Presentation Transcript
slide2

Some important classes of alkaloids

Class PrecursorsExamples_____________

Piperidine alkaloids L-lysine (C5N) Piperine

Pyrrolidine/tropane

alkaloids L-ornithine(C4N) Cocaine, scopolamine

Pyridine alkaloids L-Trp or L-Asp Niacin (Vit. B3), nicotine

Catecholamines L-Tyr (C6C2N) Dopamine, adrenaline, mescaline

and tetrahydroisoquinolinesanhalamine

Opiates 2 L-Tyr units Morphine, tubocurarine

Phenylalanine-derived L-Phe(C6C3N) Capsaicin, ephedrine

Indole alkaloids L-TrpSerotonin, ergotamine, LSD, vinblastine

Quinoline alkaloids “ quinine, camptothecin

Purine alkaloids L-Gly, L-Gln, L-Asp Caffeine, theobromine

Building blocks from the acetate, shikimate, or deoxyxylulose phosphate pathways are also frequently incorporated into the alkaloid structures.

Many alkaloids acquire their N via transamination reactions (catalyzed by Vitamin B6).

Most alkaloids are quite toxic and produced by the plant as a defense against herbivores.

key biological activity of alkaloids interaction with cns
Key biological activity of alkaloids: interaction with CNS
  • Most of the biological effects of alkaloids are due to their similarity
  • to neurotransmitters in the human body.
  • They can either mimic or block the effects of neurotransmitters, or
  • cause fluctuations in the normal levels of neurotransmitters.
  • This leads to numerous physiological and psychological effects
  • Role of neurotransmitters: to transmit nerve impulses across the
  • synapse (space) between neurons in brain, nervous system
  • Structures: mostly small molecules containing amino or ammonium functionalities
  • Action: They are released from nerve endings and bind to receptors on the surface of another neuron in the network
  • Agonists bind to and stimulate receptors
  • Antagonists block receptors
  • Not all alkaloids affect CNS, but many do!
slide4

Neurotransmitters that have effects on mood,

thought processes

(a catecholamine)

(an indole, aka 5-hydroxytryptamine or 5-HT)

Parkinson’s disease – dopamine transmission is inadequate, can be improved by L-DOPA

Depression – treatment with SSRIs increases dopamine in the synaptic cleft

slide5

Neurotransmitters that control physiological effects

throughout the body

a catecholamine

a catecholamine

a quarternary ammonium salt

Norepinephrine malfunction is implicated in anxiety and mood disorders, bipolar disorder

Acetylcholine: low levels may cause memory lapses associated with Alzheimers’, can be improved with cholinesterase inhibitors

alkaloids derived from lysine piperidine alkaloids c 5 n
Alkaloids derived from lysine(piperidine alkaloids – C5N)

Formation of the 6-membered ring

(also see Lobelia)

formation of piperine c 6 c 3 unit is lengthened and linked with 2 o amine to form amide linkage
Formation of piperine: C6C3 unit is lengthened and linked with 2o amine to form amide linkage

Piperine: from black pepper (Piper nigrum)

Spicy flavor and CYP3A4 inhibitor

The pungency of piperine is caused by activation of the heat and acidity sensing TRPV ion channel found on nociceptors (pain sensing nerve cells)[

Has insecticidal properties

Produced from three different building blocks

tropane alkaloids solanaceae family
Tropane alkaloids (Solanaceae family)

Formation of first ring

(pyrrolidine ring)

  • Tropanes are bicyclic non-aromatic alkaloids. They are not common in edible plants, but are found in some botanicals and medicinal herbs.
  • The most common natural tropane alkaloids are (-)-hyoscyamine and (-)-scopolamine (also known as hyoscine). High concentrations of these alkaloids have been found particularly in Daturaspecies.
  • Hyoscyamine is the major alkaloid in most parts of Daturastramonium (thorn apple or Jimson weed); scopolamine is the major alkaloid in other Datura spp.
slide9

Assembly of the

tropane skeleton found

in cocaine, hyoscyamine

chain building by acetyl co a units leads to second ring in bicyclic tropanes
Chain building by acetyl Co-A units leads to second ring in bicyclictropanes

From leaves of Erythoxylum coca. Well-known CNS

stimulant, also anaesthetic

Extracts of coca leaves

used in original Coca-cola

recipe (cola provided the caffeine) but in 1906 the Coca was eliminated.

