Chapter 13 – Buckling of Columns

Chapter 13 – Buckling of Columns. Failure mode of column = buckling (i.e. not stress) At P cr , stress less than yield strength!. At Pcr, column is on verge of being unstable so small lateral force, F will cause column to buckle.

dannon
Download Presentation

Chapter 13 – Buckling of Columns

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Chapter 13 – Buckling of Columns

  2. Failure mode of column = buckling (i.e. not stress) At Pcr, stress less than yield strength!

  3. At Pcr, column is on verge of being unstable so small lateral force, F will cause column to buckle. When F is removed, stays buckled. If P reduced to below Pcr will straighten out, if P increased beyond Pcr will increase lateral deflection Load P can be increased until failure occurs by yield or fracture

  4. Derivation of Euler’s Equation: Homogeneous, second order, linear DE with constant coefficients.

  5. Solution to DE is: C1 and C2 = constants of integration. u=0 at x=0 so C2=0. Which leaves: Which is satisfied if: Smallest value of P??

  6. Euler’s Equation PCR = critical or maximum axial load on the column just before it begins to buckle. E = modulus of elasticity for the material I = least moment of inertia of the column’s cross-section L = unsupported length of the column, whose ends are pinned

  7. Examples:
