PCB Fabrication at EFPCB

Many new areas of technology are employed by RF PCB manufacturing and to be made both in the reduction of tracks used and sizes of components as well as in the board's reliability, this has enabled significant improvements.

efpcb
Download Presentation

PCB Fabrication at EFPCB

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. WELCOME TO EFPCB.COM

  2. Smart Home Main Boards Small Spacing HD LED Display Main Board Layer count: 4 printed circuit board Material: FR4 , 1.0mm,  high TG , 1 OZ  for all layer Minimum tack:  6mil Minimum space(gap): 6milMinimum hole: 0.20mmSurface finished: OSPPanel size: 320*268mm/1up

  3. Aerospace Defense Industry PCB Minimum space(gap): 5 milMinimum hole: 0.25mmSurface finished: ENIGPanel size: 228*158mm/3up Rigid Flex PCB with Hard Gold plating, Via on Pads Boards Layer count: 8 layerMaterial: FR4, 1.6mm, TG 180 + 2 mil PI, 1 OZ for all layer Minimum track: 4 mil

  4. Medical Device PCB Multilayer Rigid Flex Printed Circuits Layer count: 4 layerMaterial: FR4 IT180A, high TG +1mil PI, 1.00mm,  1 OZ for all layer Minimum tack: 3.5 milMinimum space(gap): 3.5 milMinimum hole: 0.20mmSurface finished: ENIGPanel size: 128*148mm/4up

  5. Industrial Control PCB | Industry control PCB HDI Printed Circuit Board Layer count: 6 HDI PCBMaterial: FR4 , 1.0 mm, High TG, 0.5 OZ  for all layerMinimum tack: 2 mil Minimum space(gap): 2 milMinimum hole: 0.15mmSurface finished: ENIGPanel size: 220*268mm/4up

  6. Our Organization Our Milestones