Structural similarity to acetylcholine allows tropanes to block muscarinicACh receptors, providing anaesthetic effect.

Found in belladonna

(Atropa belladonna),

henbane and Datura species

Can be used as sedative

or external pain relief, but

they are toxic and have psychotropic effects

(hallucinations, etc.)

effects of tropane alkaloid contamination in animal feed
Effects of tropane alkaloid contamination in animal feed

From European Food Safety Authority website

http://www.efsa.europa.eu/EFSA/efsa_locale-1178620753812_1211902036472.htm

  • “Tropane alkaloids” are a group of > 200 compounds best known for their occurrence in the family Solanaceae, comprising over 100 genera including Datura.
  • Datura plants are toxic for animals if ingested in large amounts. Their seeds contain significant amounts of hyoscyamine and scopolamine, and can be found as botanical impurities in feed materials, particularly in soybean and linseed products.
  • Reports on adverse health effects in animals refer mostly to accidental intoxications following the consumption of Daturaplants rather than to the contamination of feed.
  • Overall, pigs have been shown to be among the most sensitive species to Datura poisoning.
effects of tropane alkaloid contamination in animal feed cont d
Effects of tropane alkaloid contamination in animal feed(cont’d)

From European Food Safety Authority website

http://www.efsa.europa.eu/EFSA/efsa_locale-1178620753812_1211902036472.htm

  • As competitive antagonists for muscarinic acetylcholine receptors, tropanes prevent binding of acetylcholine, thus affecting the function of smooth muscles and exocrine gland cells, heart rate, respiration and functions in the CNS.
  • Most common symptoms reported: dryness of the mucosa in the upper GI and respiratory tract, constipation and colic (in horses), pupil dilation, alterations in heart rate, and CNS effects such as restlessness, irritability, ataxia, seizures and respiratory depression.
  • Tropane alkaloids are readily absorbed following oral ingestion, but have a short biological half-life and are rapidly biotransformed or excreted.
  • Exposed animals are likely to exhibit symptoms and be removed from the food supply, therefore, it is unlikely that residues of tropane alkaloids in edible tissues, milk and eggs constitute a risk for consumers.
background and occurrence

Atropa belladonna is known as Deadly nightshade

Related to the tomato (also a member of Solanaceae)

Native to: Europe, North Africa, Naturalized in North America

Morphology: Branching herbaceous perennial, berry bearing, ~1.5m tall

It’s highly toxic! All parts of the plan contain tropanealkaloids atropine and hyoscyamine. Berries are sweet, but toxic

Historical use: Ladies “at court” in Europe applied to the eyes to dilate pupils, “enhance beauty”

Anticholinergic agent: Causes ataxia (loss of coordination)‏

Also causes pupil dilation, double vision, increased body temperature, confusion. Competes with ACh, reversibly inhibits neuron activity

Background and Occurrence
medicinal uses of atropine

Antitoxin for cholinesterase Inhibitors

ie: physostigmine, neostigmine

Organophosphate insecticides

Cosmetic application to eyes

Gastrointestinal sedative (for antacids)‏

External pain relief (root preparation)‏

Medicinal Uses of Atropine
henbane jimson weed also contain tropanes
Henbane & Jimson weed also contain tropanes

Henbane

Henbane (Hyosycamusniger) contains primarily hyoscyamine, a stereoisomer of atropine, and scopolamine (-)-hyoscine.

Henbane was thought to induce hallucinations & visions of flight, associated with witches. Could be used to treat GI spasms if it wasn’t so toxic.

Jimson weed (Datura) grows wild throughout Europe, Americas.

Thieves used it in the Middle Ages to drug & rob people.

Some South American tribes used it to calm down unruly kids due to mild sedative effect at low doses.

cocaine
Cocaine
  • From Erythroxylum coca
  • Historically, field workers would consume while picking the leaves
  • Leaves were extracted with gasoline, then acidified with aqueous acid to purify out the cocaine HCl salt
  • Salt converted back to “free base” by using CaCO3
  • Ether solution of free base evaporated down -> crack
slide18

Cocaine has several physiological & psychological effects:

  • Stimulant: increases norepinephrine release
  • Anesthetic: binds to acetylcholine receptors, decreases Na+ transport
  • Mood-enhancing/addictive: increases dopamine levels by blocking reuptake

Synthetic analogues of cocaine used as local anaesthetics have muscarine structural motif:

procaine/novocain

Local anaesthetic used to numb skin, rapidly absorbed.

