  1. Thursday meeting Nawin Juntong 16-10-2008

  2. TTF-Style Coupler Non identical cells 9 cells run 4.5 cells run

  3. ELRP-Style Coupler • Validate G.Burt modified method with G.Hoffstaetter method. • The results are same. 9 cells run

  4. NEXT • Learning to submit job to grid and try to submit ABCI jobs. • Simulation on ILC cavity with Fundamental mode and HOM couplers. • Understanding others method of rf kick calculation.

  5. BACK UP Slides

  6. PEC bc. PMC bc. How to calculate kick factor (Dr. G.Burt method) 1.Combine 2 SW fields to get TW fields 2.Integrate Lorentz force to get the change of momentum 3.Transverse kick factor is a ratio of the change of transverse momentum to the change of longitudinal momentum

  7. ˆ A is the fields from MWS How to calculate kick factor (B. Buckley and G.H. Hoffstaetter method) PRST-AB 10,111002(2007),Cornell-ERL-06-02 1.Combine 2 SW fields to get TW fields 2.Integrate Lorentz force to get the change of momentum 3.Transverse kick factor is a ratio of the change of transverse momentum to the change of longitudinal momentum
