The potential to feed nitrates to reduce enteric methane production in ruminants

The Potential to Feed Nitrates to Reduce Enteric Methane Production in Ruminants

By

R A Leng AO, D.Rur.Sc.

Emeritus Professor UNE-Armidale


The issues in a nut shell 1
The issues in a nut shell 1 Production in Ruminants

  • Globally ruminants produce around 80x106 tonnes of methane

  • Methane production from reduction of carbon dioxide allows reduced cofactors generated in fermentative digestion to be re-oxidized allowing feed intake and digestion to be continuous. An electron sink is essential in rumen digestion.


The issues in a nut shell 2
The issues in a nut shell 2 Production in Ruminants

  • The rumen milieu can use sulphate and nitrate as alternative electron acceptors with the production of hydrogen sulphide and ammonia.

  • Sulphate is eliminated for this purpose as the end product, hydrogen sulphide would be toxic at the dietary levels required.

  • Nitrate would be the choice electron acceptor since the sink is ammonia the preferred fermentable –N source for synthesis in cell growth. However, under some nutritional conditions/feed management nitrate becomes toxic because of the accumulation of nitrite in the rumen


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

The pathways of nitrate metabolism in the rumen are uncertain but have always been assumed to be by dissimilatory nitrate reduction (DNR) to ammonia

Overall reaction

  • NO3-+2H+ ---------H2O+NO2- --------------------1

  • NO2-+6H+ ---------H2O+ NH3 -------------------2

    Organisms capable DNR of nitrate to nitrite and assimilatory nitrite reduction(ANR) to ammonia use formate and hydrogen as the common electron donors

  • 3HCO-2+NO2-+5H+=3 CO2+NH+4+2H2O ---------- 3

  • 3H2+NO2-+2H+ = NH+4 +2H2O ------------------4

    The newly discovered NR-SOB organisms use hydrogen sulphide as an electron donor for respiratory nitrite ammonification

  • 3HS- + NO2- +5H+ = 3S0 + NH+4 +2H2O --------5



The sticking point
The sticking point inhabiting microbes (Nolan 1999

Nitrate has been rejected as a potential N source for ruminants that would also inhibit methane production because nitrite accumulated in rumen fluid when nitrate was administered to animals without prior adaptation.

Nitrite is anti-nutritional because it is absorbed and causes mild to extreme methaemoglobinaemia. The symptoms varying from a loss of production to death of the animal

Leng R A (2008) The potential of feeding nitrate to reduce enteric methane production in ruminants A Report to The Department of Climate Change, Commonwealth Government of

Australia Canberra ACT Australia


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
Changes in nitrate and nitrite in rumen fluid of a cow after ingesting hay over 45 minutes, containing 82 g of nitrate (Kemp et al 1977)


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
The changes in methaemoglobin in blood of cattle with increasing amounts of nitrate entering the rumen (after Crawford et al 1965).


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
Relationship between the peak concentration of nitrite in rumen fluid and methaemoglobin in the blood of cows (Kemp et al 1977)


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Critical leads suggesting that there is potential for nitrate to be used as a fermentable N source for ruminants with inhibition of methanogenesis

  • Extreme variability in reported field observations on nitrate toxicosis

    • LD50 (1-10g nitrate/kg body weight). Effects on death rate, abortions, growth rates and milk yield have all been reported as significant or no effects. Indicating many interacting factors

  • Research demonstrating:

    • the substantial capacity of rumen microbes to metabolize nitrate and nitrite to ammonia

    • with acclimation of sheep to nitrate in their diet the ability to metabolize nitrate and nitrite increased 300% and upto 1000%

    • no nitrite accumulated in rumen fluid in vivo or in vitro when nitrate fed in the ration of sheep, no ill effects of nitrate was observed in acclimated animals

    • nitrate could be used as the sole source of fermentable N in sheep fed a purified diet high in starch, indicating it is a source of N for microbial anabolism

    • progressively introducing nitrate into a low protein straw/molasses diets for goats changed a negative N balance to a positive when nitrate provided the sole source of fermentable N

    • nitrate had no ill effects in sheep when introduced into high protein diets at 3-5% of the feed intake.

