Presentation Transcript
slide1

EA102

SPECIFIC GRAVITY & ABSORPTION CAPACITY OF AGGREGATES

density

EA102

i.e.,

Density

For example, how many kilograms in 1 cubic metre of the material?

1 m3

The density, ρ of any material is the mass per unit of volume:

or, how many grams in 1 cubic centimetre of the material?

1 cm3

slide3

EA102

At 4˚ C, water has a density, ρw of exactly 1000 kilograms per cubic metre

1 m3

At 4˚ C, water has a density, ρw of exactly 1 gram per cubic centimetre

1 cm3

At 20˚ C (standard), water has a density, ρw of 0.99823 gram per cubic centimetre

slide4

EA102

The difference between the mass in air and water is the mass of the water displaced by the material when placed in the water:

To find the density of any material, a sample of the material is weighed in air, Mair and then in water, Mwater.

since the volume of the material weighed is the same as the volume of water it displaces

EA102

,

Since,

Since the volume of the material weighed is the same as the volume of water it displaces…

specific gravity

EA102

Specific Gravity

The specific gravity, G of a material is just its density relative to the density of water:

moisture states in aggregates

EA102

Moisture States in Aggregates

Saturated Surface Dried, SSD

Air Dried

Free Moisture

Oven Dried

There are 4 distinct moisture states for aggregates:

(Water between particles)

(Hygroscopic Moisture)

(No Moisture)

Voids Filled with Water

Water Permeable Voids

Moisture from Air

Particle coated with water

Aggregate Particle

moisture content

EA102

Moisture Content

The moisture content of a soil or aggregate is the mass of water per unit mass of dry material.

Moisture content is often expressed as a percentage, i.e., the mass of water in grams per 100 grams of dry material.

slide9

EA102

Absorption Capacity

We need to know the %ABS of the sand and stone used to make concrete because if they are drier than SSD then they will absorb some of the mixing water.

The absorption capacity, %ABS is the moisture content of the material when it is in the saturated surface dried state.

On the other hand, if there is free moisture in the aggregate then there will be too much water in the mix.

slide10

EA102

Example

First find the moisture content:

The %ABS of stock sand is 1.5% and we need 8 kg of sand in the SSD condition to make concrete. A 499.6 gram sample of the stock sand was dried over a bunsen burner to a constant mass of 486.4 grams. How much of the sand should be used?

This means that if we weighed out 8 kg of the sand, we’d get less than 8 kg of sand at SSD and extra (free) water.

We therefore must weigh out extra sand in order to get 8 kg at SSD.

how much

EA102

APPROXIMATELY, an extra 2.71-1.5 = 1.21% of the required SSD mass.

(

)

The mathematically correct version of this % correction is:

This translates to 0.0121 x 8.000 = an extra 0.0968 or 0.097 kg of sand.

How much?

This means an extra 0.097 kg of water will be brought into the mix, so the mixing water should be reduced by 0.097 kg to compensate.

bulk specific gravity

EA102

BULK SPECIFIC GRAVITY

Bulk SSD Densityis calculated by dividing the mass of the material at SSD by the bulk volume of the material.

In order to calculate volumes of the concrete mix components, we need to know the Bulk SSD Specific Gravities of the sand and stone, the specific gravity of Portland Cement and the density of water.

For sand (Lab 2 part A), a pycnometer is used to find the bulk volume of a 500.0 gram sample of sand at SSD.

a pycnometer is a glass vessel used to determine the volume of small grained loose material

EA102

Fill to calibration mark with water and weigh: B

neck

Place entire 500.0 g sample into pyc., cover with water, vacuum, fill to calibration mark and weigh: C

calibration mark

A pycnometer is a glass vessel used to determine the volume of small-grained loose material.

Empty contents of pyc., into oven container of known mass; after 18 h at 110°C find mass of container and sample and then dried sample: A

bulb

scale

any material placed in the oven must be properly identified hence the oven tag

EA102

Oven Tags

1NV12

4

2006-01-26

156.2

624.3

Any material placed in the oven MUST be properly identified…hence the oven tag:

For these to work, you must fill them out accurately and completely.

When you have finished, file them in the box with your class code in the drawer at WS 8 (208). Use the paper clip to keep all 3 of your tags together.

there are 3 different specific gravities calculated for the sand and stone

EA102

Specific Gravities

  • ASTM Bulk Specific Gravity:
  • SSD Bulk Specific Gravity:

There are 3 different specific gravities calculated for the sand and stone:

  • Apparent Specific Gravity:
