Software Security

1. Software Security Pieter.Hartel@utwente.nl

2. 2

3. 3 Overview Java Java Card Code Certification Attacks Conclusions

4. Java & Java Card

5. 5 What is Java Safety? Definition: nothing bad will happen Type safety Memory safety Java safety is limited

6. 6 What is Java Security? Access control to resources Java security policy (what) Policy manager assigns permissions to code base Java security mechanisms (how) Stack Inspection checks each frame Para 2.4 ACMCS paper Security manager consists of two components: Policy manager, which assigns permissions to a code source (basically the url where the class came from), specified in policy file Access controller performs stack inspection to ensure that all stack frames of the current call permit access, basically the intersection of all permissions There is a �super user� role which blurs the picture a bitPara 2.4 ACMCS paper Security manager consists of two components: Policy manager, which assigns permissions to a code source (basically the url where the class came from), specified in policy file Access controller performs stack inspection to ensure that all stack frames of the current call permit access, basically the intersection of all permissions There is a �super user� role which blurs the picture a bit

7. 7 How is Java implemented? Parsing Type checking Code generation Class loading Byte code verification Execution ACMCS paper para 2.3 Class loading is basically a format check Byte code verification is basically type checking -Check that frames do not under or overflow -Check that all byte codes are valid -Check that variables are initialised before use etcACMCS paper para 2.3 Class loading is basically a format check Byte code verification is basically type checking -Check that frames do not under or overflow -Check that all byte codes are valid -Check that variables are initialised before use etc

8. 8 Java?JVM: Initialis. example

9. 9 Security through obscurity? Information needed for safe loading ? information needed for de-compilation Only name obfuscation feasible

10. 10 Java card Basics Processing APDUs (more...) High level features Persistent objects in EEPROM Transient objects in RAM (Clear on Reset, Clear on Deselect) Atomic operations and transactions Applet firewall and controlled object sharing (more...) No need for expensive message passing

11. 11 Java ? Java Card Java card is a subset of java Subset of API, exceptions No concurrency, no garbage collection Java card is an extension of java Transactions, sharable objects, persistence However, a smart card is not a PC Tamper resistant ? Small, slow ? Credit card fraud drop by 75% over 5 years from 1992 in FranceCredit card fraud drop by 75% over 5 years from 1992 in France

12. 12 Java Card architecture

13. 13 Applet Development

14. 14 Applet naming AID = RID5 || PIX0..11 RID assigned by ISO to companies PIX assigned by individual company

15. 15 Applet life cycle JCRE �never� stops APDU controls applet, format: install and process applet methods

16. 16 4 public void process(APDU apdu){ 6 byte[] buffer = apdu.getBuffer(); 7 byte cla = buffer[ISO7816.OFFSET_CLA]; 8 byte ins = buffer[ISO7816.OFFSET_INS]; 12 short bytesLeft = (short) (buffer[ISO7816.OFFSET_LC] & 0x00FF); 13 if(bytesLeft < (short)55) ISOException.throwIt( ISO7816.SW_WRONG_LENGTH ); 15 short readCount = apdu.setIncomingAndReceive(); 16 while(bytesLeft > 0){ 18 bytesLeft -= readCount; 19 readCount = apdu.receiveBytes ( ISO7816.OFFSET_CDATA ); 20 } 29 short le = apdu.setOutgoing(); 30 if(le < (short)2) ISOException.throwIt( ISO7816.SW_WRONG_LENGTH ); 31 apdu.setOutgoingLength( (short)3 ); 34 buffer[0] = (byte)1; buffer[1] = (byte)2; buffer[3] = (byte)3; 35 apdu.sendBytes ( (short)0 , (short)3 ); 37 } Processing an APDU public class Test { public static void main( String[] args ) { byte[] buffer = { 0,1,2,-1,5 } ; short aap = (short) (buffer[3] & 0x00FF); int noot = (buffer[3] & 0x00FF); int mies = (buffer[3]); System.out.println( "aap=" + aap + " noot= " + noot + " mies= " + mies ) ; } } /* aap=255 noot= 255 mies= -1 */ public class Test { public static void main( String[] args ) { byte[] buffer = { 0,1,2,-1,5 } ; short aap = (short) (buffer[3] & 0x00FF); int noot = (buffer[3] & 0x00FF); int mies = (buffer[3]); System.out.println( "aap=" + aap + " noot= " + noot + " mies= " + mies ) ; } } /* aap=255 noot= 255 mies= -1 */

