significant changes to the 2007 florida residential code chapters 1 thru 3 first coast chapter boaf
Significant Changes to the 2007 Florida Residential Code Chapters 1 thru 3First Coast Chapter/BOAF
learning objectives
Learning Objectives

The attendees will obtain the information on the Florida Specific Code Changes and perhaps more importantly be aware of the base code changes found in the 2006 IRC from the 2003 IRC that Florida does not identify as a change.

disclaimer
DISCLAIMER
  • Note:

Every effort has been made to identify all changes found in the 2007 Florida Building Code-Residential.

However, not all may have been identified, and it is up to the user to become familiar with the code sections that they are using.

2007 florida residential code chapters 1 and 2

2007 Florida Residential Code, Chapters 1 and 2.

Preface

|| Marginal Markings

Vertical lines in the margins within the body of the code indicate a change from the requirements of the base codes to the 2007

Florida Building Code effective March 1, 2009.

Sections deleted from the base code are designated “Reserved.”

chapter 1 administration new section
Chapter 1Administration NEW SECTION

SECTION 105.15 Florida Building Code-Building

When any activity requiring a building permit that is applied for on or after July 1, 2008, and for which the estimated cost is $50,000 or more for a building that is located in the wind borne debris region as defined in the Florida Building Code and that has an insured value of $750,000 or more, or, if the building is uninsured or for which documentation of insured value is not presented, has a just valuation for the structure for purposes of ad valorem taxation of $750,000 or more.

Opening protections as required within the Florida Building Code, Building or Florida Building Code, Residential for new construction shall be provided.

chapter 2 definitions
Chapter 2-Definitions

Accessory Structure.

A structure not greater than 3,000 square feet in floor area, and not over two stories in height, the use of which is customarily accessory to and incidental to that of the dwelling(s) and which is located on the same lot.

chapter 2 definitions7
Chapter 2-Definitions

Air-Impermeable insulation.

An insulation having an air permeance equal to or less than 0.02 L/s-m2 at 75 Pa pressure differential tested according to ASTM E 2178 or E 283.

chapter 2 definitions8
Chapter 2-Definitions

R201.5 Terms relevant to the energy provisions of Chapter 11 shall be as defined in Section N 1100.7.3

definition changes
DEFINITION CHANGES
  • APPROVED. Acceptable to the building official.
  • APPROVED AGENCY. An established and recognized agency regularly engaged in conducting tests or furnishing inspection services, when such agency has been approved by the building official.
section r 202 definitions
SECTION R 202 – DEFINITIONS
  • AWNING. Any rigid or movable (retractable) roof-like structure, cantilevered, or otherwise entirely supported from a building. An awning is comprised of a lightweight rigid or removable skeleton structure over which an approved cover is attached.
section r 202 definitions11
SECTION R 202 – DEFINITIONS
  • CANOPY.
  • Any fixed roof-like structure, not movable like an awning, and which is cantilevered in whole or in part self supporting, but having no side walls or curtains other than valances not more than 18 inches deep. Lean-to canopies, fixed umbrellas and similar structures are included in this classification. Structures having side walls or valances more than 18 inches deep shall be classified as a tent

as set forth herein.

