climate change scenario analysis in the future over western of china

Climate Change Scenario Analysis in the Future Over western of China

Ying Xu Xuejie Gao Yun Gao

National Climate Centre, China

AIACC workshop, Philippines

Nov. 04, 2004

outline
Outline
  • Part I: Possible Climate Change in Western

China due to human activities by AOGCM

  • Part II: Possible Climate Change in Western

China due to human activities by RegCM

(1) Climate Change in the future over China due to GHG

(2)Impacts of Land-use Change on Climate in China

  • Part III: next step work plan
slide4

Models Description

A2: SRES scenario—A2

B2: SRES scenario—B2

the change of temperature over western of china in 21 st century unit

A2

B2

The change of temperature over western of China in 21st century (unit:℃)

Red: 5 model mean

Dark blue: Hadley

Sky blue: CCSR

Green: CCCma

Yellow: CSIRO

Pink: NCC/IAP

For 5 models mean, the temperature will increase about 8℃ under A2 scenario in the end of 21st century, increasing is about 5℃ under B2 scenario.

the change of precipitation over western of china in 21 st century unit

A2

B2

The change of precipitation over western of China in 21st century (unit:%)

Red: 5 model mean

Dark blue: Hadley

Sky blue: CCSR

Green: CCCma

Yellow: CSIRO

Pink: NCC/IAP

For 5 models mean, the Pr. will increase about 10% under A2 scenario in the end of 21st century, it will increase 8% under B2 scenario.

the seasonal precipitation change over western of china in 21 st century unit

A2

B2

The seasonal precipitation change over western of China in 21st century (unit:%)

Red: annual mean

Dark blue: Spring

Sky blue: Summer

Green: Autumn

Yellow: Winter

The Pr. increasing is greater in winter and spring, change is little in summer and autumn under A2 and B2 scenarios.

the distribution of annual mean temperature change over western of china 2070 2099 unit
The distribution of annual mean temperature change over western of China (2070~2099) (unit:℃)
the distribution of annual mean precipitation change over western of china 2070 2099 unit
The distribution of annual mean precipitation change over western of China (2070~2099) (unit:%)
part i conclusions
Part I : Conclusions
  • Warming is obviously in western of China, warming is exceed China mean value .
  • Compared A2 scenario with B2, it shows a majority of warming under A2 scenario than B2, So depend on different greenhouse gases emission scenario, the climate will have different change in the future.
  • The annual mean precipitation will increase in the end of 21st century.
  • For different season, most obvious rainfall increase occurs in winter and spring,the increase in autumn and summer are little.
  • For the spacial distribution, The precipitation has an increasing trend, especially in the Western China and North-western China region, while the increase is not so obvious in the Southwestern China
slide13
Part II

Possible Climate Change

in Western China due to the effect of human activities by RegCM

slide14

PartⅡ

(1) Possible Climate Change in China

5 year RCM

12h

5 year GCM

5 year RCM CTL

12 h

5 year GCM CTL

2070

Observed CO2 Concentration

1990

1881

GCM Run

Model output was interpolated to 160 stations of China

slide15

PartⅡ

Annual mean Ts Change in China

(unit: ℃)

Increase all over the area, with a higher increase in North China, it is obviously in western of China

slide16

PartⅡ

Annual mean Pr Change in China (unit: %)

Increase in most areas, higher in NW

slide17

PartⅢ

Change of Annual mean rain days (%)

●:-20~0

●: 0~10

■: 10~20

slide18

PartⅡ

  • Conclusions :
  • Ts in China will remarkably rises by 2.5oC, with
  • higher increase western of China
  • Pr will also increase by about 25%.
  • Increase of rain days in western of China.
slide19

PartⅣ

(2)Impacts of Land-use Change on Climate in China

Land-use changes a lot in China for its long agriculture

history and present big population pressure

slide20

PartⅣ

Landuse Change

in China

▼: tree →shrub

▲: tree → irrigated crop farming

●: semi desert → desert

■: tree → crop/mixed farming

◆: grass→ rop/mixed farming

Areas of no change:2: short grass 3: evergreen needleleaf tree

5: deciduous broadleaf tree 6: evergreen broadleaf tree 7: tall grass 8: desert

slide21

PartⅣ

Experiment Design:

5 year RegCM2 run driven by

5 year CTL run of AOGCM

Exp 1. With potential vegetation cover

Exp 2. With present vegetation cover

Exp2-Exp1,

was thought as the impact of landuse change on climate

Plotted and analysed in 160 station positions

slide22

PartⅣ

Change of Annual mean Ts (℃)

●:-1.5~0

■:0~1.5

slide23

PartⅣ

Change of Annual mean Pr (%)

■:<-20%

■:-20%~0

●:0~20%

●:>20%

Dotted spots are stations with change passed 90%t- test, same as below

slide24

PartⅣ

Change of Summer Tmax (℃)

●:-2.4~0

■:0~2.4

■:2.5~4.4

◆:>4.5

slide25

PartⅣ

Change of Winter Tmin (℃)

●:<-2.4

●:-2.4~0

■:0~2.4

■:>2.5

slide26

PartⅣ

Change of Annual mean Soil moisture (%)

■:-20~0

●:0 ~ 20

slide27

PartⅣ

  • Conclusions :
  • Current Landuse in China, may caused:
  • Less rainfall in NW;
  • Temperatures increasing is in Sichuan basin and part of NW area;
  • Increasing of summer Tmax in many places, Increasing of winter Tmin in NW;
  • Decrease of Soil moisture in many places, including western of China;
  • Same landuse can cause different climate effect, depends on the geography character in the area.
part iii next step work
Part III Next step work
  • Using dynamical downscaling is going to coutinue simulate various episodes in 21st Century with the regional climate model with the boundary conditions provided by the global model.
  • To apply the simulation results of the global and regional climate models into a hydrological model, to simulate the future hydrological cycle over the Western of China.
  • To provide the projected climate change simulations over the Northwestern China to the relative research groups for impacts and adaption.
slide29

The End

Thanks!