    • demonstration both in vivo and in vitro that methanogenesis was inhibited by inclusion of nitrate in the diet and /or incubation medium respectively


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
The research goals largely decided the experimental approach to the study of nitrate metabolism in ruminants.

  • The toxicological approach has been the fundamental approach used for the last 16 years by the Japanese school led by Prof J Takahashi

    • 4x4 latin square design where a sub-lethal dose of nitrate was administered and four treatments examined. The objective always to provide an additive (chemical or culture of organisms ) to reduce nitrite accumulation which usually exceeded 2mM.

  • Nutritional approach followed well recognized rules of thumb

    • Nitrate was introduced over a period of days to weeks to allow rumen microbial community to adapt

    • Nitrate was well mixed through the feed and the feed was available two times or more daily. Nitrite was undetectable in the rumen fluid of sheep at all times


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Effect of level of K-nitrate fed to sheep on the nitrate and nitrite disappearance from strained rumen fluid incubated in vitro (Alaboudi and Jones 1985).

Extrapolation to whole animal indicates that the fermentative nitrogen

requirements can be met by nitrate


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Comparison of methaemoglobin produced in dairy heifers fed hay containing nitrate or drenched with an aqueous solution of nitrate(Crawford et al 1965)

This work has been heavily criticized because the animals consumed the

feed only slowly- sensible animal response?


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Average daily feed intake and N-balance in young goats fed molasses/straw (30/60) with K-nitrate. The % K- nitrate in the feed was adjusted upwards every 7th day (Quong Do et al 2008 unpubl.)


The effects in lambs of adding nitrate and sulphur to a concentrate based diet
The effects in lambs of adding nitrate and sulphur to a concentrate based diet.

* SD

Sokolowski et al 1965


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

N-balance (g/N day) and S-balance (g S/day) in lambs given a high concentrate diet supplemented with nitrate or nitrate plus sulphur (after Sokolowski et al 1969)


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

The effects of dietary molybdenum on the clearance of nitrate from rumen fluid of sheep after placing 500g of feed containing 6.5% K-nitrate and 6.5% Na-nitrate into the rumen (Tillman et al 1965).

The difference in nitrate concentration appears to be only due to nitrite production


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

The effects of dietary Mo on the accumulation of nitrite in rumen fluid of sheep after placing 500g of feed containing 6.5% K-nitrate and 6.5% Na-nitrate into the rumen (Tillman et al 1965).

In the feeding trial no apparent ill effects in lambs were observed when nitrate

was the sole source of fermentable N. Presumably no nitrite was produced


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Changes in nitrate, nitrite and ammonia concentrations in rumen fluid of sheep fasted for 16 hours and injected intra-ruminally with 25g sodium nitrate (Lewis 1951).


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
Clearance of nitrate from rumen fluid of sheep following administration of a nitrate load in different studies.


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
Appearance of ammonia in rumen fluid after and intra-ruminal load of urea or nitrate (Lewis 1951;Stephenson et al 1992)

Note: Nitrate was injected into a 60kg sheep, whereas urea was injected into a 35kg Merino


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
Up to 80% administered nitrate appears to disappear from the rumen within the first hour. Potential explanations for this include:

  • Nitrate and nitrite are rapidly absorbed from the rumen

  • Nitrate is sequestered in microbes

  • Nitrite and possibly nitrate are bound to protein in a similar way as it is bound to haemoglobin

  • Nitrite is reduced rapidly to ammonia which is assimilated to inter-cellular amino acids( alanine) which may be released to the ammonia pool as electron availability is more synchronized with N availability

  • A nitrate load increases outflow of rumen fluid to the lower tract


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

15 rumen within the first hour. Potential explanations for this include:N in rumen fluid ammonia and nitrate plus nitrite of a cow injected intra-ruminally with 120g K-nitrate labeled with 15N (Wang et al 1961)

Nitrate was administered daily for a number of days before the

labeled nitrate was given


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
Mean blood nitrate concentration with time after introduction of cattle to diets containing nitrate (Clarke et al 1970)


Conclusions from whole animal research
Conclusions from whole animal research introduction of cattle to diets containing nitrate (

  • Toxicities from nitrite accumulation in and absorption from the rumen appeared to be the major constraint to replacing urea with nitrate in low protein diets

  • Nitrite accumulation in the rumen only occurs where nitrate is introduced abruptly and in excessive amounts.

