exploring artificial neural networks to discover higgs at lhc

Exploring Artificial Neural Networks to Discover Higgs at LHC

Using Neural Networks for B-tagging

By Rohan Adur

www.hep.ucl.ac.uk/~radur

exploring artificial neural networks to discover higgs at lhc1
Exploring Artificial Neural Networks to Discover Higgs at LHC

Outline:

  • What are Neural Networks and how do they work?
  • How can Neural Networks be used in b-jet tagging to discover the Higgs boson?
  • What results have I obtained using Neural Networks to find b-jets?
neural networks introduction
Neural Networks - Introduction
  • Neural Networks simulate neurons in biological systems
  • They are made up of neurons connected by synapses
  • They are able to solve non-linear problems by learning from experience, rather than being explicitly programmed for a particular problem
the simple perceptron
The Simple Perceptron

Output layer

  • The Simple Perceptron is the simplest form of a Neural Network
  • It consists of one layer of input units and one layer of output units, connected by weighted synapses

Synapses connected by weights

Input layer

slide5

The Simple Perceptron contd.

  • Requires a training set, for which the required output is known
  • Synapse weights start at random values. A learning algorithm then changes the weights until they give the correct output and the weights are frozen
  • The trained network can then be used on data it has never seen before

Output layer

Synapses connected by weights

Input layer

the multilayer perceptron
The Multilayer Perceptron

Output layer

  • The main drawback of the simple perceptron is that it is only able to solve linearly-separable problems
  • Introduce a hidden layer to produce the Multilayer Perceptron
  • The Multilayer Perceptron is able to solve non-linear problems

Synapses

HiddenLayer

Synapses

Input layer

finding higgs
Finding Higgs
  • The Higgs boson is expected to decay to b-quarks, which will produce b-jets
  • b-jet detection at LHC is important in detecting Higgs
  • 40 million events happening per second
  • b-taggers must reject light quark jets
b tagging
b-tagging
  • B mesons are able to travel a short distance before decaying, so b-jets will originate away from the primary vertex
  • Several b-taggers exist
  • IP3D tagger uses the Impact Parameter of the b-jets

~ 1mm

Primary Vertex

B

B-jets

Secondary Vertex

IP

  • SecVtx tagger reconstructs the secondary vertex and rejects jets which have a low probability of coming from this vertex
ip3d tagger
IP3D Tagger
  • Good amount of separation between b-jets and light jets
neural network for b tagging
Neural Network for b-tagging
  • The current best tagger is a combination of IP3D and SV1 tag weights
  • Using Neural Networks, can this tagger be combined with others to provide better separation?
the multilayer perceptron and b tagging
The Multilayer Perceptron and b-tagging
  • The TMultiLayerPerceptron class is an implementation of a Neural Network built into the ROOT framework
  • It contains several learning methods. The best was found to be the default BFGS method
  • Train with output = 1 for signal and output = 0 for background
  • The b-tagging weights were obtained using the ATHENA 10.0.1 release
  • The data was obtained from Rome ttbar AOD files
  • Once extracted, the weights were used to train the Neural Network
results
Results
  • 5 Inputs used: Transverse momentum, IP3D tag, SV1 tag, SecVtx Tag and Mass
  • 12 Hidden units and 1 Output unit
results contd1
Results Contd.

Rejection rates

Mistagging efficiency

At fixed rejection

discussion of results
Discussion of Results
  • Using a Neural Network, b-taggers can be combined to provide up to double the purity at fixed efficiency
  • At fixed rejection rate, the Neural Network provides 5% more signal than the IP3D+SV1 tagger alone
  • Neural Network performance is not always reproducible. Each time training is undertaken a different network is produced
conclusions
Conclusions
  • Neural Networks are a powerful tool for b-jet classification
  • Neural Networks can be used to significantly increase b-tagging efficiency/rejection ratios and could be useful in the search for Higgs
  • Training a Neural Network on real data will be the next hurdle