17. 17 Applet firewall Separates Applets Protects against mistakes Provides controlled sharing Firewall partitions object space in different �Contexts�

18. 18 Contexts JCRE defines privileged context Package defines regular context Context defines ownership, stacked Current context gets new object Invoke, return, exception may context switch

19. 19 Client & Sever Communication

20. 20 Sharable Interface Object (1) A sharable interface object is like a normal object to the owner Others can only access the methods defined in the shareable interface

21. 21 Sharable Interface Object (2)

22. 22 Java Card implementation Class loading Byte code verification CAP file generation Digital signature Class loading Signature verification Execution

23. 23 Signatures for code certification Producer of code c: Hash the code c: h=hash(c) Sign with private key k: s=decrypt(k,h) Send (c, s) to the consumer Why not sign c? Consumer of code (c�, s�): Hash code c�: h�=hash(c�) Check s� with public key K: h��=encrypt(K,s�) Ok if h�=h�� Is then also h=h�?

24. 24 Conclusions State of the art Easier to program than assembly Open issues Garbage collection Commercial success Java (2 Billion phones, 1 Billion PCs) Java card (4 Billion cards)

25. Code certification without signatures

26. 26 Self Certified Code Server (consumes code): Publish safety policy = Given precondition + Weakest precondition Rules Validation = Import code + proof and Check proof Run Client (produces code): Certification = Generate proof and Export Code + proof Given precondition = calling convention Weakest precondition Rules = when is program safe Safety predicate => safety Collect safety checks in safety predicateGiven precondition = calling convention Weakest precondition Rules = when is program safe Safety predicate => safety Collect safety checks in safety predicate

27. 27 SCC Architecture

28. 28 Extended abstract machine op ::= n where n ? minint...maxint |r0 |r1 |r2 instr ::= LD rd, n(rs) May read at rs+n |ST rs, n(rd) May write at rd+n |ADD rs, op, rd |BEQ rs, n May jump to n if rs=0 |RET Semantics include safety checks No loops... Semantics include safety checks No loops...

29. 29 Code example: simple filter % Address of tag in r0 ADD r0, 8, r1 % Address of data in r1 LD r0, 8(r0) % Data in r0 LD r2,-8(r1) % Tag in r2 ADD r0, 1, r0 % Increment r0 BEQ r2,7 % Branch if tag = 0 ST r0, 0(r1) RET Speculative scheduling DEC Alpha styleSpeculative scheduling DEC Alpha style

30. 30 Pre & post condition Precondition r0 is word aligned May read tag at r0 May read data at r0+8 May write data at r0+8 if tag?0. Abstract Machine semantics Generate safety conditions Postcondition true Nothing else is permittedNothing else is permitted

31. 31 Average runtime per packet

32. 32 High upfront cost

33. 33 Advantages/Disadvantages + No cryptography, no key management + Any policy possible + Can be used for unsafe language. � Does it scale up? � Window of opportunity from validation to execution (more...)

34. Attacks

35. 35 Vulnerability Time-of-check ? time-of-use A single bit error gives 70% probability of taking over the JVM

36. 36 Memory error attack Cosmic ray �Converts� A ref to B ref Subvert type system 70% success with millions of references Bits flip rarely Heating causes the OS to crashBits flip rarely Heating causes the OS to crash

37. 37 The experiment

38. 38 And the rest of the world? The Operating System is the main culprit 15,000 bugs in the Linux kernel, far more in Windows An estimated 24 in the Minix-3 micro-kernel, drivers isolated... Can the kernel be verified?

39. 39 Conclusions Java is a good starting point Reduce the trusted computing base Micro kernel Verification works in the small Security is not necessarily crypto Out of the box thinking...