  • The rumen milieu can readily adapt to nitrate as a source of fermentable N

  • Sheep on high energy diets supporting high growth rates were unaffected by adding 3.4% nitrate to their diets.

  • Dairy cows producing 16-19L milk/day were unaffected by inclusion of 2% nitrate in feed(Farra and Satter 1971)

  • Sulphur balance was effected by nitrate inclusion in sheep fed concentrate diets.

  • Additional Mo in a diet boosted nitrite production from nitrate. Mo suppresses sulphur reducing bacteria and production of hydrogen sulphide in the rumen


Conclusions from whole animal research1
Conclusions from whole animal research introduction of cattle to diets containing nitrate (

  • Acclimation to nitrate eliminates nitrite accumulation in the rumen removing any detrimental effects

  • Overall it appeared that nitrate ,at high compared to low concentrations was being metabolized by different processes and there appeared to be some interaction with sulphur availability.

  • Understanding the pathways of nitrate and sulphur metabolism offer possible explanations for nitrite accumulation.


The utilization of nitrate in the rumen appears to be different to urea
The utilization of nitrate in the rumen appears to be different to urea

  • Nitrate rapidly disappears from rumen fluid and unlike urea the major route is not by conversion to ammonia

  • Nitrate or nitrite was entering the rumen 24 hours after nitrate had been administered. The source of the nitrite/nitrate maybe

    • Nitrate cycling between body fluid pools and the rumen

    • Nitrate/nitrite released from sequestered nitrate/nitrite in the rumen

    • Nitrate/nitrite is in equilibrium with the another N pool in the rumen( highly unlikely)

  • Nitrate absorbed into blood by humans( 2-4 mM/day) is concentrated up to 10 fold in the saliva. Salivary nitrate is converted to HNO2 by the acid stomach which spontaneously breaks down to nitrite. In the ruminant nitrate would be returned via salivary secretions to the rumen.

  • Nitrate entering the mouth in monogastric animals is reduced to nitrite by populations of organisms resident on the tongue. If the entero-salivary recycling occurred in ruminants it is potentially a significant sources of rumen nitrite when a nitrate load is given in the rumen.


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

The pathways of nitrate metabolism in the rumen are uncertain but have always been assumed to be by dissimilatory nitrate reduction (DNR) to ammonia

Overall reaction

  • NO3-+2H+ ---------H2O+NO2- --------------------1

  • NO2-+6H+ ---------H2O+ NH3 -------------------2

    Organisms capable DNR of nitrate to nitrite and assimilatory nitrite reduction(ANR) to ammonia use formate and hydrogen as the common electron donors

  • 3HCO-2+NO2-+5H+=3 CO2+NH+4+2H2O ---------- 3

  • 3H2+NO2-+2H+ = NH+4 +2H2O ------------------4

    The newly discovered NR-SOB organisms use hydrogen sulphide as an electron donor for respiratory nitrite ammonification

  • 3HS- + NO2- +5H+ = 3S0 + NH+4 +2H2O --------5


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
At least three types of nitrate reductase catalyze the reduction of nitrate to nitrite in anaerobic bacteria

  • Included are:

    • A soluble, assimilatory nitrate reductase (NAS) that is present in the cytoplasm.

    • An energy-conserving nitrate reductase (NAR, for example,NarG,which is encoded by the first gene of the narGHJI operon) with catalytic sites located in thecytoplasm are associated with the cytoplasmicmembrane, from which they receive electronsfor nitrate reduction.

    • A soluble, periplasmic nitrate reductases (NAP) that are found in many Gram-negative bacteria.