section r 202 definitions12
SECTION R 202 – DEFINITIONS
  • CARBON MONOXIDE ALARM.
  • A device for the purpose of detecting carbon monoxide, that produces a distinct audible alarm, and is listed or labeled with the appropriate standard, either ANSI/UL 2034 - 96, Standard for Single and Multiple Station CO Alarms, or UL 2075 - 04, Gas and Vapor Detector Sensor, in accordance with its application.
section r 202 definitions13
SECTION R 202 – DEFINITIONS
  • CIRCULAR STAIRS. A stairway with steps that result in a sweeping circular or curved pattern, but not spiral stairs.
  • COMMISSION. Means the Florida Building Commission created by this part.
section r 202 definitions14
SECTION R 202 – DEFINITIONS
  • CONDITIONED SPACE. For energy purposes: See Space (a) conditioned space, Chapter 11, Section N1100.7.3.. For mechanical purposes, an area, room or space being heated or cooled by any equipment or appliance.
section r 202 definitions15
SECTION R 202 – DEFINITIONS
  • EMERGENCY ESCAPE AND RESCUE OPENING. An operable exterior window, door or similar device that provides for a means of escape and access for rescue in the event of an emergency.
definition changes in the 2007 florida residential code
DEFINITION CHANGES in the 2007 FLORIDA RESIDENTIAL CODE.
  • EXTERIOR WALL. {An above-grade wall enclosing conditioned space.} An above-grade wall that defines the exterior boundaries of a building. Includes between-floor spandrels, peripheral edges of floors, roof and basement knee walls, dormer walls, gable end walls, walls enclosing a mansard roof and basement walls with an average below-grade wall area that is less than 50 percent of the total opaque and nonopaque area of that enclosing side
section r 202 definitions17
SECTION R 202 – DEFINITIONS
  • FABRIC COVERED FRAMEWORK (FCF). A nonpressurized structure which is composed of a rigid framework to support tensioned membrane or fabric which provides the weather barrier.
section r 202 definitions18
SECTION R 202 – DEFINITIONS
  • FIRE SEPARATION DISTANCE. The distance measured from the building face to one of the following:
  • 1. To the closest interior lot line; or
  • 2. To the centerline of a street, an alley, easement or public way; or
  • 3. To an imaginary line between two buildings on the lot.
  • The distance shall be measured at a right angle from the face of the wall.
section r 202 definitions19
SECTION R 202 – DEFINITIONS
  • FOSSIL FUEL. Coal, kerosene, oil, fuel gases, or other petroleum or hydrocarbon product that emits carbon monoxide as a by-product of combustion.
section r 202 definitions20
SECTION R 202 – DEFINITIONS
  • GARAGE DOOR MANUFACTURER. The party responsible for the completed assembly of the garage door components.
section r 202 definitions21
SECTION R 202 – DEFINITIONS
  • HABITABLE SPACE. A space in a structure for living, sleeping, eating or cooking. Bathrooms, toilet compartments, closets, halls, screen enclosures, sunroom Categories I, II and III as defined in the AAMA/NPEA/NSA 2100, storage or utility

space, and similar areas are not considered habitable space.

section r 202 definitions22
SECTION R 202 – DEFINITIONS
  • PERMANENT LABEL. A label that cannot be removed without noticeable damage.
section r 202 definitions23
SECTION R 202 – DEFINITIONS
  • SPIRAL STAIRS. A stairway with steps that have a central connecting point, and the travel path is a corkscrew or spiral.
section r 202 definitions24
SECTION R 202 – DEFINITIONS
  • STREET. Any public thoroughfare, street, avenue, boulevard or space more than 20 feet wide which has been

dedicated or deeded for vehicular use by the public and which can be used for access by fire department vehicles.

section r 202 definitions25
SECTION R 202 – DEFINITIONS

SUNROOM.

1. A room with roof panels that include sloped glazing that is a one-story structure added to an existing dwelling with an open or glazed area in excess of 40 percent of the gross area of the sunroom structure’s exterior walls and

roof.

2. A one-story structure added to a dwelling with structural roof panels without sloped glazing. The sunroom walls may have any configuration, provided the open area of the longer wall and one additional wall is equal to at least 65 percent of the area below 6 feet 8 inches of each wall, measured from the floor. For the purposes of this code the term “sunroom” as used herein shall include conservatories, sunspaces, solariums, and porch or patio covers or enclosures.

section r 202 definitions26
SECTION R 202 – DEFINITIONS

UNUSUALLY TIGHT CONSTRUCTION. Construction

meeting the following requirements:

1. Walls comprising the building thermal envelope have a

continuous water vapor retarder with a rating of 1 perm

[57.4 ng/(s · m2 · Pa)] or less with openings therein

gasketed or sealed.

