  1. Introducing

  2. Introducing • NEW Budget, High Performance, Low Cost Receipt Printer designed specifically to meet basic receipt printing needs with high reliability for the harshest of environments.

  3. Designed Specifically for the Indian Marketplace • High Reliability 60 million lines MCBF • Lever-free paper loading increasing reliability • “Intelligent” Star Design with advanced splash-proof design – even the PCB is mounted upside down to maintain higher reliability than our competitors.

  4. “Intelligent” Star Design with advanced splash-proof design – even the PCB is mounted upside down to maintain higher reliability than our competitors. • Cables run outside of the chassis to prevent water from flowing into the PCB along them. The LED indicator is covered with the external case to prevent water from entering BSC10 Existing models

  5. Low Cost Installation • Power supply included in box • ESC/POS™ Emulation • Dual Interface as standard USB/Parallel or USB / Serial • All-inclusive StarPRNT driver and utility • suite with WHQL certification on CD in box • NO DIP Switches!

  6. Star Configuration Utility All-inclusive StarPRNT driver and utility suite with WHQL certification on CD in box DMA-48EDIII • ESC/POS™ emulation with Star Configuration Utility including OPOS™ and Epson cash drawer compatibility • Increased “Drop-In” Efficiency

  7. Low Cost Maintenance • Low cost replacement of print head, cutterand PCB. Simply remove the front printer cover to access the cutter and print head or black plate to access the main printer circuit • board (PCB).

  8. How to Replace the Cutter Unit Remove the cutter unit. (2 screws) Unplug the sensor connector Remove the front cover How to Replace the Stationary Knife Rear Cover Unit Remove 4 screws. Replace the Stationaryknife. (same as TSP654)

  9. How to Replace the Thermal Print Head Remove the cutter unit. Remove the cutter unit. (2 screws) Remove the front cover. How to Replace the Main PCB Disconnect the head connector from the flexible flat cable. Replace the head unit. • Disconnect the connectors. • Replace the Main PCB. • (4 screws) Remove the board chassis . (4 screws for chassis, 2 screws for I/F)

  10. Low Cost InstallationLow Cost Maintenance • High Reliability • High Performance True Print Speed 250mm/sec. Paper Feed Speed 300mm/sec. • FULL Value for Money

  11. z High Performance • Remember just because a manufacturer says their printer is fast does not mean it is. Just look at the results below. First print time (Graphic) in Second Competitor #1 Competitor #2 Competitor #3 Competitor #4 BSC-10

  12. StarPRNT Intelligence • ESC/POS™ Emulation with StarPRNT Intelligence & Configuration Utility • • Advanced Logo Store

  13. If you highlight the row, you can preview the image and even edit it. Export lets you save the image to your PC. Import, of course, imports the image so integrators do not have to repeat changes for multiple installs

  14. StarPRNT Intelligence • ESC/POS™ Emulation with StarPRNT Intelligence & Configuration Utility • • Advanced Logo Store • • “Text-Triggered” Image Printing – perfect • for Couponing etc.

  15. Cost / Time Saving Advantages 10cm Roll Capacity with 60% more Paper = Reduced Cost per Receipt = Less Paper Roll Changes = Reduced Paper Transport & Storage costs

  16. Additional Specifications • Dimensions 142 (W) x 212 (D) x 149 (H) mm • Weight 1.34 kg • Resolution 203 dpi • Paper Loading “Drop-In & Print”, Easy-Load

  17. Competitive Summary • Design & Reliability • 10 cm Paper Roll Advantages • StarPRNT Intelligence • Low Cost Installation • Low Cost Maintenance

  18. Introducing