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
At least three types of nitrate reductase catalyze the reduction of nitrate to nitrite in anaerobic bacteria

  • Included are:

    • A soluble, assimilatory nitrate reductase (NAS) that is present in the cytoplasm.

    • An energy-conserving nitrate reductase (NAR, for example, NarG,which is encoded by the first gene of the narGHJI operon) with catalytic sites located in thecytoplasm are associated with the cytoplasmicmembrane, from which they receive electronsfor nitrate reduction.

    • A soluble, periplasmic nitrate reductase (NAP) that are found in many Gram-negative bacteria.


Two biochemically distinct nitrite reductases catalyse the reduction of nitrite to ammonia
Two biochemically distinct nitrite reductases catalyse the reduction of nitrite to ammonia

  • The NADH-dependent NirBD nitrite reductase reduces nitrite directly to ammonia in the cytoplasm of some bacteria. NirBD’s role is to detoxify nitrite generated by NarG (the membrane-associated nitrate reductase) during anaerobic growth in the presence of excess nitrate.

  • More widely distributed is the cytochrome c nitrite reductase Nrf, which catalyses the reduction of nitrite to ammonia in the periplasm of Gram-negative bacteria. This enzyme is the terminal component of an electron-transfer pathway in which electrons are transferred from physiological substrates, especially formate (hence Nrf). Nap, the periplasmic nitrate reductase, and Nrf, the periplasmic nitrite reductase, are coordinately regulated to provide a pathway for the reduction of nitrate to ammonia in the periplasm.


Production of nitric oxide occurs in the rumen which may have inhibitory effects on some archae
Production of nitric oxide occurs in the rumen which may have inhibitory effects on some Archae

  • Some bacteria that reduce nitrite directly to ammonia generate NO.

  • NO is produced in the rumen in small amounts when nitrate is included in a diet/medium

  • Although unproven it is a possibility that this NO is produced by one of the enzymes that reduce nitrite to ammonia (NrfA or NirBD).

  • Nitric oxide and other nitrogen oxides inhibit methanogenesis in some Archae

  • W succinogenese ( a rumen microbe) produces nitric oxide when incubated with nitrate

  • Nitrate as a component of the diet may have indirect effects on methanogenesis other then straight out competition for electrons with carbon dioxide, perhaps providing a competitive edge for NRB.


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Inhibitory effects of N-oxides on have inhibitory effects on some ArchaeMethanosarcina barkeri and Methanobacterium bryantii (a Klüber and Conrad, 1998 ;b Clarens et al., 1998)


Some important issues concerning sulphur metabolism in the rumen
Some important issues concerning sulphur metabolism in the rumen

  • The major source of sulphur in grazing ruminants is from the S-amino acids in protein

  • Sulphur is required for organic S compounds that are synthesized in microbial cell growth.

  • Excess sulphur in the rumen is reduced to hydrogen sulphide which has limited solubility and quickly enters the gas head space. The head space gases are eructated and inhaled into the lungs where a proportion is absorbed and converted to sulphate in the liver.

  • Sulphide levels in rumen fluid are low often about 0.1 mM

  • Sulphide in the rumen is rapidly cleared and in cows fasting for 4 hours following a period of grazing, hydrogen sulphide concentrations in the gas space is zero.


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
Sulphur reducing (SRB) and sulphide oxidizing bacteria (NR-SOB) exist in a number of anaerobic ecosystems

  • The SRB in the rumen are grouped by the mechanism used to reduce sulphates:

    • assimilatory process,

    • dissimilatory process.

      In general, the dissimilatory reduction of sulphur compounds is used for the generation of ATP, while the assimilatory process reduces sulphur compounds for incorporation into other organic compounds necessary for cell survival. The dissimilatory pathways are responsible for the reduction of sulphur to hydrogen sulphite and hydrogen sulphide (Desulfovibrio and Desulfotomaculum spp).

