  1. BalloonSat Mini Flight Computer Programming

  2. label: • An address, or location for the program to jump to • Must end in a colon • Can be any name, but not a command • No spaces allowed, use an underline in place of a space • Can’t begin with a number

  3. PAUSE time • Halts program execution for a number of milliseconds (1/1,000 of a second) • Used to prevent the program from finishing in a fraction of a second

  4. HIGH C.2 and LOW C.2 • Used to trigger the camera • HIGH activates the relay which is the camera’s new shutter switch • Keep HIGH for about 1 second (PAUSE 1000) • LOW turns off the relay (camera needs you to release the shutter)

  5. IF PINC.3 = nlabel • Monitors the Commit Pin • Conditional jump, only occurs if condition is true • Prevents flight computer from recording data until ready for launch • n can be either a 0 or a 1 • IF PINC.3 = 0 then Commit Pin is in place • IF PINC.3 = 1 then Commit Pin is removed

  6. READADC i/o,Bx • Converts analog sensor voltage to a digital value • Linear conversion: 0V = 0 and 5V = 255 • Specifies the I/O pin (either C.1 or C.4) to digitize • Specifies the RAM memory to store the result (B0 to B27)

  7. Write Bn, x • Writes a variable from temporary RAM into permanent Data Memory • RAM variable can be B0 to B27 • Data Memory address runs from 0 to 255

  8. READ x,Bn • Reads data from permanent Data Memory into temporary RAM • Required to send the data via SERTXD • Data Memory address runs from 0 to 255 • RAM variable can be B0 to B27

  9. SERTXD “text”, Bn • Writes variable from RAM to the PC • Writes text (must enclose text in quotes) • Use the PICAXE Terminal program (F8) • Set Terminal for 4800 baud

  10. GOTO label • Jumps program execution to the label • Unconditional jump, happens as soon as command is executed

  11. FOR Bn = x TO y • Loop control, makes program repeat itself • Saves program memory, a short program can be repeated many times without writing the program many times (maximum of 255 times) • Bn is the RAM variable that monitors how many times the loop of code has been repeated • x is the starting number • y is the finishing number

  12. NEXT • Placed at the end of the lines of code repeated by the FOR command • Indicates the end of the repeated code • Easier to read program if the lines of code between the FOR and NEXT are indented