2. Doors and openable windows meet the air leakage

requirements of Chapter 13, Section 606 of the Florida

Building Code, Building; and

3. Caulking or sealants are applied to areas such as joints

around window and door frames between sole plates and

floors, between wall-ceiling joints, between wall panels,

at penetrations for plumbing, electrical and gas lines, and

at other openings.

definition changes in the 2007 florida residential code27
DEFINITION CHANGES in the 2007 FLORIDA RESIDENTIAL CODE.
  • WALL, RETAINING. A wall not laterally supported at the top, that resists lateral soil load and other imposed loads.
chapter 3 building planning r301 2 1 1 2 sunrooms
Chapter 3-Building Planning-R301.2.1.1.2-Sunrooms.
  • Sunrooms shall comply with AAMA/NPEA/NSA 2100 with the structural requirements and testing provisions of Chapter 5 modified to incorporate ASCE 7. Sunrooms shall be categorized in one of the following categories by the permitapplicant, design professional or the property owner where the sunroom is being constructed.
chapter 3 building planning r301 2 1 1 2 sunrooms category i
Chapter 3-Building Planning-R301.2.1.1.2-Sunrooms-Category I
  • Category I: A roof or a covering of an outdoor space. The openings shall be permitted to be enclosed with insect screening or 0.5 mm (20 mil) maximum thickness plastic film. The space is defined as nonhabitable and unconditioned.
chapter 3 building planning r301 2 1 1 2 sunrooms category ii
Chapter 3-Building Planning-R301.2.1.1.2 Sunrooms-Category II
  • Category II: A roof or a covering of an outdoor space with enclosed walls. The openings are permitted to be enclosed with translucent or transparent plastic or glass. The space is defined as nonhabitable and