      Most SRB are also NRB since they can actively reduce nitrite but not nitrate to ammonia

  • Nitrate reducing, sulphide oxidizing bacteria (NR-SOB) convert nitrate to nitrite and utilize nitrite to oxidize hydrogen sulphide to poly S or sulphate and reduce nitrite to ammonia with the generation of ATP

    (Wolinella succinogenese, Desulfovibrio spp)


Impact of nitrate on sulphur cycle in the anaerobic ecosystems found in oil wells
Impact of nitrate on sulphur cycle in the anaerobic ecosystems found in oil wells

  • Sulphide produced by SRB activity can be recycled to sulphate or sulphur by NR-SOB reducing nitrate to ammonia (DNRA) or in static anaerobic ecosystems denitrification occurs via nitrogen oxides to nitrogen gas.

  • Most SRB can use nitrite as an alternative electron acceptor

  • Introduction of nitrate increases NRB

  • hNRB compete with SRB for organic electron donors, such as lactate, excluding sulphide production and nitrite reduction(?) by SRB. The extent of the effect depending on the fermentation rate (availability of electron donors)

    Many SRB and hNRB oxidize lactate incompletely to acetate and CO2

  • Lowered sulphide availability prevents nitrite ammonification (respiration) by NR-SOB and stimulates nitrate reduction to nitrite which may accumulate


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Sulfurospirillum ecosystems found in oil wellssp switch from nitrite production to ammonia production according to the relative availability of electron donors in the medium- is this a model for the rumen?

  • Lactate-to-nitrate ratios in medium containing fermentable organic matter determine whether nitrate reduction by Sulfurospirillum sp. strain KW yields nitrite or ammonia.

    • When this ratio is high (nitrate limiting), ammonia is the major end product

    • When it is low (fermentable organic matter limiting), nitrite is the major end product

  • The hypothesis In the rumen a sudden load of nitrate creates the conditions for a NR-SOB to favor nitrite production. As the nitrate levels decline these conditions reverse, where ammonia production is favored.

  • The overall control appears to be the suppression of sulphate reduction and lowered hydrogen sulphide concentrations accentuating production of nitrite by inhibiting the NR-SOB further metabolizing nitrite to ammonia coupled to oxidation of sulphide

  • 3HS- + NO2- +5H+ = 3S0 + NH+4 +2H2O --------5


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

The pathways of nitrate metabolism in the rumen are uncertain but have always been assumed to be by dissimilatory nitrate reduction (DNR) to ammonia

Overall reaction

  • NO3-+2H+ ---------H2O+NO2- ----------------1

  • NO2-+6H+ ---------H2O+ NH3 ---------------2

    Organisms capable DNR of nitrate to nitrite and assimilatory nitrite reduction(ANR) to ammonia use formate and hydrogen as the common electron donors

  • 3HCO-2+NO2-+5H+=3 CO2+NH+4+2H2O ------3

  • 3H2+NO2-+2H+ = NH+4 +2H2O -------------4

    The newly discovered NR-SOB organisms use hydrogen sulphide as an electron donor for respiratory nitrite ammonification

  • 3HS + NO2- +5H+ = 3S0 + NH+4 +2H2O ----5


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Fermentable OM uncertain but have always been assumed to be by

NO3-

NRB

CO2 + VFA

NH4+

Competitive Exclusion

of SRB by NRB

SO42-

Fermentable OM

SRB

CO2 + VFA

H2S

H2S

ADP

NO3-

NR-SOB

SO42-

NH3

ATP

Sulphide removal by NR-SOB.When sulphide limiting NR-SOB reduce nitrate to nitrite


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Three processes may lower rumen fluid hydrogen sulphide uncertain but have always been assumed to be by 1)loss to the gas space, 2)competition between NRB and SRB

for electron donors and 3)oxidation to sulphate by NR-SOB

Heterotrophic nitrate reducing bacteria (NRB) out compete SRB

SO42-

NO3-

Fermentable OM

NRB

SRB

NH3

CO2 + VFA

H2S

Nitrate reducing sulphide oxidizing bacteria (NR-SOB) lower H2S

SO42-

NH3

Fermentable OM

NR-SOB

SRB

NO3-

H2S

CO2 + VFA


Nitrate poisoning is a result of the establishment of a single group of microorganisms the nr sob
Nitrate poisoning is a result of the establishment of a single group of microorganisms the NR-SOB ?

