramp sequences
  • Example: g(t) = 2(n-10).

MATLAB Code:

n=-10:1:20;

f=2*(n-10);

stem(n,f);

EE 327 fall 2002

real exponential sequences
Real Exponential Sequences
  • Real exponential sequence is defined as:

Example for A = 10 and a = 0.9, as n goes to infinity the sequence approaches zero and as n goes to minus infinity the sequence approaches plus infinity.

Composite sequence:

Multiplying point by

Point by the step sequence

MATLAB Code:

n=-10:1:10;

f =10*(.9).^n;

stem(n,f);

axis([-10 10 0 30]);

EE 327 fall 2002

sinusoidal sequence
Sinusoidal Sequence
  • A sinusoidal sequence may be described as:
  • Where A is positve real number (amplitude), N is the period, and a is the phase.
  • Example:
  • A = 5, N = 16
  • And
  • MATLAB Code:
  • n=-20:1:20;
  • f=5*[cos(n*pi/8+pi/4)];
  • stem(n,f);

EE 327 fall 2002

exponentialy modulated sinusoidal sequence
Exponentialy Modulated Sinusoidal Sequence
  • By multiplying an exponential sequence by sinusoidal sequence, we obtain an exponentially modulated sequence described by:
  • Example:
  • A = 10, N = 16, a = 0.9
  • And
  • MATLAB Code:
  • n=-20:1:20;
  • f=10*[0.9 .^n];
  • g=[cos(2*n*pi/16+pi/4)];
  • h=f .*g;
  • stem(n,h);
  • axis([-20 20 -30 70]);

EE 327 fall 2002

example28
Example:
  • Use the Sequence definition, describe analytically the following sequence.

f(n)

1

A Pulse Sequence

0

1

2

-2

-1

3

n

Solution: This pulse sequence can be describe by

f(t) = u(n) – u(n-3).

The first step sequence turn on the pulse at n = 0,

and second step turns it off at n = 3.

See page 13 of text

For more examples.

EE 327 fall 2002

a road map signals and systems
A Road MapSignals and Systems

Ordinary DE

Laplace transform

Z transform

Convolution

Simulation

Hock up

Fourier transform

Fourier series

Transfer function

State space model

Signal flow graph

Block diagram

Unit sample response

Frequency response

Mathematical Model,

usually difference or

differential equations

LP Filter

Spring Mass

Dc Motor

Any phisical

systems

Solutions

Find

x(t) or

x(n)

Implementation

or x(n+1)

Time Domain and Frequency Domain solutions.

Continuous and Discrete-time Systems.

EE 327 fall 2002

conclusions
Conclusions
  • Introduction to signals and systems,
  • Signals, definitions and classifications,
  • Building block signals- eternal complex exponentials and impulse,
  • Mathematical description of signals,
  • MATLAB examples,
  • A road map.
