  1. Centralized Management using Forefront Protection Server Management Console (FPSMC) Priya Ravichandran Program Manager II Microsoft Corporation (priyar@microsoft.com)

  2. Agenda • Overview • Standalone Management Experience • Forefront Protection Server Management Console 2010 • Demo • Forefront Protection Server Script Kit • Summary

  3. Overview • Forefront Protection 2010 for Exchange Server (FPE) • Provides Antimalware, Antispam and Filtering protection on Exchange 2007 and Exchange 2010 deployments • Released Nov 2009 • Forefront Protection 2010 for SharePoint (FPSP) • Provides Antimalware and Filtering protection on SharePoint 2007 and SharePoint 2010 • Released Apr 2010 • Both products have built-in standalone management capabilities • Comprehensive UI • PowerShell support provides scriptability • Centralized Multi-Node Management • To enable management of FPE and FPSP in the organization

  4. Standalone Management FPE and FPSP • Standalone Console • FPE manage all Exchange Anti-spam settings from single node console • Enables Hybrid Protection Scenarios via FPE FOPE Gateway • PowershellManagement • Rich Powershellsupport that mirrors functionality in the console • Enables command line management and customized scripts

  5. Multi-node Management for Forefront Protection Servers • Forefront Protection Server Management Console 2010 (FPSMC) • Multi-server management of FPE and FPSP in a single web-based interface. • Free download • Available in Q4 CY2010 • Forefront Protection Server Script Kit (FPSSK) • Scripts for discovery, configuration, deployment, and reporting on FPE and FPSP • Free download • Released August 4, 2010.

  6. Forefront Protection Server Management Console 2010 (FPSMC) Centralized Multi-node Management Console for FPE/FPSP servers

  7. FPSMC Capabilities Simplified Management Visibility & Control • Enterprise Ready • Visibility into incidents across FPE, FPSP • Real-time monitoring for security events • User friendly Dashboard view • Real-time and historical reports • Web-based interface for easier access • License distribution and activation • Centralized Quarantine • Manage FPE 2010 and FPSP 2010 • Server Discovery and Grouping • Product patch and FPSMC agent deployment • Deploy policies to custom-defined groups of servers • Manage cross-domain and non-domain server from one console • Firewall friendly communication channel • Signature Redistribution for 32-bit and 64-bit engines • Enterprise ready scalability • Support for SQL scenarios • Business continuity for critical functionality • Manage FPE on Clusters (Exchange 2007 and Exchange 2010) Built on Microsoft Infrastructure • Windows Server 2008 R2 • Hyper-V • WCF • Active Directory • SQL Server 2008 • IE 7.0 and IE 8.0 Microsoft Confidential

  8. Management Console Overview 6 Remote Access over HTTP FPE Servers 1 2 3 Active-Active configuration Communication over WCF 4 7 FPSP Servers Data access via Stored Procedures 5 Data access via Stored Procedures Add servers to FPSMC and deploy Agent Upload policy to FPSMC and create jobs Run jobs to deploy policy Retrieve Quarantine and stats periodically (stored in the Database (5) ) Continuous SQL Replication Enterprise SQL Enterprise SQL Remote access of FPSMC for management ease ( e.g. Run reports) 7. If Backup is deployed, servers and jobs replicated across SQL ; Backup functions alongside Primary in a Active-Active configuration Backup FPSMC Primary FPSMC

  9. Microsoft® Forefront Protection Server Management Console 2010 - Tour of the environment- Import Policy- Policy Distribution- Reporting demo

  10. Migrating from FSSMC to FPSMC • FSSMC Migration to FPSMC not supported • FSSMC is 32-bit only; FPSMC is 64-bit only • FSSMC only supports SQL 2005; FPSMC requires SQL 2008 • FPSMC and FSSMC must both be deployed to manage a mixed deployment • FPSMC to manage FPE/FPSP • FSSMC to manage FSE/FSSP/Antigen

  11. Forefront Protection Server Script Kit (FPSSK)

  12. FPSSK Overview • Management of FPE and FPSP servers using scripts • Solution based 100% on PowerShell features • Based on PowerShell v2.0 remoting • Leveraged in-market FPE/FPSP PowerShell cmdlets • No new compiled code • Easily customizable and extensible • FPSSK complements FPSMC functionality • Enables some features not included in FPSMC e.g. policy compliance