  • When fermentable organic matter is high NRB and SRB can co exist maintaining rumen fluid H2S

  • When electron donors are in short supply NRB out compete SRB and H2S in rumen fluid declines

  • When rumen degradable protein is high the population density of NR –SOB depends on nitrate and H2S in rumen fluid

  • When H2S and nitrate adequate NR-SOB convert nitrate to ammonia but convert nitrate to nitrite in the absence of H2S


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Percentage of nitrite and ammonia formed as a function single group of microorganisms the NR-SOB ?of the lactate-to-nitrate ratio in cultures of oil field NR-SOB (Sulfurospirillum spp.) (Hubbert and Voordouw 2007)

% N as ammonia

% N as nitrite


The effects of adding nitrate into an artificial rumen inoculated with rumen fluid
The effects of adding nitrate into an artificial rumen inoculated with rumen fluid

  • Nitrate was cleared rapidly in all incubations but nitrate N could not be accounted for in either ammonia or nitrite, particularly in first 5hr of the incubation.

  • Nitrite accumulated when nil, glucose of cellulose was included suggesting nitrite reduction to ammonia is inhibited.

  • Nitrite accumulation was negligible when dried grass was included in the medium.

Conclusion protein (sulphide) and electron

donors preserve nitrite assimilatory

conversion to ammonia in NR-SOB (source

Barnett and Bowman 1957)


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

The effects of protein intake on the accumulation of nitrite in rumen fluid after administration of a nitrate load (30g Na-nitrate) in sheep (Takahashi et al 1980)

* First measurement of nitrate concentration after nitrate load given

The hypothesis that arises is that at high concentrations of nitrate in the rumen, the fermentable biomass in the rumen

determines the rate of availability of electrons which in turn dictates the proportion of nitrate converted to nitrite or ammonia.

The extent to which this happens is determined by the population density of the NR-SOB which in turn depends on hydrogen

sulphide generation largely from organic sulphur containing compounds and is mainly dependent on the amount of

protein degraded in the rumen. This is consistent with the accumulation of nitrite being higher at higher protein intake( Table


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

The effects on methane production of administration of a nitrate load in fed sheep un-acclimated to nitrate in their diet (Sar et al 2004).


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Changes in rumen fluid nitrate and nitrite with time after administration of Na-nitrate alone or a combination of Na-nitrate and cysteine to sheep (Takahashi et al 1998).


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Effects of iso-S supplements on the concentration of hydrogensulphide in the rumen head-space gas of dairy cows. The cows had been without feed for 4 hours prior to administration of S-source (Dewhurst et al 2007).


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Effects of increasing hydrogenquantities of L-cysteine injected into the rumen on hydrogen sulphide concentration in rumen head space gas in dairy cows (Dewhurst 2007).


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
The relationship between hydrogen sulphide in rumen fluid and in the gas space in the rumen (After Gould et al 1997)


Nitrate poisoning preconditions
Nitrate poisoning preconditions and in the gas space in the rumen (After Gould

  • The population densities of NRB,SRB and NR-SOB in the rumen depend on the degradable protein content of the grazed forage

  • Fertilizer application controls growth rate of pasture soluble sugars, protein and nitrate in forage,

  • Lowering photosynthesis rate of the plant from environmental reasons may increase the accumulation of nitrate up to 10 fold.