unconditioned

chapter 3 building planning r301 2 1 1 2 sunrooms category iii
Chapter 3-Building Planning-R301.2.1.1.2 Sunrooms-Category III
  • Category III: A roof or a covering of an outdoor space with enclosed walls. The openings are permitted to be enclosed with translucent or transparent plastic or glass. The sunroom complies with additional requirements for forced-entry resistance, air-leakage resistance and water-penetration resistance. The space is defined as nonhabitable and unconditioned.
chapter 3 building planning r301 2 1 1 2 sunrooms category iv
Chapter 3-Building Planning-R301.2.1.1.2 Sunrooms-Category IV
  • Category IV:A roof or a covering of an outdoor space with enclosed walls. The sunroom is designed to be heated and/or cooled by a separate temperature control or system and is thermally isolated from the primary structure. The sunroom complies with additional requirements for forced-entry resistance, water penetration resistance, air-leakage resistance, and thermal performance. The space is defined as habitable and conditioned.
chapter 3 building planning r301 2 1 1 2 sunrooms category v
Chapter 3-Building Planning-R301.2.1.1.2 Sunrooms-Category V
  • Category V: A roof or a covering of an outdoor space with enclosed walls. The sunroom is designed to be heated and/or cooled and is open to the main structure. The sunroom complies with additional requirements for forced-entry resistance, water-penetration resistance, air-leakage resistance, and thermal performance. The space is defines as habitable and conditioned.
chapter 3 building planning r301 2 1 2 protection of openings
Chapter 3-Building Planning-R301.2.1.2-Protection of Openings
  • 1. Opening in sunrooms, balconies or enclosed porches constructed under existing roofs or decks are not required to be protected provided the spaces are separated from the building interior by a wall and all openings in the separating wall are protected in accordance with this section. Such space shall be permitted to be designed as either partially enclosed or enclosed structures.
chapter 3 building planning section r301 2 1 4 exposure category
Chapter 3-Building Planning-Section R301.2.1.4 Exposure Category
  • Note that Categories “A” & “D” are currently not applicable in Florida.
  • Key Word CURRENTLY.
chapter 3 building planning section r301 2 1 4 exposure category37
Chapter 3-Building Planning-Section R301.2.1.4 Exposure Category
  • R301.2.1.4 Exposure category. For each wind direction considered, an exposure category that adequately reflects the characteristics of ground surface irregularities shall be determined for the site at which the building or structure is to be constructed. For a site located in the transition zone between categories, the category resulting in the largest wind forces shall apply. Account shall be taken of variations in ground surface roughness that arise from natural topography and vegetation as well as from constructed features. For any given wind direction, the exposure in which a specific building or other structure is sited shall be assessed as being one of the following categories:
  • Exception: An intermediate exposure between the exposure categories defined is permitted in a transition zone provided that it is determined by a rational analysis method.
chapter 3 building planning section r301 2 1 4 1 exposure category
Chapter 3-Building Planning-Section R301.2.1.4.1 Exposure Category
  • R301.2.1.4.1 Wind directions and sectors. For each selected wind direction at which the wind loads are to be evaluated, the exposure of the building or structure shall be determined for the two upwind sectors extending 45 degrees (0.79 rad) either side of the selected wind direction. The exposures in these two sectors shall be determined in accordance with Sections R301.2.4.2 and R301.2.1.4.3 and the exposure resulting in the highest wind loads shall be used to represent winds from that direction.
chapter 3 building planning section r301 2 1 4 1 2 exposure category
Chapter 3-Building Planning-Section R301.2.1.4.1.2 Exposure Category
  • R301.2.1.4.1.2 Surface roughness categories. A ground surface roughness within each 45-degree (0.79 rad) sector shall be determined for a distance upwind of the site as defined in Section R301.2.1.4.3 from the categories defined below, for the purpose of assigning an exposure category as defined in Section R301.2.1.4.3.
chapter 3 building planning section r301 2 1 4 2 surface roughness b
Chapter 3-Building Planning-Section R301.2.1.4.2 Surface Roughness B
  • Exposure B. Urban and suburban areas, wooded areas or other terrain with numerous closely spaced obstructions having the size of single-family dwellings or larger. Exposure B shall be assumed unless the site meets the definition of another type exposure
chapter 3 building planning section r301 2 1 4 surface roughness c
Chapter 3-Building Planning-Section R301.2.1.4 Surface Roughness “C”
  • Surface Roughness C.
  • Open terrain with scattered obstructions having heights generally less than 30 feet. This category includes flat open country, grasslands, and all watersurfaces in hurricane-prone regions. This surface roughness shall also apply to any building located within surface roughness B-type terrain where the building is within 100 feet horizontally in any direction of open areas of surface roughness C-type terrain that extends more than 600 feet and width greater than 150 ft. in the upwind direction. Short-term (less than two year) changes in the pre-existing terrain exposure, for the purposes of development, shall not be considered surface roughness C. Where development buildout will occur within three years and the resultant condition will meet the definition of surface roughness B, surface roughness B shall be regulating for the purpose of permitting. This category includes flat open country, grasslands and ocean or gulf shorelines and shall extend downwind for a distance of 1500 feet.
chapter 3 building planning section r301 2 1 4 3 exposure category
Chapter 3-Building Planning-Section R301.2.1.4.3 Exposure Category
  • R301.2.1.4.3 Exposure categories.
  • An exposure category shall be determined in accordance with the following:
chapter 3 building planning section r301 2 1 4 3 exposure category43
Chapter 3-Building Planning-Section R301.2.1.4.3 Exposure Category
  • 1 Exposure B. Exposure B shall apply where the ground surface roughness condition, as defined by Surface Roughness B, prevails in the upwind direction for a distance of at least 2,600 feet or 20 times the height of the building, whichever is greater.
  • Exception: For buildings whose mean roof height is less than or equal to 30 feet, the upwind distance is permitted to be reduced to 1,500 feet.
chapter 3 building planning section r301 2 1 4 3 exposure category45
Chapter 3-Building Planning-Section R301.2.1.4.3 Exposure Category
  • 2 3. Exposure C. No change.
  • Exposure C. Exposure C shall apply for all cases where Exposure B does not apply.Buildings located within a distance of 600 feet of inland bodies of water that present a fetch of 1 mile or more or inland waterways or rivers with a width of 1 mile or more shall be classified as Exposure C and roof sheathing uplift and roof-to-wall uplift loads shall be increased by 20 percent.
slide49

Chapter 3-Section Table 301.5-IRC clarified the truss-loading criteria for attics with and without storage, change in the Florida Residential Code.

