  1. Fuzzing Processor Performing Security Auditing In Hardware Tony Fynn Dustin Locke

  2. Overview • What is fuzzing? • Project goals • Architecture details • Optimizations • Performance • Conclusion

  3. What is Fuzzing? • Sending semi-random data to an application to try and make it misbehave • Used to detect vulnerabilities 11010010 01010101

  4. Types of Fuzzing TCP Packet Source port Destination port Sequence number Acknowledgment number Hdr length Reserved/flags Window size Checksum Urgent pointer Intelligent fuzzing Dumb fuzzing Options Data Naively fuzzes all data Selectively fuzzes certain fields

  5. Goals • Ability to fuzz multiple types of data (robust) • Intelligent fuzzing • Using structural knowledge to our advantage • High-speed • The goal would be to have a network protocol fuzzer that accepts packets on one side, mangles them, and sends them on their way through the other side • For our purposes, we perform the fuzzing operation on data from input files 1011 0110 Fuzzer

  6. Architecture Register File – 256-bit registers, 32-bit mask New Instructions – fzlw, fzsw, fuzz, mskh, mskl Fuzzing Unit 256-bit SRAM MUX mask MUX FUZZER SRAM 32 FUZZING UNIT 256 – BIT FUZZING REGISTERS 1 data 256 addr + wr_en PC ALU GENERAL REGISTERS DATA MEMORY MUX MUX IMEM

  7. Fuzzing Unit • Takes as input a data word and a mask specifying which bytes are “fuzzable” in the data word • Generates a random number and XORs fuzzable data bytes with corresponding random number bytes 11010110 00001111 00000110 11010000 11010110

  8. Register File • 256 bit word length • Parallel 32-bit data/mask registers • Read operation puts data word as well as its corresponding mask on the data output lines Register 1 Mask 1 Register 2 Mask 2 Register 3 Mask 3 Register 4 Mask 4 … … Register 8 Mask 8

  9. Optimizations • Mask in register file is per byte, not per-bit • Each bit masks an entire byte in the data word • 256-bit random number generated from 32 parallel 8-bit random numbers • Prevents an expensive 256-bit multiply • Drastically reduces gate delay of fuzzer

  10. Data Throughput • Fuzzing unit has maximum gate delay of 21ns • Translates to maximum clock speed of about 48 MHz • Effectively fuzz 256 bits of data in 5 clock cycles (for large amounts of data and a full pipeline) • Resulting maximum throughput is ~2.5 Gbps for dedicated application • Able to keep up with line speed of OC-48 fiber line (~2.5 Gbps) 1011 0110 Fuzzer

  11. Conclusion/Summary • Able to fuzz multiple types of data? • Yes • Able to perform intelligent fuzzing? • Use of data mask allows selective fuzzing • High speed? • Able to keep up with OC-48 • It is entirely possible to perform intelligent, reconfigurable fuzzing in hardware at high speeds

  12. Questions
