  1. Analisa Network

  2. Ada 2 Metode Yang umudigunakan • CPM (Critical Path Method) • PERT (Program Evaluation and Review Technique)

  3. Diagram Jaringan Kerja • PerancanganProyek • Gambarkegiatanproyek • Simbol – simbol yang digunakan : 1. AnakPanah Menyatakankegiatan Gambar : 2. AnakPanahTerputus – putus Menyatakankegiatansemuatau Dummy Gambar :

  4. 3. Anak Panah dengan garis sejajar atau tebal Gambar : 4. Peristiwa Menyatakan Peristiwa atau suatu kejadian Gambar : MenyatakanJalurkritis, jalurkritisjalur terpanjangdarijaringankerja

  5. Metode CPM (Critical Path Method) • Earliest Start Time (ES) : waktutercepatuntukbisamemulaisuatukegiatandenganwaktu normal, tanpamengganggukegiatan lain • Latest Start Time (LS) : waktu paling lambatuntukbisamemulaikegiatandenganwaktu normal, tanpamenggangukegiatan-kegiatanlainnya • Earliest Finish Time (EF) : waktu paling cepatuntukmenyelesaikansuatupekerjaandalamwaktu normal, tanpamengganggukegiatan lain • Latest Finish Time (LF) : waktu paling lambatuntukmenyelesaikansuatukegiatandalamwaktu normal, tanpamengganggukegiatan lain

  6. Contoh Soal

  7. Network C F 3 4 5 6 5 A H 2 8 D 7 1 4 B 8 12 6 7 2 E G

  8. Menghitung ESi

  9. Menghitung LSi

  10. Memeriksa kegiatan Kritis • Kegiatan A ES1 = LS1  0 = 0 ES3 = LS3  4 ≠ 7 ES1 + t13= ES3  0 + 2 = 4  2 ≠ 4 • Kegiatan B ES1 = LS1  0 = 0 ES2 = LS2  4 = 4 ES1 + t12 = ES2  0 + 4 = 4  4= 4 • Kegiatan D ES2 = LS2  4 = 4 ES4 = LS4  12 = 12 ES2 + t24 = ES4  4 + 8 = 12  12= 12

  11. Kegiatan E ES2 = LS2  4 = 4 ES6 = LS6  18 = 18 ES2 + t26 = ES6  4 + 12 = 18  16 ≠ 18 • Kegiatan F ES4 = LS4  12 = 12 ES5 = LS5  18 = 18 ES4 + t45 = ES5  12 + 6 = 18  18 = 18 • Kegiatan H ES5 = LS5  18 = 18 ES7 = LS7  26 = 26 ES5 + t57 = ES7  18 + 7 = 26  25 ≠ 26 • Kegiatan G ES6 = LS6  18 = 18 ES7 = LS7  26 = 26 ES6 + t67 = ES7  18 + 8 = 26  26 = 26

  12. Kegiatan Kritis : B, D, F, Dummy 2, G • Jalur Kritisnya : 1 – 2 – 4 – 5 – 6 – 7 • Waktu Kritisnya : 4 + 8 + 6 + 0 + 8 = 26 • Waktu penyelesaian persoalan diatas minimal 26 minggu C F 4 12 18 3 4 5 12 18 7 6 5 A H 2 8 0 D 7 Dummy 2 Dummy 1 1 0 4 B 8 4 12 26 18 6 7 2 E G 18 26 4
