  1. Primary Considerations Ch. 3- Architecture R.D.& D. 7 Set of Floor Plans Architectural Design

  2. Plot Plan ( Site Plan) • Foundation Plan • Floor Plan • Elevations • Electrical Plan • Construction Details • Pictorial Presentation Set of Plans

  3. Plot Plan

  4. Shows the location of the house on the site. • Shows utilities, topographical features, site dimensions, and any other buildings on the property. Plot Plan- Site Plan

  5. Foundation Plan

  6. Foundation Plan

  7. Illustrates foundation size and materials. • Provides the information pertaining to excavation, waterproofing, and supporting structures. • May also include basement plan if the house has a basement. Foundation Plan

  8. Floor Plan

  9. Shows all exterior and interior walls, doors, windows, patios, walk, decks, fireplaces, mechanical equipment, build-in cabinets, and appliances. • A separate plan view is drawn for each floor of the house. ( ex. First floor , second floor, basement…) Floor Plan

  10. Elevations

  11. Flat Roof: 2/12 Low Slope: 2/12-4/12 Conventional Slope Roof: 4/12-9/12 Steep Slope: 9/12 and higher Roof Slope

  12. Roof Pitch http://www.pole-barn.info/roof-pitch.html

  13. Slope (pitch)= Rise : Run • Example: 5:12 • Pitch = Rise • ___________ Span = 5/24 Pitch= Rise/ Clear Span

  14. Command: Line-@20’<45 Roof Pitch http://www.pole-barn.info/roof-pitch.html

  15. Building Calculator.. Cool!!

  16. Elevations

  17. The elevations represent orthographic projections of the exterior features of the building/ house. • They show placement of windows, doors, exterior materials, steps, chimney, rooflines, and other exterior details. Elevations

  18. Electrical

  19. Shows switches, convenience outlets, ceiling outlet fixtures, televisions jacks, service entrance location, and the panel box. • Also provides general information concerning circuits and special installations. • Note: may be found in AutoCAD Insert- Center Designer. Electrical Plan

  20. Electrical Symbols

  21. Construction Details

  22. Drawn where more information is needed to fully describe how the construction is to be done. • Includes detail of kitchens, stairs, chimneys, fireplaces, windows, and doors, and foundation walls. Construction details

  23. Specifications describe the quality of work and materials. • Provide additional details that are not shown on the drawings. • Drawings and specifications form the basis of a legal contract between the owner and the builder. Specification- Detail work

  24. Pictorial Presentation

  25. This is often included to show how the finished structure will appear. • It’s usually drawn/ drafted in a two-point perspective. Pictorial Presentation

  26. Roof Plan • Framing Plan • Floor Framing Plan • Heating and cooling plan • Plumbing plan • Landscaping Plan • Furniture Plan • Expansion Plan Other Plans- pg. 64

  27. These other plans may be included in a set of residential construction drawings. • Specifications describe the quality of work and materials Other Plans

  28. http://homeinterior-tips.com/home-design/home-plan/how-to-make-a-madden-home-for-your-own-home-design.html/attachment/plot-plan-in-trick-to-make-a-madden-home-for-your-own-home-designhttp://homeinterior-tips.com/home-design/home-plan/how-to-make-a-madden-home-for-your-own-home-design.html/attachment/plot-plan-in-trick-to-make-a-madden-home-for-your-own-home-design • http://www.buyerschoiceinspections.com/roof-slope • http://www.hiltongooge.com/details_to_expect.html Sources:

  29. Lets focus on the Roof Design & Elevations. Assignment for a Major Grade.