Also used as anti-arrhythmia agent after a heart attack

Alters signal transduction in nerve membranes by blocking fast voltage-gated sodium channels, stopping pain signals

Used mainly as a

topical anaesthetic

Found in anbesol,

cepacol, solarcaine

Both are sodium channel

blockers, used mainly in

dentistry

cocaine and addiction
Cocaine and addiction
  • Addiction from cocaine and similar drugs arises from its effects on dopamine transmission.
  • Normally, dopamine is released from the transmitting neuron, crosses the synapse and binds to receptors on the receiver.
  • Excess dopamine is transported back to the transmitting neuron.
  • Cocaine blocks the dopamine transporters, inhibiting the re-uptake of dopamine by the transmitter.
  • This results in increased dopamine levels in the synapse  euphoria
  • Reward system results in addiction
  • Users get used to higher levels of dopamine and “crash” when stimulus is removed.
it s the real thing
It’s the real thing...
  • Cola (kola) is the dried cotyledon from seeds of Cola spp. (Sterculiaceae), e.g. C. nitida & C. acuminata, trees cultivated mainly in West Africa and the West Indies.
  • Fresh cola seeds are chewed in tropical countries as a stimulant
  • Cola seeds (nuts) contain up to 3% caffeine & 0.1% theobromine, partly bound to tannins. On drying, some polyphenol oxidation occurs, forming a red pigment, and free caffeine is liberated.
  • Vast quantities of dried seeds are processed for the preparation of cola drinks, e.g. Coca-Cola and Pepsi-Cola.
  • Coca-Cola was invented by Atlanta pharmacist John Pemberton in 1886. It originally contained cocaine (from E.coca leaf) and caffeine from the kola nut (5 oz. coca leaf/gallon of syrup). It once contained ~ 9 mg cocaine per glass, but in 1903 it was removed.
  • After 1904, Coca-Cola started using "spent" leaves left over from the cocaine-extraction process. A cocaine-free coca leaf extract is still used for flavoring.
capsaicin
Capsaicin
  • Produced by red hot chili peppers (Capsicum annuum) of Solanaceae
  • Secondary metabolite, probably produced as a deterrent against herbivores & fungi
  • Has analgesic properties
  • Used medicinally in creams to treat neuralgia or neuropathy caused by diabetes, herpes
  • Also in topical pain-relieving preparations for arthritis.
  • The initial burning effect of capsaicin affects the pain receptors, depleting substance P, and making them less sensitive
nicotinic acid niacin vit b 3
Nicotinic acid/Niacin (Vit. B3)
  • Role: redox cofactor when in form of NAD(P)+/NAD(P)H
  • In animals, produced by degradation of L-Trp
  • In most plants, L-Asp is the precursor
  • Nuc. attack on phosphoglyceraldehyde followed by imine formation
  • Reaction with N-methyl pyrrolinium leads to nicotine
  • Nicotinic acid is also produced during the roasting of coffee from the decomposition of N-methyl derivativetrigonelline
structural similarity with acetylcholine leads to stimulant properties
Structural similarity with acetylcholine leads to stimulant properties

Tobacco - the cured and dried leaves of Nicotianatabacum(Solanaceae)

an annual herb indigenous to tropical America, cultivated widely for smoking

Tobacco leaves may contain from 0.6–9% of (−)-nicotine (an oily, volatile liquid) together with smaller amounts of structurally related alkaloids. Nicotine in small doses can act as a respiratory stimulant, but in larger doses it causes respiratory depression.

