a physical resource management approach to minimizing fpga partial reconfiguration overhead

A Physical Resource Management Approach toMinimizing FPGA Partial Reconfiguration Overhead

Heng Tan and Ronald F. DeMaraUniversity of Central Florida

agenda
Agenda
  • Introduction
  • Previous work on reducing Partial Reconfiguration overhead
  • Develop a multi-step physical area management strategy
  • Experimental case studies:
    • 4 simple circuits: serial, parallel, block multiplier resource,high fanout carry chain LUT multiplier
    • 2 large circuits: SECDED, MD5 step function (new)
  • Conclusion and future work
motivation
Motivation

For partial reconfiguration operations, especially those running on a SOC configuration,

  • storage space and
  • reconfiguration speed

are crucial.

 Find way to optimize them . . .

previous work
Previous Work
  • Architecture-level [Ganesan2000]
    • Pipelining
    • overlap execution of one temporal partition with reconfiguration of another
  • Logical level [Raghuraman2005]
    • Minimization of frames
    • relating the number of frames that need to be downloaded into FPGAs to the number of minterms of a specially constructed logic function
  • Hardware level [Compton2002][Hauck1999]
    • Requires dedicated HW component
    • Compression or defragmentation performed externally at runtime
  • Physical-level resource management?
    • Not specifically addressed for partial reconfiguration modules in literature
    • But can be done … and … also cascaded with above techniques for multiplicative benefit
module based flow
Module Based Flow

Basic concept and capability for PR proposed by Xilinx

  • Including Fixed modules and PR modules
  • Using Bus Macro
  • Suitable for potential full automation
  • Primary PR technique to study
column level configuration format
Column-Level Configuration Format
  • For Virtex II/Pro series
  • Including IOB, IOI, CLB, GCLK, BlockRAM, and BlockRAM Interconnect
  • Labeling with 32-bit addresses composed of a Block Address (BA), a Major Address (MJA), a Minor Address (MNA), and a byte number
  • Only contents of CLB column are studied in this research
bitstream compression
Bitstream Compression
  • CLB columns program the configurable logic blocks, routing, and most interconnect resources.
  • Each CLB column contains 2 columns of slices.
  • 22 frames are utilized within the bitstream for each column of slices, describing the logic and routing information respectively.
  • Each frame occupies 424 bytes.
  • In bitstream of PR modules, a compression technique is already used by Xilinx to represent the unused CLB frame.
  • For unused CLB frames, only 10 bytes are used instead of 424 to describe empty contents.
optimization strategy
Optimization Strategy
  • Primary goal: minimize the number of columns of slices utilized, including routing resources
  • Secondary goal: do not incur increase in propagation delay after area optimization
  • Physical area management procedure:
      • Region Allocation: define size and boundary
      • Pin Assignment: top/bottom edge preferred
      • Column Alignment: fill column of slices at a time
      • Choke-Point Elimination: resolve high fanout cases
      • Repeat
case study
Case Study
  • The hardware platform is Xilinx Virtex II Pro VP7 device.
  • Module-based partial reconfiguration flow is adopted to generate the partial reconfiguration bitstream.
  • The Xilinx ISE 6.3 is used to support the module based flow.
  • The area constraints are entered directly into User Constrain File (.ucf)before map and routing.
  • Four representative small cases and two larger size cases studies are tested for the strategy.
  • Similar or identical external pin arrangement.
  • Hypothesis: larger circuits can achieve more savings
4 lut design optimization parallel
4-LUT Design Optimization (parallel)
  • Simple 4-LUT elements
  • Parallel logic path with direct input from external signals
  • LUTs feed outputs straight though to flip flops
  • Best strategy is by locating them in a single column close to the external pins
shifter optimization serial
Shifter Optimization (serial)
  • All logic elements are cascaded in contiguous string of CLBs
  • Attributes of this serial circuit functionality will have best arrangement from input to output in single column serially
block multiplier optimization
Block Multiplier Optimization
  • Block multiplier resource involved
  • Requires balancing the routing between two paths.
  • One path is between the block multiplier and the LUTs. The other path is from the LUTs to the external pins.
  • Decreased savings compared to use of LUT-only circuits
lut multiplier optimization
LUT Multiplier Optimization
  • High fan-out occurs because of the carry chains
  • Single column style is not optimal
  • Arrange related LUTs around each other using adjacent columns
larger case studies
Larger Case Studies
  • SECDED as full PR module and MD5 step functions were developed as PR module vs. SHA family
  • During the optimization process, not every slice has been specifically placed because of the large number of resources involved
  • Only the slices on the critical path are constrained.
  • These are comparatively larger modules, increased bitstream savings of 33% and 30% are achieved
area optimization results
Area Optimization Results
  • A physical resource area management strategy is proposed to minimize the reconfiguration overhead.
  • Experiments show that up to one-third of size reduction can be achieved for partial reconfiguration modules.
  • The maximum propagation delay has also been decreased slightly in most cases (not increased).
  • On the other hand, the larger the module is, the more complicated and time consuming the process becomes.
  • Providing autonomous area optimization capabilities is future work for integrating into our Multi-Layer Runtime Reconfiguration Architecture FGPA framework
current work direct bitstream management
Current Work:Direct Bitstream Management
  • Change one-bit full adder to a one-bit full subtracter
  • Both have three one-bit inputs and two one-bit outputs.
  • Both used 2 LUTs with identical logic interconnections between LUTs and I/O signals.
  • Only difference between them is actually only one truth table stored inside one LUT, changing from 0xE8 to 0x8E

Combined MD5 / SHA-1

Step Function – Area Utilization

Original AlgorithmModule Based Frame Based

SHA-1 192(slices) 65(slices)32(slices)

MD5 881(slices) 168(slices) 32(slices)

Combined 1068(slices) 324(slices) 32(slices)