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

N-fertilization of perennial rye grass (PRG) increases both crude protein content of forage and there is a linear increase in nitrate content (Lovett 2004)


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
N-fertilization of perennial rye grass (PRG) (Lovett 2004) or Kikuyu grass (Marais 2008) increases crude protein and nitrate

Marais 2008

Dewhurst et al 2004


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

N-fertilization of alfalfa increases both crude protein content of forage and there is a linear increase in nitrate content (Cherney et al 1994)


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979
Nitrate poisoning--The sudden introduction of nitrate into the rumen causes a series of flow on effects as follows

  • nNRB are provided with additional substrate and inhibit SRB activity for both sulphur and nitrite reduction by competition for organic electron donors

  • Reduced activity of SRB reduces concentrations of hydrogen sulphide in rumen liquor and the rumen gas head space

  • As hydrogen sulphide levels in rumen fluid decrease the growth capacity of NR-SOB is lowered (nitrite ammonification is normally synchronised with hydrogen sulphide oxidation), uncoupling growth and substrate metabolism and directing electrons to nitrite formation from nitrate at an enhanced rate

  • SRB are competitively hampered in using nitrite by the availability of electron donors which are usurped by NRB. This is only reversed when nitrate levels fall below a critical concentration.

  • Nitrite accumulates in rumen fluid and is absorbed and binds to haemoglobin.

  • As nitrate levels are lowered in rumen fluid and, dependent on the availability of electron donors (fermentation potential), the effects of electron starvation on SRB cease at a critical level and nitrite uptake by SRB and NR-SOB returns to normal.


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Effects of a meal(9.5 kg the rumen causes a series of flow on effects as followswet weight) of white clover or perennial rye grass on the concentration of hydrogen sulphide in the rumen head-space of dairy cows (Dewhurst et al 2007).

Clover had almost double the protein and therefore cysteine

content compared to rye grass


The potential to feed nitrates to reduce enteric methane production in ruminants 1284979

Effect of high sulfur and various compounds on in vitro ruminal hydrogen sulfide production. Low sulfur = 0.29% S; High sulfur = 1.09% S. AQ = 10 ppm (fluid basis) of 9,10 anthraquinone; Molybdate = 25 ppm of molybdate; Monensin = 5 ppm. (Data from Bracht and Kung, 1997.)

Does monensin inhibit NR-SOB and if it does what are the effects on nitrite

production in the rumen during a nitrate load.


Major conclusions 1
Major conclusions 1 ruminal hydrogen sulfide production. Low sulfur = 0.29% S; High sulfur = 1.09% S. AQ = 10 ppm (fluid basis) of 9,10 anthraquinone; Molybdate = 25 ppm of molybdate; Monensin = 5 ppm. (Data from Bracht and Kung, 1997.)

  • Urea can be replaced by nitrate as a source of fermentable nitrogen in diets where the nitrogen source is mixed in the feed with the expectations of reduced enteric methane production.

    • Diets include grain based feedlot diets

    • Hand feeding in drought with grain, hay and straw/other crop residues

    • Feedlot based feeding of alkali treated crop residues (35 million tonnes of straw)

    • Sugar cane based diets

    • Molasses, cassava, sugar beet based diets


Major conclusions 2
Major conclusions 2 ruminal hydrogen sulfide production. Low sulfur = 0.29% S; High sulfur = 1.09% S. AQ = 10 ppm (fluid basis) of 9,10 anthraquinone; Molybdate = 25 ppm of molybdate; Monensin = 5 ppm. (Data from Bracht and Kung, 1997.)

  • Nitrate as a supplement has wide scale application in developing countries where ruminant production is largely based on using crop residues

  • Urea maybe replaced by nitrate in dry season supplements fed through out Australia (requires research to develop delivery systems)

  • For each 1% inclusion of K-nitrate in a diet methane production will be reduced by 10%

  • As an example in grain based feed lot rations 1% urea is usually required to optimise rumen efficiency. This would be replaced with 3.3% K-nitrate reducing methane production by 33%?


Major conclusions 3
Major conclusions 3 ruminal hydrogen sulfide production. Low sulfur = 0.29% S; High sulfur = 1.09% S. AQ = 10 ppm (fluid basis) of 9,10 anthraquinone; Molybdate = 25 ppm of molybdate; Monensin = 5 ppm. (Data from Bracht and Kung, 1997.)

  • Using nitrate to decrease enteric methane production when consumed by grazing ruminants on high protein diets has major barriers

    • Accessing animals

    • Incidence of nitrate poisoning

    • Increased NOx from excreta (surplus N in diet).