  • Attics without storage are those where the maximum clear height between joist and rafter is less than 42 inches, or where there are nottwo or more adjacent trusses with the same web configuration capable of containing a rectangle 42 inches high by 2 feet wide, or greater, located within the plane of the truss. For attics without storage, this live load need not be assumed to act concurrently with any other live load requirements.
chapter 3 table r301 5
Chapter 3- Table R301.5
  • Footnote g.
  • For attics with limited storage and constructed with trusses, this live load need be applied only to those portions of the bottom chord where there are two or more adjacent trusses with the same web configuration capable of containing a rectangle 42 inches high or greater by 2 feet wide or greater, located within the plane of the truss. The rectangle shall fit between the top of the bottom chord and the bottom of any other truss member, provided that each of the following criteria is met:
chapter 3 table r301 5 footnote g continued
Chapter 3-Table R301.5 footnote g continued:
  • 1. The attic area is accessible by a pull-down stairway or framed opening in accordance with Section R807.1; and
  • 2. The truss has a bottom chord pitch less than 2:12.

When these two items occur this area is storage and needs the additional loading. Instructor Note.

chapter 3 table r301 5 footnote h
Chapter 3- Table R301.5 footnote h.
  • h. Attic spaces served by a fixed stair shall be designed to support the minimum live load specified for sleeping rooms.
section r302 1 exterior walls florida specific
Section R302.1 Exterior Walls Florida Specific
  • Section R302.1 Exterior walls, add text to read as follows:
  • R302.1 Exterior walls. No change.
  • Exceptions:
  • 1-3 No change.
  • 4. Openings and roof overhang projections shall be permitted on the exterior wall of a building located on a zero lot line when the building exterior wall is separated from an adjacent building exterior wall by a distance of 6 feet or more, and the roof overhang projection is separated from an adjacent building projection by a distance of 4 feet or more, with 1 hour fire resistive construction on the underside of the overhang required, unless the separation between projections is 6 feet or more.
chapter 3 florida stayed with the 6 foot section r302 exterior wall location
Chapter 3-Florida stayed with the 6 foot. Section R302 Exterior Wall Location
  • TABLE R302.1