Arecoline is the major alkaloid in Areca nuts (betel nuts) - the seeds of Areca catechu (Palmae/Arecaceae), a tall palm cultivated in India & other parts of Asia. Nuts are mixed with lime, wrapped in leaves of the betel pepper and then chewed for their stimulant effect, and subsequent feeling of well-being and mild intoxication.

slide25

Addition of a C6C2 unit on each side of amine group leads to lobeline

Lobelia inflataor “Indian tobacco” contains lobeline, which has a similar but weaker stimulant effect than nicotine

Used in smoking deterrent preparations

alkaloids derived from tyrosine part 1 catecholamines
Alkaloids derived from tyrosine, Part 1: Catecholamines

Peyote:

The dried sliced tops of Lophophorawilliamsii, found in Mexico & Southwestern US is used to prepare peyote, used by native Americans in religious ceremonies to induce hallucinations. The major psychoactive alkaloid in peyote is mescaline, named after the Mescaleros Apaches. Mechanism of action may involve blocking reuptake of norepinephrine at receptors, increased serotonin release.

cacti have been around since prehistoric times
Cacti have been around since prehistoric times...
  • Journal of Ethnopharmacology study documented prehistoric peyote use!
  • El Seedi, et al, 2005
  • More info in a separate slideshow.
analyzing ancient alkaloids
Analyzing ancient alkaloids…
  • Two peyote buttons (Lophophora) found in a TX cave in 1933 were obtained from Witte museum for the study
  • Insides were scraped to give a powder that was either extracted with EtOH, basified and further extracted with CHCl3 OR boiled with 10% HCl, extracted with ether.
  • Dried extracts of 2-14 mg were obtained
  • Dragendorff test showed alkaloids were present (about 2% by mass)
  • TLC and GC-MS analysis confirmed mescaline present (isoquinoline alkaloids not found)
  • Radiocarbon dating analysis showed the samples to be from 3780-3660 BCE.
  • Oldest artifact proven to contain a psychoactive substance!

(El-Seedi, et al, J. Ethnopharmacology (2005)101: 238-242.)

those wacky cacti family cactaceae genus species lophophora williamsii carnegiea gigantea
Those wacky cacti! Family: CactaceaeGenus/species: LophophorawilliamsiiCarnegieagigantea

Many cactus alkaloids have a heterocyclic

6-membered ring (isoquinoline structure):

adrenergic receptors
Adrenergic receptors
  • a-adrenergic receptors:
    • a1 – blood vessels, causes vasoconstriction
    • a2 – nerves, mediates synaptic transmission
  • b-adrenergic receptors:
    • b1 – heart, cerebral cortex, agonists increase heart muscle contraction
    • b2 – lungs, cerebellum, agonists dilate bronchi
    • b3 – adipose tissue, agonists increase lipolysis
  • General: increases cyclic AMP, activating protein kinases
beta blockers synthetic antagonists of b adrenergic receptors and some agonists

Block b-adrenoreceptors that regulate cardiac muscle contractions (b1) and smooth muscle relaxation in the lungs (b2)

“Beta blockers”: synthetic antagonists of b-adrenergic receptorsand some agonists

Inhibits

DOPA

decarboxylase

cardiac stimulant

b1 agonist

a1 antagonist

vasodilator

lowers bp

a1 agonist

vasoconstrictor, used in Afrin

nasal spray (natural)

b1 antagonist controls force of heart contractions, lowers bp

b2 agonist relaxes

bronchial smooth

muscle (asthma)

slide33

Used since 1500’s

--CNS Stimulant

--Epinephrine Agonist

--Bronchodilator

--Decongestant

--Diet Aid

BANNED!

slide34

Catecholamine mimics from L-Phe

The major stimulant in Ephedra is ephedrine, a sympathomimetic amine (similar effects to noradrenaline)

Unlike actual catecholamines, ephedrine only acts weakly on receptors, but it can displace noradrenaline from nerve storage vesicles which then stimulates receptors.

Ephedrine is orally active and lasts longer than noradrenaline.

“Khat” Catha edulis (Celastraceae): In African and Arabian countries, the leaves of this tree are chewed as a stimulant to alleviate hunger and fatigue, while also giving a sensation of general well-being. Users become cheerful and talkative, so khat has become a social drug and use may lead to psychological dependence.

Young, fresh leaves are most effective. The principal CNS stimulant is contain (−)cathinone ,with similar pharmacological properties as the synthetic CNS stimulant (+)-amphetamine.

Both compounds act by inducing release of catecholamines.

slide35

Amphetamines usually cause dependence in users.

Other amphetamine-like derivatives include MMDA

(methoxymethylenedioxyamphetamine) and MDMA (methylene-dioxymethamphetamine)

MMDA may be formed in the body after ingestion of nutmeg (Myristicafragrans) by an amination process on myristicin, which may account for reported euphoric and hallucinogenic effects of consuming nutmeg.