  13. FPSSK Base Scripts • Scripts can be extended to meet customer needs

  14. Summary • Forefront Protection Server Management Console 2010 • Provides multi-server management for all FPE and FPSP deployments in the organization • Management of jobs on the target server • Centralized Quarantine Management • On-demand and email reports • Available in Q4 CY2010 as a free download • Forefront Protection Server Script Kit • Provides scripting management solution • Base set of scripts that can be extended to meet customer need • Complements FPSMC

  15. Business Ready Security Demo Environment (VHD) 4.0c Introducing

  16. Business Ready Security Demo Environment 4.0c • End to end demo environment • All Identity and Security Solutions/Technologies • 7 GB size zipped/installer package • Demo scripts/architecture overview documentation providedAvailable as download at • Microsoft FW Link http://go.microsoft.com/fwlink/?LinkId=190269

  17. Business Ready Security Demo Environment - Scenarios

  18. Appendix

  19. Deployment • Installs on Windows Server 2008 R2 • Prerequisites • SQL2008R2 Express (if not using SQL Enterprise) • MS Chart Control for .Net 3.5 • Windows Additional Components ( e.g. IIS) • 2 deployment options • Standalone • Will install SQL Server 2008 R2 Express by default • Support both Express and Enterprise versions of Microsoft SQL Server • Cannot be used to connect to a Backup server • Primary/Secondary • Primary is identical to the Standalone server; Requires SQL enterprise • Backup requires primary to be already deployed • Primary and Secondary deployments cannot be on the same server

  20. Access to the Console • Web access for the UI • http://<FPSMCserver>/FPSMConsole • HTTPS must be enabled by the Admin • Initial Access is limited to the Installation Admin • Other users must be added via the console • Access limited to Administrators • Local Admin, Domain Admin, Exchange Admin, Enterprise Admin • This is a change from Forefront Server Security Management Console (FSSMC)

  21. FPSMC Home Page • Side Navigation bar provides quick access to desired functionality • At-a-glance provides 24-hour activity snapshot • Stats broken out by Exchange and SharePoint • Top 5 viruses • Most active servers • Highlighted navigation and ‘breadcrumb bar’ for current location

  22. Server Management • FPSMC can manage domain joined servers and non-domain joined servers • E.g. Edge servers, Perimeter SharePoint deployments • Automatic discovery of FPE and FPSP servers within AD • Displayed under “New Servers” • Must be added to FPSMC to be managed • Non-domain joined servers can be manually added • Need to enter FQDN • Servers can be managed as groups

  23. Management Agent • Agent must be deployed to the FPE/FPSP server • Pushed out from FPSMC server • Requires port 445 to be opened for Agent deployment • Local Admin credentials on target server needed • Agent deployment status displayed in the console • Once successful, version of Forefront on managed server is displayed • Detailed logs available under “Notification Logs”

  24. Job Management • 4 types of jobs • Deployment job (Policy and Patch) • Signature Redistribution Job • Scheduled Report Job • Product Activation Job • Jobs can be scheduled or run on demand • Jobs can be scoped to target a specific set of servers • Configured by the Administrator

  25. Job Management • Deployment (Policy/Patch) • Policy Deployments distribute FPE/FPSP configuration files (XML format) • Partial policy enabled • Credentials, if applicable, must be entered as well • Patch deployment jobs will push out .exe and .msp files • Cannot deploy the initial FPE or FPSP install. • Signature Redistribution • No jobs by default • Can customize jobs by engine and by target server(s) • Will download and then distribute

  26. Job Management • Scheduled Report • Generates and emails reports – daily, weekly or monthly • Always sends 4 reports • Product Activation • Activate Eval FPE/FPSP servers by deploying Activation key • Renew expiring subscriptions by distributing new License Key and expiry date

  27. Quarantine Management • Centralized management • Configurable retrieval period and polling interval • Defaults to retrieving 5 days of records and polling every 15 min • Broken out by Exchange and SharePoint • Enables deliver/restore of false positives directly from console • Results can be filtered for quicker recovery

  28. Reporting • On-demand • Incident Detection, Spam Detection, Engine and Definition Version • Report scoped based on date range and desired servers • Report includes distribution of detections, trending and raw data • Scheduled • Delivered via email

  29. Online Integration • FOPE Gateway can be specified in Policies to be deployed in the servers • FOPE Administration links • Admin Center, Message Tracing, Hosted Quarantine, and Reports