EXTERIOR WALLS

EXTERIOR WALL ELEMENT MINIMUM FIRE-RESISTANCE RATING MINIMUM FIRE SEPARATION DISTANCE

  • Walls (Fire-resistance rated) 1 hour with exposurefrom both sides 0 feet

(Not fire-resistance rated) 0 hours 3 feet

  • Projections
  • (Fire-resistance rated) 1 hour on the Underside 4 feet
  • (Not fire-resistance rated) 0 hours 3 feet
  • Openings Not allowed N/A
  • 25% Maximum of Wall Area 0 hours < 3 feet
  • Unlimited 0 hours 3 feet
  • Penetrations
  • All
  • Comply with Section R317.3 < 3 feet
  • None required 3 feet
  • N/A = Not Applicable.
chapter 3 section r303 6 stairway illumination
CHAPTER 3-SECTION R303.6 STAIRWAY ILLUMINATION
  • R303.6.1 Light activation. Where lighting outlets are installed in interior stairways, there shall be a wall switch at each floor level to control the lighting outlet where the stairway has six or more risers. The illumination of exterior stairways shall be controlled from inside the dwelling unit.
  • Exception: Lights that are continuously illuminated or automatically controlled.
chapter 3 section r305 1 ceiling height minimum height exc 3
Chapter 3-section R305.1 Ceiling Height-Minimum height. Exc. # 3
  • The code section has been revised to clarify that only 50% of a room’s required floor area must have a minimum 7-foot ceiling height in rooms with sloped ceilings.
section r308 1 glazing identification
Section R308.1 Glazing Identification
  • R308.1 Identification. Each pane shall bear the manufacturer’s label designating the type and thickness of glass or glazing material. Except as indicated in Section R308.1.1, each pane of glazing installed in hazardous locations as defined in Section R308.4 shall be provided with a manufacturer’s or installer’s label, designating the type and thickness of glass and the safety glazing standard with which it complies, which is visible in the final installation. The safety glazing label shall be acid etched, sandblasted, ceramic-fired, embossed mark, or shall be of a type which once applied cannot be removed without being destroyed. Laminated glass, other than as used for safety glazing, shall be permanently identified as per this section, designating laminator, overall glass thickness and trade name of interlayer.
section r308 1 identification
Section R308.1 Identification
  • R308.1 Identification.
  • Exceptions:
  • 1. For other than tempered glass, labels may be omitted provided the building official approves the use of a certificate, affidavit or other evidence furnished by the glazing contractor certifying that each light is glazed in accordance with approved construction documents that comply with the provisions of this chapter confirming compliance with this code.
  • 2. Tempered spandrel glass may be identified by the manufacturer with a removable paper label.
chapter 3 section r309 1 2
Chapter 3-section R309.1.2
  • R309.1.2 Other penetrations. Penetrations through the separation required in Section R309.2 {garage walls & ceilings} shall be protected by filling the opening around the penetrating item with approved material to resist the free passage of flame and products of combustion.
chapter 3 section r309 2 separation required
Chapter 3-section R309.2 Separation required.
  • Garages located less than 3 feet from a dwelling unit on the same lot shall be protected with not less than 1/2-inch gypsum board applied to the interior side of exterior walls that are within this area. Openings in these walls shall be regulated by Section R309.1. This provision does not apply to garage walls that are perpendicular to the adjacent dwelling unit wall.
new chapter 3 section 310 emergency escape rescue openings
New CHAPTER 3-SECTION 310 Emergency Escape & Rescue Openings
  • R310.1 Emergency escape and rescue required. Basements and every sleeping room shall have at least one operable emergency escape and rescue opening.
  • Exception: Basements used only to house mechanical equipment and not exceeding total floor area of 200 sq. ft.
r310 4 bars grills covers and screens
R310.4 Bars, grills, covers and screens.
  • The temporary installation or closure of storm shutters, panels and other approved hurricane protection devices shall be permitted on emergency escape and rescue openings during the threat of a storm. Such devices shall not be required to comply with the operational constraints of Section R310.1.4.
r310 4 bars grills covers and screens65
R310.4 Bars, grills, covers and screens.
  • R310.1.4 Operational constraints. Emergency escape and rescue openings shall be operational from the inside of the room without the use of keys, tools or special knowledge.
r310 4 bars grills covers and screens66
R310.4 Bars, grills, covers and screens.
  • While such protection is provided, at least one means of escape from the dwelling or dwelling unit shall be provided. The means of escape shall be within the first floor of the dwelling or dwelling unit and shall not be located within a garage without a side-hinged door leading directly to the exterior.
r311 4 3 landings at doors
R311.4.3 Landings at Doors.
  • R311.4.3 Landings at doors. There shall be a floor or landing on each side of each exterior door.
  • Exception: Where a stairway of two or fewer risers is located on the exterior side of a door, a landing is not required for the exterior side of the door.
r311 4 3 landings at doors68
R311.4.3 Landings at Doors.
  • The floor or landing at exterior doors required by Section R311.4.1 shall not be required to comply with this requirement but shall have a rise no greater than that permitted in Section R311.5.3.
new frc chapter 3 section 312 1
New FRC.CHAPTER 3-SECTION 312.1
  • R312.1 Guards. Porches, balconies, ramps or raised floor surfaces located more than 30 inches above the floor or grade below shall have guards not less than 36 inches in height.
chapter 3 section 313 2 1
CHAPTER 3-SECTION 313.2.1
  • When alterations, repairs or additions requiring a permit occur, or when one or more sleeping rooms are added or created in existing dwellings, the individual dwelling unit shall be equipped with smoke alarms located as required for new dwellings; the smoke alarms shall be interconnected and hard wired.
  • Exceptions:
chapter 3 section r313 2 1
CHAPTER 3-SECTION R313.2.1
  • 1. Interconnection and hard-wiring of smoke alarms in existing areas shall not be required where the alterations or repairs do not result in the removal of interior wall or ceiling finishes exposing the structure, unless there is an attic, crawl space or basement available which could provide access for hard wiring and interconnection without the removal of interior finishes.
chapter 3 section r313 2 172
CHAPTER 3-SECTION R313.2.1
  • 2. Work involving the exterior surfaces of dwellings, such as the replacement of roofing or siding, or the addition or replacement of windows or doors, or the addition of a porch or deck, are exempt from the requirements of this section.
carbon monoxide florida statute rule 9b 3 0472
CARBON MONOXIDE FLORIDA STATUTE RULE 9B-3.0472
  • (1) Definitions: For purposes of this rule, the following definitions shall apply:
  • (a) CARBON MONOXIDE ALARM. A device for the purpose of detecting carbon monoxide, that produces a distinct audible alarm, and is listed or labeled with the appropriate standard, either ANSI/UL 2034 - 96, Standard for Single and Multiple Station CO Alarms, incorporated herein by reference, or UL 2075 - 04, Gas and Vapor Detector Sensor, incorporated herein by reference, in accordance with its application.
r313 4 carbon monoxide protection
R313.4 CARBON MONOXIDE PROTECTION