  • A paradigm shift in research and pasture/animal management would be needed to:

    • Produce lower protein highly digestible forages( similar to sugar cane)

    • Produce pasture/forage with a higher percentage of the protein as bypass protein (tanniniferous legumes- e g sulla)

    • Develop energy efficient feed processing of forages to optimize digestibility of crop residues and mature forages (this already underway )

    • Develop strategies for providing nitrate under grazing.


Nitrite is not normally an intermediate released into the medium rumen fluid by nrb 1
Nitrite is not normally an intermediate released into the medium( rumen fluid) by NRB -1

  • Rumen NRB convert nitrate to ammonia without production of nitrite and mainly by assimilatory pathways.

  • A small specialized population of NR-SOB are universally present in the rumen and population density is controlled by the extent and pattern of availability of nitrate and sulphide.

  • NR-SOB are versatile organisms with a wide spectrum of sources of nutrients but when nitrate is available and hydrogen sulphide concentration is adequate they reduce nitrate to ammonia without the intracellular intermediate, nitrite, being released to the medium.


Nitrite is not normally an intermediate released into the medium rumen fluid by nrb 2
Nitrite is not normally an intermediate released into the medium( rumen fluid) by NRB -2

  • The rapid reduction of nitrate by both NRB and NR-SOB effectively compete with SRB for the electrons generated in fermentation, lowering sulphur reduction to sulphide.

  • Decreased sulphur reduction and increased sulphide oxidation lower sulphide concentrations in the rumen which then inhibits ammonification of nitrite in NR-SOB and nitrite accumulates in the medium.

    This then suggests that nitrite is not normally produced by one group oforganisms to be used by a second group in the rumen.

    This then suggests that in the rumen nitrite is only produced in small quantities and only by NR-SOB when sulphide availability is curtailed.

    NR-SOB population densities are controlled by sulphide concentrations (and indirectly RDP)


Is it worthwhile investing in major research programs 1
Is it worthwhile investing in major research programs 1? medium( rumen fluid) by NRB -2

  • I believe that the answer is a whole hearted YES for the following reasons

    • Considerable research to attain this goal to date by other processes has been unrewarding.

    • Application of nitrate to replace urea in low protein pasture/ forage and high energy feeds (grain based or sugar/starch based) has been proven albeit in only a limited number of studies.

    • The majority of the world populations of domestic ruminants are maintained on crop residues for all or a substantial part of their lives and are hand fed and because they produce at rates 10-20% of their genetic capacity contribute disproportionately to total enteric methane production particularly when methane is calculated on the basis of liters per unit of production.


Is it worthwhile investing in major research programs 2
Is it worthwhile investing in major research programs 2? medium( rumen fluid) by NRB -2

  • I believe that the answer is a whole hearted YES for the following reasons

    • The depletion of critical resources and the high energy costs associated with future agriculture suggests that ruminant animals will become increasingly the preferred meat, milk, fiber and maybe energy providers in the future increasing world numbers substantially

    • Already industries are gearing up to apply high technology to improve the utilization of crop residues which appears to have been highly successful as in some cases straw fed ruminants with good supplement management are achieving levels of production approaching the animals genetic potential.

    • Successful utilization of nitrate, with high levels of production on low protein crop residues such as treated straw would provide the stimulus for paradigm shifts in pasture management and forage breeding that would optimize biomass production but with lower protein content in the biomass.


The optimistic view point the end
The Optimistic View Point medium( rumen fluid) by NRB -2The END

  • The ruminant population of the world is estimated to produce 80 million MT enteric methane

  • Most of this is produced by animals on low quality forages

  • There appears to be no problems feeding nitrate to animals so long as the following principles are applied

    • N in the feed is kept within stoichiometric requirements for efficient fermentative digestion

    • Animals are adjusted to nitrate slowly.

    • Previous diet and the production diet are low in readily fermentable( or rumen degradable) protein.

  • Potentially 50% enteric methane production could be prevented by wide scale application of nitrate and a change in production management to low protein diets