Every building for which a permit for new construction is issued having a fossil-fuel-burning heater or appliance, a fireplace, or an attached garage shall have an operational carbon monoxide alarm installed within 10 feet of each room used for sleeping purposes.

r313 4 1 carbon monoxide protection
R313.4.1 CARBON MONOXIDE PROTECTION

R313.4.1 Power Source. In new construction, alarms shall receive their primary power from the building wiring when such wiring is served from the local power utility. Such alarms shall have battery back up.

r314 1 foam plastic
R314.1 FOAM PLASTIC

R314.1 General.

The provisions of this section shall govern the materials, design, application, construction and installation of foam plastic materials.

chapter 3 section r317 dwelling unit separation
Chapter 3-Section R317Dwelling Unit Separation
  • R317.1 Two-family dwellings. Dwelling units in two-family dwellings shall be separated from each other by wall and/or floor assemblies having not less than a 1-hour fire-resistance rating.
chapter 3 section r317 dwelling unit separation78
Chapter 3-Section R317Dwelling Unit Separation
  • Exceptions: 1 & 2
  • 1. A fire-resistance rating of 1/2 hour shall be permitted in buildings equipped throughout with an automatic sprinkler system installed in accordance with NFPA 13.
r317 dwelling unit separation two family dwellings
R317 Dwelling Unit Separation Two-family dwellings
  • Exceptions:
  • 2. Wall assemblies need not extend through attic spaces when the ceiling is protected by not less than 5/8-inch Type X gypsum board and an attic draft stop constructed as specified in Section R502.1.2.1 is provided above and along the wall assembly separating the dwellings. The structural framing supporting the ceiling shall also be protected by not less than 1/2-inch gypsum board or equivalent.
section r502 12 1
Section R502.12.1
  • Draftstopping materials shall not be less than 1/2-inch gypsum board, 3/8-inch wood structural panels, 3/8-inch Type 2-M-W particleboard or other approved materials adequately supported.
section r320 7 protection against decay and termites revise text to read as follows
Section R320.7 Protection against decay and termites, revise text to read as follows:
  • Condensate Lines, irrigation/sprinkler system risers for spray heads, and roof downspouts shall discharge at least 1 foot away from the structure sidewall, whether by underground piping, tail extensions or splash blocks. Gutters with downspouts are required on all buildings with eaves of less than 6 inches horizontal projection except for gable end rakes or on a roof above another roof.
section r326 1 elevators revise text to read as follows
Section R326.1 Elevators, revise text to read as follows:
  • R3263.1 Elevators. Where provided, passenger elevators, limited-use/limited-application elevators or private residence elevators shall comply with ASME A17.1.
thank you
Thank You
  • The First Coast Chapter of the Building Officials Association of Florida.
